NuvoMed Opvarmet Rygmassage Brugermanual

1. Introduktion

Thank you for choosing the NuvoMed Heated Back Wrap Massager. This device is designed to provide soothing heat and optional vibration massage to the lower back area, promoting relaxation and temporary relief from minor muscle aches. Please read this manual thoroughly before use to ensure safe and proper operation. Keep this manual for future reference.

Vigtige sikkerhedsoplysninger

• Do not use this product if you have a pacemaker, are pregnant, or have any serious medical conditions without consulting a physician.
• Do not use on sensitive skin areas, open wounds, or swollen areas.
• Avoid using while sleeping.
• Do not immerse the device in water or use it in excessively humid environments.
• Opbevares utilgængeligt for børn.
• Afbryd strømmen, når den ikke er i brug.
• If you experience discomfort, discontinue use immediately.

2. Pakkens indhold

Kontroller venligst, at alle nedenstående varer er inkluderet i din pakke:

• 1x NuvoMed Heated Back Wrap Massager
• 1x Belt Extender
• 1x USB Cable (Micro USB, 6 feet)
• 1x brugermanual

3. Produktet er slutview

Familiarize yourself with the components of your Heated Back Wrap Massager.

Billede 3.1: Top view of the NuvoMed Heated Back Wrap Massager, showing the integrated control panel and the attached USB power cable.

Komponenter:

• Main Belt: Constructed from durable Neoprene material with carbon fiber heating elements.
• Kontrolpanel: Integrated buttons for power, heat settings, and vibration settings.
• USB strømport: For connecting the USB cable to a power source.
• Hook and Loop Fasteners: For adjustable and secure fitting around the waist.
• Belt Extender: Provides additional length for a comfortable fit.

Billede 3.2: Indvendigt view of the massager, highlighting the grid pattern of the heating elements.

Kontrolpanelets funktioner:

• Power knap: Tænder/slukker enheden.
• Heat Setting Button: Cycles through 3 heating levels (Low, Medium, High).
• Vibration Setting Button: Activates and cycles through vibration modes (if applicable).

4. Opsætning

1. Pakker ud: Carefully remove the Heated Back Wrap Massager and all accessories from the packaging.
2. Tilslut strøm: Insert the Micro USB end of the provided USB cable into the USB power port on the massager. Connect the standard USB-A end of the cable to a compatible 5V 2A USB power source (e.g., a wall adapter or a portable power bank, not included).
3. Placering: Wrap the massager around your lower back, ensuring the heating elements are positioned over the desired area. Secure the belt using the hook and loop fasteners. If needed, attach the belt extender for a more comfortable fit.

Image 4.1: The Heated Back Wrap Massager being worn by an individual, demonstrating proper placement around the lower back.

5. Betjeningsvejledning

Tænd/sluk:

• Press and hold the Power button for approximately 2-3 seconds to turn the device ON.
• Press and hold the Power button again for 2-3 seconds to turn the device OFF.

Justering af varmeindstillinger:

The massager features 3 heating levels. Once the device is powered on:

• Press the Heat Setting button to cycle through the available heat levels.
• Each press will change the heat intensity (e.g., Low, Medium, High, Off).
• Observe the indicator lights on the control panel to identify the current heat level.

Activating Vibration Massage:

The massager offers an optional vibration massage mode:

• Press the Vibration Setting button to activate the vibration function.
• Subsequent presses will cycle through different vibration patterns or intensities, or turn the vibration off.
• Refer to the control panel indicators for the active vibration mode.

It is recommended to start with the lowest heat and vibration settings and gradually increase to a comfortable level. Do not use for extended periods without breaks.

6. Vedligeholdelse og pleje

• Rensning: Disconnect the massager from the power source before cleaning. Wipe the surface with a soft, damp klæde. Brug ikke slibende rengøringsmidler eller nedsænk enheden i vand.
• Opbevaring: When not in use, ensure the device is clean and dry. Fold it flat for convenient storage in a cool, dry place, away from direct sunlight and extreme temperatures.
• Håndtering: Avoid sharp objects that could damage the Neoprene material or internal components. Do not pull on the USB cable excessively.

7. Fejlfinding

Hvis problemet fortsætter efter at have forsøgt disse løsninger, bedes du kontakte kundesupport.

8. Specifikationer

9. Garanti og support

NuvoMed products are manufactured to high-quality standards. For information regarding warranty coverage, please refer to the warranty card included with your product or visit the official NuvoMed website. For technical support, troubleshooting assistance, or to inquire about replacement parts, please contact NuvoMed customer service.

Juridisk ansvarsfraskrivelse: Statements regarding dietary supplements have not been evaluated by the FDA and are not intended to diagnose, treat, cure, or prevent any disease or health condition. This product is intended for personal comfort and relaxation purposes only.
