KERUI 16-kanals 5MP hybrid 5-i-1 DVR brugermanual

1. Introduktion

This manual provides comprehensive instructions for the installation, operation, and maintenance of your KERUI 16-Channel 5MP Hybrid 5-in-1 Digital Video Recorder (DVR). This DVR supports various camera types including AHD, TVI, CVI, CVBS, IP, and XVI, offering a versatile solution for your security monitoring needs. Please read this manual carefully before using the product to ensure proper setup and functionality.

2. Produktet er slutview

The KERUI 16-Channel DVR is designed for high-definition surveillance, supporting 5MP resolution for clear and detailed image capture. It features advanced functionalities such as human detection, 24/7 recording, and remote access.

Nøglefunktioner:

• 5MP High Definition: Captures clear and detailed images with 5-megapixel resolution.
• Super kompatibilitet: Supports AHD, TVI, CVI, CVBS, IP, and XVI camera types, allowing connection of up to 16 cameras.
• Smart alarm: Equipped with motion detection and human detection, sending instant notifications and email alerts to your mobile device.
• Quick Playback Search: Features a pre-installed 2TB hard drive for continuous 24/7 recording and easy review af madtage.
• Advanced H.265+ Video Compression: Optimizes storage space and bandwidth by up to 50% compared to H.264.
• Fjernadgang: Monitor your property anytime, anywhere via a mobile application.

Product Components and Connections:

Billede 1: For og bag view of the KERUI 16-channel DVR, showing control buttons, video input/output ports, and a 2TB hard drive. This image illustrates the physical layout of the device and its included storage.

Billede 2: Diagram illustrating the hybrid 5-in-1 compatibility of the DVR, supporting CVBS, CVI, TVI, AHD, and XVI camera types, along with various input/output connections like audio, network, HDMI, VGA, USB, and power. This diagram helps visualize how different camera types and peripherals connect to the DVR.

Billede 3: Image highlighting the expandable storage capacity of the DVR, featuring a pre-installed 2TB HDD and support for up to 14TB external HDD, with various scenarios of property monitoring. This image demonstrates the DVR's capability for extensive video storage.

Billede 4: Comparison graphic demonstrating the efficiency of H.265+ video compression over H.264, showing up to 50% storage savings and faster downloads for H.265+. This visual explains the benefits of the advanced compression technology used in the DVR.

3. Opsætning

Follow these steps to set up your KERUI DVR system:

1. Pak ud og undersøg: Carefully unpack all components. Verify that all items listed in the packing list are present and undamaged.
2. Tilslut kameraer: Connect your AHD, TVI, CVI, CVBS, IP, or XVI cameras to the corresponding BNC video input ports (V1-V16) on the rear panel of the DVR. Ensure secure connections.
3. Tilslut skærm: Tilslut en skærm til DVR'en ved hjælp af enten HDMI- eller VGA-udgangsporten.
4. Tilslut mus: Plug the USB mouse into one of the USB ports on the DVR for navigation.
5. Tilslut netværk (valgfrit): Til fjernbetjening viewing and network features, connect an Ethernet cable from your router to the LAN port on the DVR.
6. Tilslut strøm: Connect the provided power adapter to the DVR's DC 12V power input and then plug it into a power outlet. The DVR will power on automatically.
7. Indledende konfiguration: Upon first boot, follow the on-screen wizard to set up basic parameters such as language, date/time, network settings, and password.

4. Betjeningsvejledning

This section covers basic operation of your DVR.

Levende View:

After successful setup, the DVR will display live video feeds from connected cameras on your monitor. You can switch between single-camera view og multikameragitter view using the on-screen controls or the DVR's front panel buttons.

Indspilning:

Billede 5: Visual representation of the 24/7 non-stop recording capability, showing a user monitoring multiple camera feeds on a screen, emphasizing continuous security. This image highlights the DVR's ability to record continuously for maximum security.

• Kontinuerlig optagelse: The DVR is configured for 24/7 continuous recording by default, utilizing the pre-installed 2TB HDD.
• Bevægelsesaktiveret optagelse: You can configure specific channels to record only when motion is detected. Access the recording schedule settings in the main menu.

Afspilning:

Billede 6: Sequence of images demonstrating the advanced smart playback function, allowing users to quickly review optaget footage of events, such as a person approaching a door. This image illustrates the ease of reviewved specifikke begivenheder.

• Navigate to the 'Playback' section from the main menu.
• Select the desired date and camera channel.
• Use the timeline to locate and play back recorded events. The smart playback feature allows for quick navigation to events.

Smart Alarm and Human Detection:

Billede 7: Illustration of the AI motion and human detection feature, showing detected human figures outlined in green, with app push notifications and email alerts for security events. This image demonstrates how the DVR identifies and alerts users to human activity.

• Access 'Alarm Settings' in the main menu.
• Configure motion detection zones and sensitivity for each camera.
• Enable human detection for specific channels to reduce false alarms.
• Set up email alerts and push notifications to your mobile app for immediate alerts.

Fjernadgang:

Billede 8: Graphic depicting free and easy remote access to the DVR system via a mobile application (available on App Store and Google Play), showing multiple users monitoring their property from various devices. This image illustrates the convenience of monitoring your security system remotely.

• Download the official KERUI mobile application from the App Store (iOS) or Google Play (Android).
• Register an account and add your DVR device using its unique ID or QR code.
• Når du er tilsluttet, kan du view live feeds, play back recordings, and receive alerts from anywhere with an internet connection.

5. Vedligeholdelse

Regular maintenance ensures optimal performance and longevity of your DVR system.

• Renhed: Keep the DVR unit clean and free from dust. Use a soft, dry cloth for cleaning. Do not use liquid cleaners.
• Ventilation: Sørg for, at DVR'en er placeret et godt ventileret område for at forhindre overophedning. Ventilationsåbningerne må ikke blokeres.
• Firmwareopdateringer: Kontroller jævnligt producentens website for firmware updates. Updating firmware can improve performance and add new features.
• Harddiskens tilstand: Monitor the health of the hard drive through the DVR's system settings. Replace the HDD if any issues are detected to prevent data loss.
• Adgangskodesikkerhed: Regularly change your DVR and app passwords to maintain security.

6. Fejlfinding

Dette afsnit omhandler almindelige problemer, du kan støde på.

7. Specifikationer

8. Garanti og support

For warranty information and technical support, please refer to the documentation included with your purchase or contact KERUI customer service directly. Contact details are typically available on the manufacturer's official webwebstedet eller gennem dit købssted.

If you encounter any quality issues or installation connection problems with your KERUI security DVR system, please do not hesitate to contact us at any time.
