MECHEN X55 MP3-afspiller brugermanual

1. Produktet er slutview

The MECHEN X55 is a versatile MP3 and MP4 player designed for both local and streaming media. Running on Android 10 OS, it features a 4-inch HD touchscreen, Bluetooth 4.1, and Wi-Fi connectivity. It supports a wide range of audio and video formats and comes with pre-installed popular streaming applications.

Billede 1.1: Forside view of the MECHEN X55 MP3 Player.

Nøglefunktioner:

• Android 10 OS: Provides a familiar and intuitive user experience.
• 4-tommer HD-berøringsskærm: For clear visuals and easy navigation.
• 96 GB lagerplads: Includes 32GB internal ROM and a 64GB expansion card, expandable up to 1TB.
• Bluetooth 4.1: For wireless audio connections with headphones, speakers, and car systems.
• Wi-Fi-forbindelse: Enables online streaming, app downloads, and internet access.
• HiFi tabsfri lyd: Equipped with an intelligent noise reduction chip for high-fidelity audio.
• 2000mAh batteri: Offers extended music and video playback time.

2. Kom godt i gang

2.1 Hvad er der i æsken

Pak forsigtigt kassen ud, og sørg for, at alle dele er til stede:

• 1 x MECHEN X55 Music Player
• 1 x USB-C kabel
• 1 x høretelefoner
• 1 x beskyttelsesfilm
• 1 x beskyttelsesetui
• 1 x brugermanual
• 1 x 64GB TF Card (pre-installed or separate)

Image 2.1: Contents included with the MECHEN X55 MP3 Player.

2.2 Opladning af enheden

Before first use, fully charge the MECHEN X55. Use the provided USB-C cable and a certified 5V 1A charger. Avoid fast chargers or wireless pads to prevent over-voltage-beskyttelsesproblemer.

• Connect the USB-C cable to the player's charging port.
• Connect the other end to a compatible USB power adapter.
• Opladningsindikatoren lyser. En fuld opladning tager typisk cirka 2.5 timer.

Image 2.2: MECHEN X55 MP3 Player connected for charging.

2.3 Tænd/sluk

• For at tænde: Press and hold the Power button (located on the side) until the screen illuminates.
• For at slukke: Press and hold the Power button until a power-off menu appears. Select 'Power off'.
• For at genstarte: From the power-off menu, select 'Restart'.

3. Grundlæggende betjening

3.1 Navigation med berøringsskærm

The MECHEN X55 features a responsive 4-inch IPS full-touch HD screen. Navigate the interface using standard Android gestures:

• Tryk på: For at vælge et element eller åbne en app.
• Stryg: Til at rulle gennem lister eller skifte mellem skærme.
• Knib-for-at-zoome: In supported applications like image galleries or web browsere.

3.2 Tilslutning til Wi-Fi

Wi-Fi connectivity allows for online streaming, app downloads, and internet browsing.

1. Gå til Indstillinger > Netværk og internet > Wi-Fi.
2. Slå Wi-Fi til/fra On.
3. Vælg det ønskede netværk fra listen.
4. Indtast adgangskoden, hvis du bliver bedt om det, og tryk på Forbinde.

3.3 Tilslutning via Bluetooth

The device supports Bluetooth 4.1 for connecting to wireless headphones, speakers, and other Bluetooth-enabled accessories.

1. Gå til Indstillinger > Tilsluttede enheder > Bluetooth.
2. Slå Bluetooth til/fra On.
3. Sørg for, at dit Bluetooth-tilbehør er i parringstilstand.
4. Select the accessory from the list of available devices to pair.

Image 3.1: Bluetooth connectivity options for the MECHEN X55 MP3 Player.

4. Medieafspilning

4.1 Musikafspilning

The MECHEN X55 supports various audio formats and streaming services.

• Understøttede formater: FLAC, APE, WAV, MP3, AAC, WMA, OGG, DSD (DSF/DFF), MQA, AIFF.
• Streamingapplikationer: Pre-installed apps include Spotify, Amazon Music, Oto Music, Audible, VLC Music, and more. Additional apps can be downloaded from the Play Store.
• Lokal musik: Overfør musik files from your computer to the device's internal storage or the installed TF card. Use the pre-installed music player app to browse and play your library.

Image 4.1: Music library interface and equalizer on the MECHEN X55 MP3 Player.

Image 4.2: Pre-loaded streaming applications on the MECHEN X55 MP3 Player.

4.2 Videoafspilning

The device supports high-definition video playback on its 4-inch screen.

• Understøttede formater: MP4, MKV, MOV, FLV, RMVB, DAT, MPG, TS, AVI, WMV, MPEG, WebM.
• Use the pre-installed video player app to enjoy your media.

Image 4.3: Video playback on the MECHEN X55 MP3 Player.

5. Lagerstyring

The MECHEN X55 comes with 32GB of internal storage and a 64GB TF card, totaling 96GB. Storage can be expanded further.

• Intern opbevaring: 32 GB ROM.
• Included Expansion: 64GB TF Card.
• Maksimal udvidelse: Supports Micro SD cards up to 1TB.

Image 5.1: Storage capacity and expansion options for the MECHEN X55 MP3 Player.

6. Avancerede funktioner

6.1 FM Radio, Voice Recorder, E-Book

Beyond music and video, the MECHEN X55 includes several utility features:

• FM-radio: Stil ind på lokale radiostationer.
• Stemmeoptager: Optag lyd ved hjælp af den indbyggede mikrofon.
• E-Book Reader: Read digital books and documents.

Image 6.1: Additional features of the MECHEN X55 MP3 Player.

6.2 Forældrekontrol

The device supports parental control features to manage usage and content access.

1. Install the Family Link app on a parent device.
2. Bind the MECHEN X55 device via a pairing code.
3. Set daily usage limits and content filters as desired.

Image 6.2: Parental control interface for managing device usage.

7. Vedligeholdelse

7.1 Retningslinjer for opladning

• Always use a certified 5V 1A charger.
• Avoid fast chargers and wireless charging pads, as they may trigger over-voltage protection and potentially damage the device.

7.2 Firmwareopgraderinger

Periodically check for and install firmware upgrades to ensure optimal performance and access to new features.

• Connect the device to Wi-Fi.
• Gå til Indstillinger > System > Systemopdatering.
• Følg instruktionerne på skærmen for at downloade og installere alle tilgængelige opdateringer.

Image 7.1: Firmware upgrade process on the MECHEN X55 MP3 Player.

8. Fejlfinding

Dette afsnit omhandler almindelige problemer, du kan støde på.

8.1 Almindelige problemer og løsninger

• Enheden tænder ikke: Sørg for, at batteriet er opladet. Tilslut det til en oplader i mindst 15 minutter.
• Apps der går ned eller fryser: Close background applications. Restart the device. Clear app cache in Settings.
• Problemer med Wi-Fi/Bluetooth-forbindelse: Toggle Wi-Fi/Bluetooth off and on. Restart the device. Forget and re-connect to the network/device.
• Dårlig lydkvalitet: Check headphone connection. Ensure volume is adequate. Try different audio files.

8.2 Google Account Precautions

If you plan to perform a factory reset, ensure you sign out of your Google account on the device and remove the device from your Google account settings online (google.com/devices). Failure to do so may result in a login loop after the reset.

Image 8.1: Troubleshooting tips for the MECHEN X55 MP3 Player.

9. Specifikationer

10. Garanti og support

For any product malfunctions or issues not covered in this manual, please contact MECHEN customer support. We are committed to providing assistance and resolving any problems you may encounter.

Image 10.1: MECHEN Aftersales Service information.
