KENT RoboKlean R1 robotstøvsuger og moppe brugermanual

1. Introduktion

This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your KENT RoboKlean R1 Robotic Vacuum Cleaner & Mop. Please read this manual thoroughly before using the product and retain it for future reference.

Figure 1: KENT RoboKlean R1 Robotic Vacuum Cleaner and its accompanying smart home application interface.

2. Produktet er slutview

The KENT RoboKlean R1 is an advanced 2-in-1 robotic vacuum cleaner and mop designed for comprehensive floor cleaning. It features AI-powered navigation, strong suction, and smart control options.

Nøglefunktioner:

• Advanced LDS (Laser Distance Sensor) Navigation: For precise mapping and efficient cleaning paths.
• Reaktiv AI-forhindringsgenkendelse: Detects and avoids obstacles to prevent damage and getting stuck.
• 8500Pa Ultra-Strong Suction: Effectively picks up dirt, dust, and debris from various surfaces.
• Våd- og tørrensning: Integrated vacuuming and mopping functions.
• 5200mAh batteri: Provides up to 3 hours (180 minutes) of runtime on a single charge.
• Selvopladning: Automatically returns to the charging station when the battery is low.
• Smart-app og stemmestyring: Compatible with KENT Smart Home app, Amazon Alexa, and Google Home Assistant.
• Anti-Fall Feature: Sensors protect the robot from accidental falls down stairs or ledges.
• HEPA-filtreringssystem: Captures minute particles and allergens for a healthier environment.

Figure 2: The KENT RoboKlean R1 operating in a home environment, demonstrating hands-free cleaning.

3. Opsætning

3.1 Udpakning og komponenttjek

Carefully remove all components from the packaging. Ensure all items listed in the 'Included Components' section of the specifications are present.

3.2 Placering af ladestation

Place the charging station against a wall in an open area, ensuring there are no obstacles within 1 meter to the sides and 1.5 meters in front of the station. Connect the power adapter to the charging station and plug it into a power outlet.

3.3 Indledende opladning

Place the RoboKlean R1 onto the charging station. Ensure the charging contacts on the robot align with those on the station. Allow the robot to fully charge before its first use. The indicator light on the robot will change to indicate a full charge.

3.4 Appinstallation og parring

1. Download the 'KENT Smart Home' app from your device's app store.
2. Opret en konto eller log ind.
3. Follow the in-app instructions to add your RoboKlean R1 device. This typically involves connecting the robot to your home Wi-Fi network.

3.5 Indledende kortlægning

After initial setup, initiate a full cleaning cycle or a mapping run through the app. The robot will use its LDS navigation to create a detailed map of your home, which is crucial for efficient cleaning and setting up custom zones.

Figure 3: The RoboKlean R1 utilizes advanced LiDAR navigation for precise real-time mapping of your home layout.

4. Betjeningsvejledning

4.1 Start af en rengøringscyklus

You can start a cleaning cycle using the physical button on the robot, the KENT Smart Home app, or voice commands via Amazon Alexa or Google Home Assistant.

4.2 Rengøringstilstande

• Automatisk rengøring: The robot cleans the entire mapped area.
• Rengøring af pletter: Instruerer robotten til intensiv rengøring af et specifikt lille område.
• Local Cleaning: Renser et brugerdefineret område på kortet.
• User-Defined Area Cleaning: Allows you to select specific rooms or zones for cleaning via the app.

Figure 4: The RoboKlean R1 offers diverse cleaning modes and features for customized cleaning.

4.3 Våd- og tørrengøring

The RoboKlean R1 performs both vacuuming and mopping. Ensure the water tank is filled for wet mopping. The robot is designed to handle various surfaces including tiles, marble, wooden floors, and carpets. It automatically boosts suction on carpets for deeper cleaning.

Figure 5: The RoboKlean R1's 2-in-1 functionality for wet mopping and dry vacuuming with auto-boost.

4.4 Planlægning og No-Go-zoner

Use the KENT Smart Home app to schedule cleaning times and define 'no-go zones' or virtual walls to restrict the robot from entering specific areas.

4.5 Stemmekontrol

Integrate your RoboKlean R1 with Amazon Alexa or Google Home Assistant for hands-free operation. Refer to the app for detailed instructions on connecting to these services.

5. Vedligeholdelse

Regular maintenance ensures optimal performance and extends the lifespan of your RoboKlean R1.

5.1 Skraldespand og vandtank

• Empty the 250 ML dustbin after each cleaning cycle.
• Clean the 250 ML water tank and mop pad regularly. The dustbin and mop components are designed for easy removal and washing.

5.2 HEPA-filter

Clean the HEPA filter periodically by tapping it gently to remove dust. Replace the filter every 3-6 months, or as indicated by the app or reduced suction performance.

5.3 Brushes and Sensors

• Regularly check and clean the main brush and side brushes for tangled hair or debris.
• Wipe the charging contacts, cliff sensors, and LDS sensor window with a dry cloth to ensure proper function.

5.4 Pleje af batterier

The RoboKlean R1 features a long-lasting 5200mAh battery. To maintain battery health, ensure the robot is always docked and charging when not in use. Avoid fully discharging the battery frequently.

Figure 6: The RoboKlean R1's self-charging capability ensures it is always ready for the next cleaning session.

6. Fejlfinding

If you encounter issues with your RoboKlean R1, refer to the following common troubleshooting steps:

• Robotten oplader ikke: Sørg for, at ladestationen er tændt, og at robottens opladningskontakter er rene og korrekt justeret i forhold til stationen.
• Robot sidder ofte fast: Clear obstacles from the cleaning path. Clean the Reactive AI obstacle recognition sensors.
• Dårlig rengøringsevne: Tøm støvbeholderen, rengør eller udskift HEPA-filteret, og rengør hoved- og sidebørsterne.
• Problemer med app-forbindelse: Ensure your robot and smartphone are connected to the same Wi-Fi network. Restart the app and the robot.
• Robot falder ned ad trappen: Rengør klippesensorerne på undersiden af ​​robotten.

For persistent issues, consult the 'Help' section within the KENT Smart Home app or contact customer support.

7. Specifikationer

Figure 7: Physical dimensions of the RoboKlean R1.

8. Garanti og support

8.1 Garantioplysninger

This product may be eligible for an extended warranty plan, such as the '1 Year Extended Warranty Plan by Onsitego', which can be purchased separately. Please refer to your purchase documentation for specific warranty terms and conditions. Standard warranty details are typically provided with the product at the time of purchase.

8.2 Kundesupport

For technical assistance, service requests, or any inquiries regarding your KENT RoboKlean R1, please contact KENT RO SYSTEMS LTD customer support. Contact details can usually be found on the official KENT website or within the KENT Smart Home app.

You can also find helpful resources and FAQs within the KENT Smart Home app.
