Yeedi S20 Infinity robotstøvsuger og moppe brugermanual

1. Vigtige sikkerhedsinstruktioner

Please read this manual thoroughly before operating your Yeedi S20 Infinity Robot Vacuum and Mop. Keep this manual for future reference.

• Ensure the robot is used on stable, level surfaces.
• Hold løse kabler, gardiner og andre genstande, der kan vikle robotten ind i dens bane.
• Lad ikke børn eller kæledyr lege med robotten.
• Use only the original power adapter and charging station provided by Yeedi.
• The robot is compatible with 2.4GHz Wi-Fi networks only. 5GHz Wi-Fi is not supported.
• Avoid exposing the robot or station to water or moisture.

2. Produktet er slutview og komponenter

The Yeedi S20 Infinity is an advanced robot vacuum and mop designed for comprehensive floor cleaning. It features an intelligent robot unit and a multifunctional OmniCyclone Station.

Figure 2.1: Yeedi S20 Infinity Robot Vacuum and OmniCyclone Station. The image shows the circular robot unit next to its tall, rectangular self-emptying and cleaning station.

Inkluderede komponenter:

• Robotstøvsuger (1)
• OMNI Station (1)
• Power Cord (Black) (1)
• Brugervejledning (1)
• Hurtig vejledning (1)
• Ordinary New Roller Cloth Roller (1)
• Sidebørste (1)
• Main Brush & Main Brush Cover (1)
• Filter (1)
• Auxiliary Compartment Auto-Fill Module (1)
• Clean Water Tank (1)
• Dirty Water Tank (1)

Dimensioner:

• All-in-one Station: 15.0"L x 19.41"W x 18.31"H
• Robot: 13.9"L x 13.8"W x 3.9"H

3. Opsætningsvejledning

Follow these steps to set up your Yeedi S20 Infinity for the first time.

3.1 Udpakning og første placering

1. Pak alle komponenter forsigtigt ud.
2. Place the OmniCyclone Station against a wall on a level, hard ground. Ensure there is at least 0.64ft (20cm) of clear space on either side and 2.6ft (80cm) in front of it.
3. Sæt netledningen i stationen og en stikkontakt.
4. Remove all protective films and packaging from the robot.
5. Place the robot onto the station to begin charging.

Figure 3.1: The OmniCyclone Station positioned against a wall with the robot docked for charging. The image illustrates the recommended clear space around the station.

3.2 Appinstallation og -forbindelse

1. Download the 'Yeedi Home' app from your smartphone's app store.
2. Open the app and follow the on-screen instructions to add your Yeedi S20 Infinity.
3. You will need to scan the QR code located under the robot's top cover.
4. Sørg for, at din smartphone er forbundet til et 2.4 GHz Wi-Fi-netværk under opsætningsprocessen.

3.3 Indledende kortlægning

Once connected to the app, initiate an 'Auto Clean' cycle. The robot will begin exploring your home and creating a map, which will be visible in the app. This map is crucial for advanced features like zone cleaning and virtual boundaries.

4. Betjeningsvejledning

Your Yeedi S20 Infinity offers various cleaning modes and smart features for optimal performance.

4.1 Rengøringstilstande

• Kun støvsuger: Til tørt snavs på alle gulvtyper.
• Kun moppe: Til vådrengøring af hårde gulve.
• Støvsuger og mopper: Samtidig støvsugning og mopping for omfattende rengøring.

4.2 PowerBoost Charging

The S20 Infinity features PowerBoost charging, allowing the robot to quickly recharge during mop washing cycles. This ensures uninterrupted cleaning, especially for larger homes, by restoring 6% battery in just 3 minutes.

4.3 OZMO Roller 2.0 Mopping

The OZMO Roller 2.0 system provides real-time self-washing of the mop, ensuring a clean cloth touches every inch of your floor. Its extendable design allows for wider coverage and closer edge cleaning.

4.4 BLAST Suction

Experience deep cleaning with 19,500Pa suction and 38CFM airflow. This powerful suction effectively removes dirt and pet hair from carpets and hard floors. The ZeroTangle 3.0 technology on main and side brushes minimizes hair tangles.

4.5 AIVI 3D Navigation and TruEdge 3.0

AIVI 3D Navigation intelligently detects obstacles and maps your home for precise cleaning. TruEdge 3.0 ensures thorough edge cleaning, reaching close to walls and corners.

4.6 Smart Triple Lift System

The robot automatically lifts the mop on carpets, raises side brushes for large debris, and adjusts the main brush to prevent spills, providing seamless cleaning across different floor types.

4.7 App- og stemmestyring

Control your robot remotely via the Yeedi Home app. Schedule cleanings, set no-go zones, customize cleaning parameters, and manage maps. Voice commands are supported through Amazon Alexa and Google Assistant.

5. Vedligeholdelse

Regular maintenance ensures optimal performance and longevity of your Yeedi S20 Infinity.

5.1 OmniCyclone Station Maintenance

• Bagless Auto-Empty: The station automatically empties the robot's dustbin into its 1.6-liter bagless container. Empty the station's container as needed.
• Vask med varmt vandmoppe: The station washes the mop roller with 167°F hot water.
• Varmlufttørring: After washing, the mop is dried with 145°F hot air to prevent odors and mildew.
• Dual Solution Cleaning: The station supports dual cleaning solutions for different cleaning needs.

Figur 5.1: Detaljeret view of the OmniCyclone Station's bagless auto-emptying feature. The image shows the transparent dust collection bin within the station.

5.2 Rengøring af robotkomponenter

• Skraldespand: The robot's internal dustbin is automatically emptied by the station. Periodically check and clean if any residue remains.
• Rullemoppe: The mop roller is self-washed by the station. Ensure the station's clean and dirty water tanks are maintained.
• Main Brush and Side Brushes: Regularly check for tangled hair or debris. The ZeroTangle 3.0 technology minimizes tangles, but occasional manual cleaning may be required.
• Filter: Clean the robot's filter regularly by tapping out dust. Replace as recommended in the app.

6. Fejlfinding

If you encounter any issues with your Yeedi S20 Infinity, refer to the following common solutions:

• Robotten oplader ikke: Ensure the robot is correctly docked on the station and the station is powered on. Clean charging contacts on both the robot and station.
• Dårlig rengøringsevne: Check if the dustbin is full, brushes are tangled, or the filter is clogged. Clean or replace components as necessary.
• Problemer med app-forbindelse: Verify your Wi-Fi network is 2.4GHz. Restart your router, robot, and app.
• Robotten sidder fast: Clear any obstacles from the robot's path. Check for tangled cables or debris in the wheels.
• Mop not washing/drying: Ensure water tanks are correctly installed and filled (clean water) or emptied (dirty water). Check for blockages in the station's cleaning mechanism.

For further assistance, please contact Yeedi customer support.

7. Specifikationer

8. Garanti og support

Your Yeedi S20 Infinity Robot Vacuum and Mop comes with a manufacturer's warranty and dedicated customer support.

8.1 Garantioplysninger

Yeedi provides a 12-month worry-free warranty for the S20 Infinity. Please retain your proof of purchase for warranty claims.

8.2 Returns and Exchanges

A 30-day free return and exchange policy is available. Refer to your retailer's specific return policy for details.

8.3 Kundesupport

For any questions, troubleshooting, or warranty claims, please visit the official Yeedi website or contact their customer service team. They offer a rapid responding service team.
