Indledning
This instruction manual provides essential information for the safe and efficient operation of your Lacidoll LCD-JSQ-J39-US 6.6 Gallon Whole House Humidifier. Please read this manual thoroughly before initial use and retain it for future reference. This humidifier is designed to provide optimal humidity levels for large spaces up to 3000 sq.ft, suitable for residential, commercial, and industrial applications.
Sikkerhedsinstruktioner
- Placer altid luftfugteren på en fast, flad og vandtæt overflade.
- Do not operate the humidifier near heat sources or in direct sunlight.
- Ensure the power cord is not damaged and is properly plugged into a suitable electrical outlet (120V AC).
- Nedsænk ikke hovedenheden i vand eller andre væsker.
- Opbevares utilgængeligt for børn og kæledyr.
- Unplug the unit before cleaning, refilling, or moving.
- Use clean, cool tap water. Distilled or demineralized water is recommended to prevent mineral buildup.
- Do not add essential oils directly into the water tank as this may damage the unit.
Pakkens indhold
Pak forsigtigt alle komponenter ud, og sørg for at du har følgende:
- Lacidoll Humidifier Main Unit
- Fjernbetjening
- Mist Output Tube with 360° Nozzle
- Caster Wheels (4 pieces)
- Brugervejledning (dette dokument)
Image: Components and features including top-fill, easy cleaning, wheels, and remote control.
Opsætning
- Udpakning: Remove all packaging materials. Locate the power cord, remote control, and mist tube inside the water tank.
- Fastgør hjul: For easy mobility, attach the four caster wheels to the bottom of the humidifier unit using the provided screws.
- Assemble Mist Tube: Insert the mist output tube into the designated opening on the top of the humidifier. Ensure it is securely seated. The 360° nozzle can be adjusted to direct mist as needed.
- Placering: Place the humidifier on a flat, stable surface in the desired location. Ensure there is at least 6 inches of space from walls and furniture for optimal mist dispersion.
- Fyld vandtank: The humidifier features a convenient top-fill design. Open the top cover and pour clean, cool water directly into the tank. Do not exceed the maximum fill line. The large 6.6-gallon (25L) capacity allows for extended operation.
- Strømtilslutning: Sæt netledningen i en standard 120V AC stikkontakt.
Image: The Lacidoll humidifier ready for use in a room, showcasing its design and mist output.
Betjeningsvejledning
Your Lacidoll humidifier can be controlled via the touch panel on the unit or the included remote control.
Grundlæggende betjening
- Tænd/sluk: Press the 'Power' button on the control panel or remote to turn the unit on or off.
- Justering af tågeniveau: Press the 'Max/Min' button to cycle through 3 mist output levels (Low, Medium, High).
- 360° dyse: Manually rotate the mist output nozzle to direct the mist in any desired direction.
Smart fugtighedskontrol
The built-in humidistat allows you to set your desired humidity level (40% to 90%).
- Indstil luftfugtighed: Press the 'Humidity Set' button. The display will show the current humidity. Use the 'Max/Min' button to adjust the target humidity. The unit will automatically maintain this level, turning off when reached and restarting when humidity drops.
Timer funktion
Set the humidifier to operate for a specific duration (1-12 hours).
- Indstil timer: Press the 'Timer' button repeatedly to select the desired operating time. The unit will automatically shut off once the set time expires.
Intermitterende tågetilstand
This mode provides mist in intervals (30s, 60s, 90s) for controlled humidification.
- Activate Intermittent Mist: Press the 'Intermittent Mist' button to cycle through the available intervals.
Image: The humidifier's smart humidity mode, showing how it maintains a set humidity level over time.
Video: En overview of the Lacidoll 25L whole house humidifier, demonstrating its features and operation.
Opretholdelse
Regular cleaning is crucial for optimal performance and longevity of your humidifier.
- Daglig vedligeholdelse: Empty and rinse the water tank daily. Refill with fresh, cool water.
- Ugentlig rengøring:
- Træk stikket ud af luftfugteren.
- Remove the mist tube and water tank.
- Wipe the inside of the water tank and water sink with a soft, damp klæde.
- To remove mineral buildup (scale), fill the water tank with a mixture of equal parts white vinegar and water. Let it soak for 20-30 minutes, then rinse thoroughly.
- Clean the transducer (mist-making component) with a soft brush or cotton swab if mineral deposits are present. Do not use harsh chemicals or abrasive cleaners.
- Skyl alle komponenter grundigt inden genmontering.
- Opbevaring: If storing the humidifier for an extended period, ensure all components are clean and completely dry. Store in a cool, dry place.
Image: The humidifier's water tank and nozzle, highlighting areas for cleaning and maintenance.
Fejlfinding
If you encounter issues with your humidifier, please refer to the following common solutions:
- Ingen tågeproduktion:
- Kontroller om enheden er tilsluttet og tændt.
- Ensure there is enough water in the tank. The unit has a waterless auto-off feature.
- Clean the transducer and water tank for mineral buildup.
- Usædvanlig lugt:
- Clean the water tank and all components thoroughly.
- Replace old water with fresh, clean water.
- Overdreven støj:
- Sørg for, at luftfugteren står på en flad, stabil overflade.
- Check for any foreign objects in the water tank or mist outlet.
- Hvidt støv:
- This is typically caused by hard water. Use distilled or demineralized water to reduce white dust.
- Clean the unit regularly to remove mineral deposits.
Hvis problemet fortsætter efter at have forsøgt disse løsninger, bedes du kontakte kundesupport.
Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Lacidoll |
| Modelnavn | LCD-JSQ-J39-US |
| Kapacitet | 6.6 gallons (25 liter) |
| Dækningsområde | Op til 3000 sq.ft |
| Driftstilstand | Ultralyd Cool Mist |
| Tågeoutput | 3000mL/h (Max) |
| Særlige funktioner | Adjustable Humidity Control, Low Water Indicator, Programmable Timer, Remote Control, Water Level Window, 360° Nozzle, Caster Wheels |
| Produktdimensioner | 17" D x 8" B x 17" H |
| Varens vægt | 12 pund |
| Voltage | 120 volt (AC) |
| Wattage | 100 watt |
Image: The humidifier's application in diverse large environments such as homes, supermarkets, and factories.
Garanti og support
Lacidoll provides a 30-day replacement policy for any manufacturing defects and 1-year support for your humidifier. If you have any questions, concerns, or require assistance with your product, please do not hesitate to contact our customer support team. Please have your model number (LCD-JSQ-J39-US) and purchase information ready when contacting support.
