KINGBOLEN S608 OBD2 tovejsscanningsværktøj brugermanual

1. Introduktion

The KINGBOLEN S608 is an advanced OBD2 bidirectional scan tool designed for comprehensive automotive diagnostics. It provides powerful active tests, 9 essential reset functions, and full system diagnostics for Engine, ABS, SRS, and Transmission systems. This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your S608 device.

2. Pakkens indhold

• 1 * KINGBOLEN S608 Bidirectional OBD2 Scanner
• 1 * OBDII Diagnostic Cable
• 1 * Type-C USB Cable
• 1 * Hurtig startvejledning

3. Opsætning

1. Første opstart: Upon receiving your S608, ensure it is fully charged using the provided Type-C USB cable and a compatible power adapter. The device will power on automatically or can be powered on by pressing the power button.
2. Sprogvalg: Follow the on-screen prompts to select your preferred language from the 28 available options.
3. Wi-Fi-forbindelse: Connect the device to a stable Wi-Fi network for software updates and online services. Navigate to 'Settings' and select 'Wi-Fi' to connect.
4. Softwareopdatering: After connecting to Wi-Fi, navigate to the 'Upgrade' section to perform a one-click update. This ensures your device has the latest vehicle coverage and functions.
5. Tilslutning til køretøj: Locate your vehicle's OBDII port (typically under the dashboard). Connect the OBDII diagnostic cable to the S608 and then to the vehicle's OBDII port. Turn the vehicle's ignition to the 'ON' position (engine off or running, depending on the diagnostic task).

4. Betjeningsvejledning

4.1 Grundlæggende navigation

The S608 features a 6.2-inch HD touchscreen and physical buttons for navigation. Use the touchscreen for direct selection or the directional pad and 'OK' button for menu navigation. The 'Return' button navigates back to the previous screen.

4.2 Automatic Vehicle Identification (AutoVIN)

For most vehicles manufactured after 2006, the S608 can automatically identify the vehicle's brand, model, and year within 10 seconds. This streamlines the diagnostic process by ensuring correct vehicle information. If AutoVIN does not work, manual VIN entry is available.

4.3 4-System Diagnostics

The S608 provides in-depth diagnostics for four essential vehicle systems:

• Motorsystem: Reads and clears Diagnostic Trouble Codes (DTCs), turns off the Check Engine Light, and displays live data. Helps identify issues related to lubrication, fuel, air compression, cooling, and sensor failures.
• Antilock Braking System (ABS): Accesses and diagnoses ABS systems. Reads/clears ABS fault codes, turns off warning lights, and monitors real-time data such as wheel speed and ESP sensor data.
• Airbag System (SRS): Reads and clears fault codes within the SRS system, turning off the airbag warning light to ensure proper and safe operation of safety components.
• Transmissionssystem: Views live data, reads and clears codes in transmission systems, and turns off the warning light. Supports reading transmission temperature to assist in timely gearbox repairs.

Image: Multi-System Diagnostics Interface. The S608 can quickly scan and report on the Engine, ABS, SRS, and Transmission systems, displaying fault codes and live data.

4.4 Tovejsstyring (aktive test)

This function allows the S608 to send commands to vehicle ECUs to perform specific tests on actuators. This helps in quickly identifying faulty components without extensive disassembly.

• Motor: EVAP test, A/C clutch activation, fuel injector activation, fuel pump on/off, VTEC test, ETCS(TAC) test, throttle valve actuation, cylinder balance test.
• ABS: ABS solenoid test, ABS inlet/outlet valve test, bleeding procedure, pump motor test, modulator test, valve sequence test.
• SRS: Triggering belt tensioner crash signal, front passenger airbag-disabled-indicator lamp, component protection, seat belt pretensioner circuit test, safing sensor test, SRS warning lamp kontrollere.
• Transmission (TCM): Shift solenoid pressure control, converter pressure control, firm shift, gear command by output state control, line pressure control, output state control of torque converter, transmission adaptive values reset/relearn, quick learn/factory adaptations.

Image: Bidirectional Active Tests. The S608 allows direct control over various vehicle components for precise fault isolation.

4.5 Special Functions (9 Reset Services)

The S608 provides 9 common reset functions to assist with vehicle maintenance:

• Olie nulstilling: Resets the oil life reminder and turns off the oil change light after an oil replacement.
• SAS kalibrering: Performs steering angle sensor calibration, clears fault memories, and sets the steering angle to zero.
• Brake Reset (EPB): Retracts electric parking brake calipers for pad replacement and resets the brake pad position.
• DPF-regenerering: Initiates the regeneration process for the Diesel Particulate Filter to restore efficiency.
• Injektorkodning: Writes new injector codes into the ECU or rewrites existing codes after injector replacement to ensure accurate fuel injection.
• BMS Matching (Battery Matching): Resets the monitoring unit of the vehicle battery and registers new battery replacements.
• Tilpasning af gashåndtaget: Relearns the throttle's operating parameters and makes initial settings to throttle actuators after replacement or cleaning.
• ABS-blødning: Assists in bleeding the brakes by cycling the pump and valves during the bleeding process to remove air from the system.
• Gearindlæring: Allows the transmission control module (TCM) to recalibrate and adapt to new or worn components, improving shift timing and fuel efficiency.

Image: 9 Special Functions. The S608 offers a range of reset services for common maintenance tasks.

4.6 Fuld OBDII-funktioner

The S608 supports all 10 OBD2 test modes for emission-related diagnostics:

• Læs koder
• Slet koder
• Live-datastrøm
• Frys rammedata
• I/M-parathedsstatus
• O2 Sensortest
• On-board Monitor Test
• EVAP System Test
• Køretøjsoplysninger
• Komponenttest

4.7 Data Stream Analysis

The device provides real-time sensor data in text and graphical formats. You can view single, merged, or multi-graph displays (4-in-1) for parameters like engine RPM, transmission oil temperature, engine load, fuel pressure, and throttle response. Data can be recorded and replayed for further analysis.

4.8 Diagnostic Report Management

After completing a diagnostic session, the S608 automatically generates detailed reports. These reports can be viewed, saved, shared via email/Bluetooth, or printed. The 'Pre & Post Scan' feature documents vehicle conditions before and after repairs, providing a clear comparison. Diagnostic history is saved for quick access to previous test reports.

4.9 DTC Lookup & Google Code Search

A built-in library of over 3000 fault codes provides definitions and diagnostic tips. For more detailed repair information, the integrated Google browser allows instant access to repair videos, wiring diagrams, and parts databases directly on the tool.

4.10 Vehicle Coverage Inquiry

The S608 includes a 'Vehicle Coverage' database. Users can quickly check if their specific vehicle model is supported by the scanner before initiating a diagnostic session. The device supports over 110 global brands and 10,000+ models from 1996-2025, including new CAN FD protocols for 2019+ GM/Chrysler and secure access for 2017+ FCA and 2015+ Renault SGW vehicles (requires separate AutoAuth/Renault account/token).

Image: Vehicle Coverage. The S608 offers extensive compatibility with global vehicle brands and supports advanced protocols.

5. Vedligeholdelse

• Softwareopdateringer: The S608 offers lifetime free software updates via Wi-Fi. Regularly check for and install updates to ensure the latest vehicle coverage and functions. Navigate to the 'Upgrade' section and follow the prompts.
• Batteripleje: The device is equipped with a 4150mAh battery. For optimal battery life, avoid extreme temperatures and fully charge the device when not in use for extended periods.
• Rensning: Brug en blød, tør klud til at rengøre enheden. Undgå at bruge skrappe kemikalier eller slibende materialer.

6. Fejlfinding

• Unable to Scan All Modules: The KINGBOLEN S608 is designed for 4-system diagnostics (Engine, ABS, SRS, Transmission). For full-system scans or advanced ECU coding (e.g., BCM, TPMS, HVAC), consider upgrading to KINGBOLEN K7 or K8 diagnostic tools.
• OBD2 Cable Length: An OBD2 extension cable is available at no cost. Contact customer support via your Amazon order to request one.
• Warning Light Remains On: If a warning light persists after clearing codes, it indicates that the underlying problem has not been resolved. Address the mechanical issue before attempting to clear codes again.
• Inkompatibilitetsproblemer: If you encounter incompatible models or abnormal diagnostic functions, provide the vehicle's VIN to customer support for assistance.

7. Specifikationer

8. Garanti og support

KINGBOLEN is committed to providing reliable products and excellent customer service.

• Garanti: The KINGBOLEN S608 comes with a 5-year warranty.
• Livstids gratis opdateringer: Enjoy lifetime free software updates via Wi-Fi, ensuring your device remains current with the latest vehicle models and systems.
• Returnerings-/erstatningspolitik: An extended 60-day replacement or return policy is provided.
• Onlinefeedback: For incompatible models or abnormal functions, submit online feedback to the KINGBOLEN team for analysis and troubleshooting.
• Instant Live Support: Access live technical support directly from the device by tapping the 'Service' button. Share detailed reports via chat for faster issue resolution.
• Fjernhjælp: For complex issues, remote assistance is available to connect with an expert who can help diagnose and resolve problems remotely.
• Kontaktoplysninger: For further assistance, you can reach out via email at ediagtools@hotmail.com or call 1-323-325-5773.
