FLEXISPOT BigX-OS4 Ergonomisk Kontorstol Brugermanual

1. Introduktion

This manual provides comprehensive instructions for the safe and efficient use of your FLEXISPOT BigX-OS4 Ergonomic Office Chair. Please read this manual thoroughly before assembly and operation, and retain it for future reference. The FLEXISPOT BigX-OS4 is designed for enhanced comfort and support, featuring a robust construction suitable for users up to 600 lbs.

Figure 1: FLEXISPOT BigX-OS4 Ergonomic Office Chair. This image displays the overall design of the black leather office chair, highlighting its padded backrest, seat, and armrests, along with the sturdy five-star base and blade rubber wheels.

2. Vigtige sikkerhedsoplysninger

WARNING: Do not exceed the maximum weight limit of 600 lbs. Prolonged sitting may cause discomfort. Always use the chair as intended and follow assembly instructions carefully.

• Sørg for, at alle komponenter er forsvarligt fastgjort før brug.
• Stå ikke på stolen.
• Undgå at placere tunge genstande på stolens ryglæn eller armlæn.
• Hold børn og kæledyr væk fra stolen under montering og justering.
• Brug på en plan overflade for at forhindre væltning.

3. Opsætning

The FLEXISPOT BigX-OS4 chair is designed for minimal assembly. No complex assembly is required. Simply unbox the chair and ensure all parts are present and undamaged. The chair is ready for immediate use after unboxing.

4. Betjeningsvejledning

4.1. Adjusting Lumbar Support

The chair features adjustable dynamic lumbar support. Locate the knob on the side of the chair (as shown in Figure 2). Rotate the knob to adjust the lumbar support to fit the natural curve of your spine, providing targeted relief and promoting proper posture.

Figure 2: Lumbar Support Adjustment. This image illustrates the adjustable lumbar support mechanism, showing how it can be rotated to customize the back support.

4.2. Højdejustering

To adjust the chair's height, locate the lever beneath the seat on the right side. Pull the lever upwards while seated to lower the chair, or stand up and pull the lever to raise it. Release the lever at your desired height.

4.3. Hældning og vippefunktion

The chair offers a tilt range of 90 to 130 degrees. To recline, pull the lever located on the left side of the seat outwards. Lean back to your desired angle and push the lever inwards to lock the position. To adjust the stiffness of the tilt, rotate the knob located underneath the seat. Turning it left makes it easier to recline, while turning it right increases resistance.

Figure 3: Chair Reclining Function. This image shows the chair in a reclined position, demonstrating its adjustable tilt feature for various comfort levels.

4.4. Justering af armlæn

The armrests are 2D flip-up adjustable. To raise or lower the armrests, press the button located on the side of each armrest and move them to your preferred height. This feature allows for easy entry and exit, and can accommodate various desk heights.

4.5. General Comfort Features

The BigX-OS4 features an extra-wide seat (24" x 20.1") and a thickened elastic seat cushion with high-resilience spring components for superior comfort during extended periods of sitting. The high back design provides comprehensive support for your entire back.

Figure 4: Comfortable Seating Design. This image highlights the wide seat and double-padded soft leather, emphasizing the chair's comfortable design for prolonged use.

Figure 5: Thickened Elastic Seat Cushion. A cutaway view of the seat cushion reveals premium foam wrapped around high-resilience spring components, designed to reduce pressure points.

5. Vedligeholdelse

5.1. Rensning

• For general cleaning, wipe the leather surfaces with a soft, damp klæde.
• Undgå at bruge skrappe kemikalier, slibende rengøringsmidler eller opløsningsmidler, da disse kan beskadige materialet.
• For stubborn stains, use a mild leather cleaner specifically designed for polyurethane or faux leather. Test on an inconspicuous area first.

5.2. Casters (Wheels)

The chair is equipped with heavy-duty blade rubber wheels designed for smooth and quiet movement. Periodically check the wheels for accumulated hair or debris and clean them to ensure optimal performance.

6. Fejlfinding

• Stol synker eller holder ikke højden: This may indicate an issue with the pneumatic lift cylinder. Ensure the height adjustment lever is fully engaged. If the problem persists, contact customer support.
• Stolen føles ustabil: Verify that all screws and bolts are tightened. Ensure the chair is on a flat, even surface. Avoid leaning excessively to one side, especially if you are near the weight limit.
• Difficulty Reclining or Adjusting Tilt: Check the tilt tension knob underneath the seat. Adjust it to a looser setting (turn left) if it feels too stiff. Ensure the recline lock lever is disengaged.
• Knirkende lyde: Apply a small amount of silicone-based lubricant to moving parts, such as the wheel axles or tilt mechanism.

7. Specifikationer

Figure 6: Product Dimensions Diagram. This diagram provides detailed measurements of the chair's width, depth, and adjustable height range.

Figure 7: Heavy Duty Capacity Illustration. This image visually represents the chair's 600 lbs weight capacity, emphasizing its robust construction.

8. Garanti og support

FLEXISPOT offers various protection plans for your product. For detailed information regarding warranty coverage and to purchase extended protection plans, please refer to the product's purchase page or contact FLEXISPOT customer support directly.

For any questions, technical assistance, or support needs, please visit the official FLEXISPOT webwebstedet eller kontakt deres kundeserviceafdeling. Kontaktoplysninger kan typisk findes på producentens webwebstedet eller din købsdokumentation.
