GOLABS CT1 2-Person Campinstruktionsmanual til teltet

Indledning

This manual provides detailed instructions for the proper setup, operation, maintenance, and care of your GOLABS CT1 2-Person Camping Tent. Please read this manual thoroughly before using the tent to ensure a safe and enjoyable experience. Retain this manual for future reference.

Produkt overview

Nøglefunktioner

• Praktisk størrelse: Outer dimensions: 84.6 x 65 x 48.8 inches; inner dimensions: 82.7 x 59 x 48 inches. Designed for two adults.
• Vandtæt beskyttelse: Features PU1500mm waterproof coating and premium fabric to keep the interior dry.
• Holdbare materialer: Constructed with 190D polyester taffeta and strong fiberglass poles for reliability.
• Breathable Comfort: Mesh skylight and door provide ventilation and insect protection.
• Let og bærbar: Weighs approximately 4.4 lbs and packs into a 20.1 x 5.9 inch carry bag.
• Smart Interior Design: Includes one hook for lanterns or small items and two storage pockets.

Komponenter inkluderet

Verify that all components are present before attempting to set up your tent.

Image: All components of the GOLABS CT1 tent, including the tent body, poles, stakes, ropes, and carry bag.

• Tent Body (with integrated rainfly)
• Poles x 2 (Fiberglass)
• Indsats x 7
• Ropes x 3
• Bæretaske x 1

Opsætningsinstruktioner

The GOLABS CT1 tent is designed for quick and easy setup, typically within 3 minutes for experienced users.

Image: Step-by-step visual representation of the tent setup process.

1. Pakker ud: Remove the tent and all components from the carry bag. Lay the tent body flat on a clear, level surface, ensuring the floor is spread out.
2. Saml stænger: Connect the sections of the two fiberglass poles.
3. Indsæt poler: Locate the pole sleeves on the tent body. Carefully slide each pole through its corresponding sleeve, forming an 'X' shape over the tent.
4. Sikre stænger: Insert the ends of the poles into the grommets or pins located at the corners of the tent. This will raise the tent structure.
5. Fastgør klips: Clip the tent body to the poles using the plastic clips along the pole sleeves.
6. Indsats ned: Secure the tent to the ground using the provided stakes. Insert stakes through the loops at each corner and along the sides. For added stability, especially in windy conditions, attach the ropes to the designated points and stake them out.
7. Justere: Ensure the tent is taut and stable. Adjust stakes and ropes as needed.

Betjening af teltet

Ventilation

Image: The tent's mesh door and top provide airflow, keeping the interior cool.

The GOLABS CT1 tent features a mesh skylight and a mesh door. These elements are crucial for maintaining airflow and reducing condensation inside the tent. Keep the mesh door and skylight uncovered when conditions allow to maximize ventilation and keep insects out.

Vandtætte funktioner

Image: The tent in a rainy environment, showcasing dens vandtætte design.

The tent is equipped with a PU1500mm waterproof coating. This coating, combined with the tent's fabric, provides protection against rain. Ensure all zippers are fully closed during rain to prevent water entry.

Indvendige funktioner

Billede: Detaljeret view of the tent's internal hook and storage pockets.

• Lanternekrog: A built-in hook is provided at the top of the tent for hanging a lantern or other lightweight items.
• Opbevaringslommer: Two interior storage pockets are available to keep small essentials organized and within reach, such as phones, flashlights, or glasses.

Opretholdelse

Proper maintenance extends the life of your tent and ensures its performance.

• Rensning: Clean the tent with a soft sponge and mild soap (non-detergent) and lukewarm water. Do not use harsh chemicals, bleach, or machine wash. Spot clean only.
• Tørring: Sørg altid for, at teltet er helt tørt, inden du pakker det væk.amp tent can lead to mildew, odor, and fabric degradation. Air dry in a shaded area.
• Opbevaring: Opbevar teltet i bæretasken på et køligt, tørt sted, væk fra direkte sollys og ekstreme temperaturer.
• Pleje af stang: Inspect poles for cracks or damage before and after each use. If a pole splinters, repair kits are available.
• Lynlåspleje: Keep zippers clean and free of dirt. Lubricate occasionally with a silicone-based zipper lubricant if they become stiff.

Fejlfinding

Kondens inde i teltet

• Årsag: Body heat and moisture from breathing, combined with cooler outside air, can cause condensation.
• Løsning: Maximize ventilation by keeping the mesh door and skylight open whenever weather permits. Ensure adequate airflow around the tent.

Vandlækager

• Årsag: Improper setup, damaged fabric, or worn seams.
• Løsning: Ensure the tent is pitched tautly and correctly. Check for small holes or tears and repair with a tent repair kit. Seams can be re-sealed with a seam sealer product.

Poles Not Fitting/Breaking

• Årsag: Incorrect pole assembly or excessive force during setup.
• Løsning: Ensure pole sections are fully seated. Avoid bending poles excessively. If a pole breaks, use a pole repair sleeve (often included in tent repair kits) or contact customer support for replacement parts.

Specifikationer

Garantioplysninger

The GOLABS CT1 2-Person Camping Tent comes with a 1 års begrænset garanti from the date of purchase. This warranty covers manufacturing defects in materials and workmanship. It does not cover damage caused by misuse, improper setup, accidents, normal wear and tear, or modifications.

Gem venligst dit købsbevis for garantikrav.

Kundesupport

For any questions, concerns, or assistance with your GOLABS CT1 Camping Tent, please contact GOLABS customer support.

Webwebsted: www.golabs.com (Eksample Link, please refer to actual product packaging for official contact details)

E-mail: support@golabs.com (Eksample Email, please refer to actual product packaging for official contact details)
