Indledning
This manual provides comprehensive instructions for the safe and effective use of your SoundPEATS H3 Hi-Res Wireless Bluetooth Headphones. Please read this manual thoroughly before using the product and retain it for future reference.
Image: SoundPEATS H3 Hi-Res Wireless Bluetooth Headphones, highlighting their elegant golden finish and ergonomic shape.
Hvad er der i æsken
- SOUNDPEATS H3 HIFI Wireless Earbuds
- USB-C ladekabel
- Brugermanual
- Beskyttende opladningsetui
- Eartip Replacements (5 sizes: XS, S, M, L, XL)
Image: The SoundPEATS H3 earbuds resting securely within their sleek charging case, ready for use.
Produkt overview
The SoundPEATS H3 headphones feature a sophisticated triple-driver hybrid system designed for high-fidelity audio reproduction.
Billede: En eksploderet view diagram of the SoundPEATS H3 earbuds, detailing the 12mm custom polymer diaphragm dynamic driver for bass/mid-bass and the Bellsing dual balanced armatures for mid-high/high frequencies.
Each earbud incorporates a 12mm dynamic driver for deep bass and dual balanced armatures for clear mid-high and high frequencies, ensuring a rich and detailed sound profile.
Image: A close-up of the Qualcomm QCC3091 chip, highlighting its role in enabling Hi-Res audio, Bluetooth 5.4, and aptX Lossless for superior wireless sound quality.
Opsætning
Iført øretelefoner
- Gently insert the earphone into your ear canal.
- Rotate the earphone to achieve a comfortable and secure fit.
Select the appropriate ear tip size from the five included options (XS, S, M, L, XL) to ensure optimal comfort, sound isolation, and stability.
Image: A visual guide demonstrating the correct two-step process for inserting and rotating the SoundPEATS H3 earbuds for a comfortable fit, alongside an array of ear tip sizes.
Parring
To pair your SoundPEATS H3 headphones with a device:
- Åbn opladningsetuiet med øretelefonerne indeni.
- Press and hold the pairing button on the case until the indicator light flashes.
- Enable Bluetooth on your device and select 'SOUNDPEATS H3' from the list of available devices.
Betjeningsvejledning
Tryk på kontrolelementer
The SoundPEATS H3 earbuds feature intuitive touch controls for managing playback, calls, and various modes. These controls can be customized via the PeatsAudio App.
| Handling | Venstre øretelefon | Højre ørepropper |
|---|---|---|
| Enkelt tryk | Lydstyrke ned | Lydstyrke op |
| Dobbelttryk | Afspil/pause | Afspil/pause |
| Tredobbelt tryk | Spiltilstand | Stemmeassistent |
| Langt tryk (1.5 sek.) | Noise Cancelling Mode Cycle | Næste spor |
Aktiv støjreduktion (ANC) og transparenstilstand
The SoundPEATS H3 offers adaptive hybrid ANC up to 55dB, effectively blocking out ambient noise. You can switch between Noise Cancelling, Normal, and Transparency modes. The PeatsAudio App allows for fine-tuning of ANC strength and selection of specific modes (Indoor, Outdoor, Transport, Adaptive).
Image: A visual representation of the SoundPEATS H3's 55dB maximum noise cancellation capability, effectively eliminating train and engine rumbling sounds in a subway setting.
6-mikrofon AI klare opkald
Equipped with a 6-microphone system and Qualcomm CVC 8.0 technology, the H3 ensures crystal-clear calls by enhancing vocal clarity and filtering out wind and ambient noise.
Image: An illustration highlighting the 6 high-sensitivity microphones and Qualcomm CVC V8.0 algorithm within the SoundPEATS H3, designed to capture voice precisely and block noise for clear calls.
Spiltilstand / Lav latenstid
Activate Gaming Mode via the touch controls or the PeatsAudio App for reduced audio latency, providing a more synchronized audio-visual experience during gaming.
Video: An official SoundPEATS video demonstrating the Gamesky feature for H3 wireless earbuds, highlighting its low-latency capabilities for an enhanced gaming experience.
Tilslutning med flere punkter
The SoundPEATS H3 supports multi-point connection, allowing you to connect to two devices simultaneously. To switch audio playback, simply pause on one device and play on the other. Note that LDAC codec cannot be used simultaneously with multi-point connection.
Opladning
Opladning af øretelefoner og etui
To charge the earbuds, place them back into the charging case. To charge the case, connect a Type-C charging adapter (with a current ≤1A) to the charging port.
Video: An official SoundPEATS video demonstrating how to charge the H3 earbuds and their charging case using a Type-C cable.
Batterilevetid
The earbuds provide up to 7 hours of playtime on a single charge (ANC off), with a total of 37 hours using the charging case. With ANC on, playtime is approximately 4 hours per charge and 21 hours total with the case. A quick 10-minute charge can provide 2 hours of playtime.
Image: A detailed table outlining the battery life of SoundPEATS H3 earbuds under various bit rates (SBC, AAC, aptX adaptive, aptX lossless, LDAC) for both Normal Mode (ANC off) and ANC Mode, indicating up to 7 hours on a single charge and 37 hours total with the charging case.
Batteriindikatorer
- Opladningsetui:
- 100%-50%: Grønt lys
- 49%-10%: Gult lys
- Under 10 %: Rødt lys
- Charging Status Indicator (Case):
- Below 20%: Red light (slow breathing)
- 20%-69%: Yellow light (slow breathing)
- 70%-99%: Green light (slow breathing)
- 100%: Green light (steady on)
Opretholdelse
Rengøring og opbevaring
- Regularly clean the earbuds and charging contacts with a soft, dry cloth.
- Opbevar hovedtelefonerne i deres opladningsetuiet, når de ikke er i brug, for at beskytte dem mod støv og skader.
- If unused for extended periods, charge the device at least once every three months to maintain battery health.
Vandmodstand
The SoundPEATS H3 earbuds are rated IPX5 water resistant, meaning they are protected against low-pressure water jets from any direction. This makes them suitable for workouts and light rain, but they are not designed for swimming or submersion in water.
Image: A visual demonstration of the SoundPEATS H3 earbuds' IPX5 rating, showing a user jogging comfortably in light rain, indicating resistance to sweat and splashes.
Fejlfinding
- Ingen lyd/dårlig lydkvalitet: Ensure earbuds are properly seated in your ears and connected to your device. Check the ear tip size for a secure seal. Verify the volume levels on both the earbuds and your device.
- Forbindelsesproblemer: Ensure Bluetooth is enabled on your device and the earbuds are within range. Try resetting the earbuds by placing them in the case, closing it, and then reopening to re-pair.
- Opladningsproblemer: Check the charging cable and adapter for damage. Ensure the charging contacts on both the earbuds and case are clean and dry.
- ANC fungerer ikke effektivt: Ensure the earbuds are properly sealed in your ear canals. Adjust ANC modes via the PeatsAudio App to suit your environment.
Specifikationer
| Feature | Detalje |
|---|---|
| Modelnavn | SOUNDPEATS H3 |
| Støjkontrol | Adaptiv støjreduktion, støjreduktion fra omgivelserne, hybrid støjreduktion |
| Forbindelsesteknologi | Trådløs (Bluetooth 5.4) |
| Audio driver type | Hybrid Driver (12mm Dynamic + Dual Balanced Armatures) |
| Frekvensrespons | 40 KHz |
| Batterilevetid | Op til 37 timer (med opladningsetui) |
| Opladningstid | 1 time (øretelefoner) |
| Vandmodstandsniveau | IPX5 (vandtæt) |
| Kontroltype | Touch Control, App Control |
| Særlige funktioner | Fast Charging, Multipoint Pairing, Noise Cancellation, Sweatproof, Touch Control |
| Varens vægt | 53 gram (i alt) |
| Produktdimensioner | 2.79 x 1.22 x 1.89 tommer |
| Materiale | ABS+PC |
Garanti og support
The SoundPEATS H3 comes with a comprehensive one-year warranty, ensuring peace of mind with your purchase. If you encounter any issues or have questions, our responsive customer service team is ready to assist you at any time. We are committed to providing timely solutions and support to guarantee your satisfaction and a seamless listening experience.
For further assistance, please visit the official SoundPEATS webwebstedet eller kontakt deres kundesupport direkte.
