ZEALOT ZE01 Bærbar Bluetooth Højttaler Brugsanvisning

1. Introduktion

Thank you for choosing the ZEALOT ZE01 Portable Bluetooth Speaker. This manual provides essential information for setting up, operating, and maintaining your speaker to ensure optimal performance and longevity. Please read this manual thoroughly before use and retain it for future reference.

Figure 1: The ZEALOT ZE01 speaker is designed for portability, featuring a convenient shoulder strap for easy transport during outdoor activities.

2. Sikkerhedsoplysninger

• Udsæt ikke højttaleren for ekstreme temperaturer eller direkte sollys i længere perioder.
• Undgå at tabe eller udsætte højttaleren for kraftige stød.
• Keep the speaker away from water and liquids, despite its IPX6 rating, to prevent damage to internal components.
• Forsøg ikke selv at skille ad, reparere eller modificere højttaleren. Kontakt kvalificeret servicepersonale for at få hjælp.
• Use only the provided charging cable and a compatible power adapter (PD2.0 45W adapter recommended for optimal charging) to prevent damage.
• Opbevares utilgængeligt for børn.

3. Pakkens indhold

Bekræft at alle varer er til stede i pakken:

• 1x ZE01 Bluetooth Speaker
• 1x AUX -kabel
• 1x Power Cable (Type-C)
• 1x hurtigstartguide
• 1x Removable Shoulder Strap
• 1x garantikort

Figure 2: Included accessories with the ZEALOT ZE01 Portable Bluetooth Speaker.

4. Produktet er slutview

4.1 Styringer

Figure 3: Top panel controls for the ZEALOT ZE01 speaker.

• Tænd/sluk-knap (tænd/sluk): Tryk og hold i 3 sekunder for at tænde/slukke.
• Afspil/pause knap: Tryk én gang for at afspille eller sætte lyd på pause.
• Lydstyrke op (+): Press once to increase volume. Press and hold for 2 seconds for next track.
• Skrue ned for lyden (-): Press once to decrease volume. Press and hold for 2 seconds for previous track.
• Tilstandsknap (M): Press to switch between Wireless (Bluetooth), TF Card, AUX, and USB modes.
• EQ knap: Press to cycle through EQ modes (Bass, Vocal, Normal).
• Lys knap: Press to turn LED lights on/off or change light modes.
• Parringsknap: Press to initiate Bluetooth pairing or TWS pairing.

4.2 havne

Figure 4: Input and output ports on the ZEALOT ZE01 speaker.

• TYPE-C CHARGE IN: Til opladning af højttaleren.
• AUX IN: Til tilslutning af eksterne lydenheder via et 3.5 mm lydkabel.
• USB-DREV: Til afspilning af musik direkte fra et USB-flashdrev.
• TF -KORT: Til afspilning af musik direkte fra et TF-kort (MicroSD).
• OUT-5V (USB): Functions as a power bank to charge other devices.

5. Opsætning

5.1 Opladning af højttaleren

1. Connect the provided Type-C power cable to the 'TYPE-C CHARGE IN' port on the speaker.
2. Connect the other end of the cable to a compatible USB power adapter (not included). A PD2.0 45W adapter is recommended for optimal charging speed.
3. The battery indicator lights on the control panel will show charging status:
   • Red light flashes: Charging
   • Red light on: Battery below 30%
   • Yellow light on: Battery 40%-70%
   • Green light on: Battery 80%-100%
4. A full charge typically takes 3-4 hours. The speaker offers up to 40 hours of playtime at 30% volume in standard EQ mode.

Figure 5: Battery status indicators and charging port.

5.2 Bluetooth -parring

1. Power on the speaker by pressing and holding the Power button for 3 seconds. The speaker will enter Bluetooth pairing mode automatically, indicated by a flashing blue light.
2. Aktiver Bluetooth på din enhed (smartphone, tablet osv.) og søg efter tilgængelige enheder.
3. Select "ZEALOT-ZE01" from the list of devices.
4. Once connected, the blue light will stop flashing, and you will hear an audible confirmation.

5.3 Ægte trådløs stereo (TWS) parring

To achieve a 240W Max ultra stereo sound experience, you can pair two ZEALOT ZE01 speakers:

1. Ensure both ZEALOT ZE01 speakers are powered on and in Bluetooth pairing mode (not connected to any device).
2. On one of the speakers, press the 'Pairing' button (often indicated by a chain link icon). This speaker will become the primary unit.
3. The two speakers will automatically connect to each other. Once connected, the primary speaker's Bluetooth indicator will flash, and the secondary speaker's indicator will be solid.
4. Now, connect your device to the primary speaker via Bluetooth as described in Section 5.2.

Figure 6: TWS pairing allows for a wider stereo soundstage.

5.4 Other Connection Methods

The ZEALOT ZE01 supports multiple playback modes:

• AUX-indgang: Connect an external audio device using a 3.5mm AUX cable to the 'AUX IN' port. Press the 'M' button to switch to AUX mode.
• USB-drev: Insert a USB flash drive into the 'USB DRIVE' port. Press the 'M' button to switch to USB mode.
• TF-kort: Insert a TF (MicroSD) card into the 'TF CARD' slot. Press the 'M' button to switch to TF Card mode.

Figure 7: The speaker offers various connectivity options for versatile audio playback.

6. Betjeningsvejledning

6.1 Grundlæggende lydafspilning

• Afspil/pause: Tryk på knappen Afspil/pause.
• Lydstyrkejustering: Press '+' to increase volume, '-' to decrease volume.
• Næste / forrige nummer: Press and hold '+' for the next track, press and hold '-' for the previous track.

6.2 EQ-tilstande

The ZEALOT ZE01 features three Equalizer (EQ) modes to customize your audio experience:

1. Press the 'EQ' button to cycle through the modes.
2. Bastilstand: Green light on. Enhances low frequencies for a deeper bass sound.
3. Vokal tilstand: Orange light on. Optimizes mid-range frequencies for clearer vocals.
4. Normal tilstand: White light on. Provides a balanced audio profile.

Figure 8: EQ mode indicators.

6.3 LED-lysstyring

The speaker is equipped with dynamic colorful LED lights that can be controlled:

1. Press the 'Light' button (indicated by a sun/star icon) to turn the lights on/off or cycle through different light modes (e.g., Ritmo, Breathing, Rainbow).

Figure 9: Dynamic LED lights enhance the listening experience.

6.4 Powerbankens funktion

The ZEALOT ZE01 can also serve as a portable power bank:

1. Connect your external device (e.g., smartphone) to the 'OUT-5V' USB port on the speaker using a compatible charging cable.
2. The speaker will begin charging your device.

7. Vedligeholdelse

• Rensning: Brug en blød, tør klud til at rengøre højttalerens yderside. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• Opbevaring: Opbevar højttaleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer, når den ikke er i brug i længere perioder.
• Vandtæthed: The speaker has an IPX6 water resistance rating, meaning it can withstand powerful water jets. However, it is not designed for submersion. Ensure all port covers are securely closed before exposure to water.

Figure 10: The IPX6 rating provides protection against water splashes and dust.

8. Fejlfinding

9. Specifikationer

Figure 11: The internal speaker configuration for powerful audio.

10. Officiel produktvideo

Video 1: En officiel produktvideoasing the ZEALOT ZE01 120W Party Speaker's features and capabilities, including its sound quality and LED lights.

11. Garanti og support

The ZEALOT ZE01 Portable Bluetooth Speaker comes with a limited warranty. Please refer to the included Warranty Card for detailed terms and conditions. For technical support, troubleshooting assistance, or warranty claims, please contact ZEALOT customer service through the official channels provided on the warranty card or the ZEALOT webwebsted.
