Caroma Peak K1 El-løbehjul med sæde Brugsanvisning

Indledning

This manual provides essential information for the safe operation, assembly, maintenance, and troubleshooting of your Caroma Peak K1 Electric Scooter with Seat. Please read this manual thoroughly before first use to ensure optimal performance and safety.

The Caroma Peak K1 Electric Scooter features a powerful 350W motor (500W peak) for speeds up to 20 MPH, a 36V removable lithium-ion battery offering up to 15 miles per charge, and a robust aluminum frame. Designed for adult commuting, it includes dual seats, a front basket, and front shock absorption for a comfortable ride.

Sikkerhedsoplysninger

Your safety is paramount. Always wear a helmet and appropriate safety gear when operating the scooter. Adhere to local traffic laws and regulations. This scooter is designed for adults and has a weight limit of 330 pounds. The product has passed UL2272 certification, ensuring it meets stringent safety standards.

• Bær altid hjelm og beskyttelsesudstyr.
• Kør ikke i dårligt vejr.
• Sørg for, at alle komponenter er forsvarligt fastgjort før hver tur.
• Familiarize yourself with the dual braking system.
• Overskrid ikke den maksimale vægtgrænse på 330 pund.
• The scooter is equipped with an LED headlight and reflectors for visibility.

Pakkens indhold

Ved udpakning skal du kontrollere, at alle dele er til stede:

• Caroma Peak K1 Electric Scooter Frame (partially assembled)
• Forhjul
• Samling af styr
• Forskærm
• Frontkurv
• Seat (main)
• Bagsæde
• Støtteben
• Oplader
• Installation Tools (Allen wrench, spanner)
• Brugermanual

Opsætning og montering

The scooter comes mostly assembled. Follow these steps for final assembly:

1. Pak scooteren ud: Fjern forsigtigt alle emballagematerialer og komponenter fra kassen.


   Image: The Caroma Peak K1 Electric Scooter components as they appear after unpacking from the box, wrapped in protective materials.
2. Install the Kickstand: Attach the kickstand to the designated mounting points on the scooter frame using the provided bolts and Allen wrench. Ensure it is securely tightened.
3. Installer styret: Insert the handlebar stem into the front fork tube. Align the handlebar with the front wheel and tighten the top bolt using the Allen wrench.
4. Install the Front Fender and Headlight: Attach the front fender to the front fork. The headlight is pre-attached but may need to be secured or adjusted. Ensure the fender supports are properly fastened.
5. Monter forhjulet: Carefully align the front wheel with the front fork dropouts. Ensure the brake disc is correctly positioned between the brake pads. Secure the wheel with the provided nuts and washers, tightening them firmly with the spanner.


   Image: Close-up of the front wheel of the Caroma Peak K1 Electric Scooter, showing the disc brake and tire tread.

6. Installer sæderne: Insert the main seat post into the frame and adjust to your preferred height. Secure it with the quick-release lever. Attach the rear seat to the rear rack using the provided hardware.
7. Installer den forreste kurv: Attach the front basket to the handlebar stem using the provided screws and screwdriver.
8. Oppust dæk: Inflate both tires to the recommended pressure (check tire sidewall for PSI).

Betjeningsvejledning

1. Tænd/sluk: Insert the key into the battery lock and turn it to the 'on' position. Press and hold the power button on the handlebar display to turn the scooter on. Repeat to turn off.
2. Gashåndtag: The scooter uses a throttle technique. Gently twist the throttle on the right handlebar to accelerate.
3. Hastighedstilstande: Use the buttons on the display to cycle through different speed modes (Speed 1, 2, 3). Speed 3 typically allows for a top speed of 20 MPH under ideal conditions.
4. Forlygte: Press the dedicated button on the handlebar to turn the LED headlight on or off.
5. Bremsning: Use the brake levers on both handlebars to engage the mechanical dual disc brakes. Apply both brakes simultaneously for optimal stopping power.
6. Vise: The smart LCD display shows battery life, current speed, odometer, trip distance, and voltage.

Image: Close-up of the handlebar display on the Caroma Peak K1 Electric Scooter, showing speed, battery level, and other ride data.

Opretholdelse

• Batteriopladning: The 36V lithium-ion battery can be charged while installed on the scooter or removed. It takes approximately 3 hours for a full charge. The BMS system provides 14 types of protection for battery safety and longevity.


  Image: Close-up of the removable 36V lithium-ion battery on the Caroma Peak K1 Electric Scooter, highlighting its features and charging port.

• Dæktryk: Regularly check and maintain the correct tire pressure for optimal performance and safety.
• Bremsejustering: Periodically check brake responsiveness and adjust as needed to ensure effective stopping.
• Generel rengøring: Keep the scooter clean and free of dirt and debris. Avoid direct high-pressure water washing on electrical components.

Fejlfinding

• Scooter tænder ikke: Ensure the battery is properly inserted, charged, and the key is in the 'on' position. Check all connections.
• Reduceret ydeevne: Check tire pressure, battery charge level, and ensure no components are loose or damaged.
• Bremserne reagerer ikke: Inspect brake cables for tension and pads for wear. Adjust as necessary.
• Usædvanlige lyde: Stop riding immediately and inspect the scooter for loose parts, debris, or damage.

Specifikationer

Image: Detailed dimensions and specifications of the Caroma Peak K1 Electric Scooter, including handlebar height, total length, wheel height, standover height, handlebar reach, wheelbase, and maximum seat height.

Garanti og support

The Caroma Peak K1 Electric Scooter comes with a 365-day warranty and lifetime technical support. For any inquiries or assistance, please refer to the contact information provided in your user manual or visit the official Caroma webwebsted.
