1. Vigtige sikkerhedsoplysninger
Please read and understand all safety instructions before operating the Anker SOLIX C1000 Portable Power Station. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Enheden må ikke skilles ad, repareres eller modificeres.
- Keep the unit away from heat sources, direct sunlight, humidity, and water.
- Brug kun originale eller certificerede kabler og tilbehør.
- Sørg for korrekt ventilation under brug for at forhindre overophedning.
- Opbevar enheden på et køligt, tørt sted.
- Opbevares utilgængeligt for børn og kæledyr.
- Brug ikke i eksplosive atmosfærer, såsom i nærheden af brændbare væsker, gasser eller støv.
2. Produktet er slutview
The Anker SOLIX C1000 is a portable power station designed to provide reliable power for various applications, from home backup to outdoor adventures. It features a 1056Wh LiFePO4 battery and an 1800W AC output (up to 2400W with SurgePad technology).
Figure 2.1: Anker SOLIX C1000 Portable Power Station and included water-resistant bag.
2.1 Pakkens indhold
- Anker SOLIX C1000 bærbar kraftstation
- Water Resistant Bag
- Brugervejledning (dette dokument)
- AC-opladerkabel
- Bil ladekabel
- Solar Charging Cable (MC4 to XT-60)
3. Opsætning og opladning
3.1 Indledende opladning
Before first use, it is recommended to fully charge the Anker SOLIX C1000. The unit supports UltraFast recharging, achieving 80% capacity in approximately 43 minutes and a full charge in under an hour via AC input when enabled through the Anker app.
Figure 3.1: The Anker SOLIX C1000 connected to an AC power supply for UltraFast recharging.
3.2 Solopladning
The Anker SOLIX C1000 can be recharged using solar panels, supporting up to 600W fast solar recharging. A full charge can be achieved in approximately 1.8 hours under optimal sunlight conditions.
Figure 3.2: The Anker SOLIX C1000 being recharged by solar panels in an outdoor setting.
4. Betjeningsvejledning
4.1 Strømforsyning til enheder
The Anker SOLIX C1000 provides 11 versatile ports, including AC outlets, USB-A, and USB-C, to power a wide range of appliances. With SurgePad technology, it can deliver up to 2400W output, enabling it to power 99% of common appliances.
Figure 4.1: The Anker SOLIX C1000 providing power to a coffee maker, blender, and other devices on a table outdoors.
4.2 Using the Anker App
Control and monitor your Anker SOLIX C1000 remotely using the dedicated Anker app. The app allows you to customize AC charging speed, get low power alerts, check power status, and connect via Bluetooth or Wi-Fi.
Figure 4.2: A smartphone displaying the Anker app, showing battery level, input/output wattage, and settings for the SOLIX C1000.
4.3 Funktionen af en uafbrydelig strømforsyning (UPS)
The Anker SOLIX C1000 features a seamless UPS transfer function with less than 20ms switchover time. This ensures that connected devices continue to receive power without interruption during a power outage.
Figure 4.3: The Anker SOLIX C1000 connected to a desktop computer setup, illustrating its UPS capability during a power interruption.
4.4 Water-Resistant Bag Usage
The included water-resistant bag provides protection against rain and elevates the power station to keep it off soaked terrain. It features a velcro design for easy access to multiple outlets, allowing charging and recharging without removing the cover.
Figure 4.4: Demonstrating how to access the charging port of the Anker SOLIX C1000 while it is protected by its water-resistant bag.
5. Vedligeholdelse og levetid
The Anker SOLIX C1000 is built with LiFePO4 batteries, offering exceptional longevity with 3,000 battery cycles over a 10-year lifespan under normal operating conditions. This technology, referred to as InfiniPower, ensures long-term reliability.
Figure 5.1: An illustration of Anker's InfiniPower technology, highlighting EV-class LiFePO4 batteries, unibody drop-proof design, smart temperature control, and industrial-grade electronic components, contributing to a 10-year lifespan.
5.1 Opbevaring
- Store the power station in a cool, dry environment, away from direct sunlight and extreme temperatures.
- Ved langtidsopbevaring skal enheden oplades til cirka 50-60% hver 3.-6. måned for at opretholde batteriets sundhedstilstand.
- Ensure the unit is turned off when not in use.
5.2 Rengøring
- Use a dry, soft cloth to clean the exterior of the unit.
- Brug ikke slibende rengøringsmidler eller opløsningsmidler.
- Keep vents clear of dust and debris.
6. Fejlfinding
If you encounter issues with your Anker SOLIX C1000, please refer to the following common troubleshooting steps:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Enheden tænder ikke | Battery depleted; Power button not pressed correctly. | Oplad enheden; Tryk på tænd/sluk-knappen og hold den nede i 3 sekunder. |
| No output from AC/DC ports | Output ports not activated; Overload protection triggered. | Ensure AC/DC output buttons are pressed; Reduce load, then restart the unit. |
| Langsom opladningshastighed | UltraFast charging not enabled; Environmental temperature too high/low. | Enable UltraFast charging in the Anker app; Charge within recommended temperature range (0°C-40°C). |
| Problemer med appforbindelse | Bluetooth/Wi-Fi off; Unit too far from device. | Ensure Bluetooth/Wi-Fi is enabled on both devices; Move closer to the unit. |
If the problem persists, please contact Anker customer support for further assistance.
7. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Anker SOLIX |
| Modelnavn | Anker SOLIX C1000 |
| Modelnummer | A1761 |
| UPC | 194644246778 |
| Strømkilde | Battery Powered (LiFePO4) |
| Batterikapacitet | 1056Wh |
| AC Output Wattage | 1800W (Rated), 2400W (SurgePad) |
| Produktdimensioner | 14.8 cm L x 8.7 cm B x 10.5 cm H |
| Varens vægt | 31.1 pund |
| Farve | Mørkegrå |
| Battericykler | 3,000 cyklusser (til 80% kapacitet) |
| Levetid | 10 years (under normal operating conditions) |
| Særlige funktioner | Portable, UltraFast Recharging, SurgePad Technology, UPS Function, Smart App Control, IP54 Water-Resistant Bag |
8. Garanti og support
The Anker SOLIX C1000 Portable Power Station comes with a 5-year warranty, reflecting its durable design and long-lasting LiFePO4 battery technology, which is rated for 3,000 charge cycles over a 10-year lifespan.
For warranty claims, technical support, or additional product information, please visit the official Anker SOLIX website or contact their customer service directly. Details regarding extended protection plans may also be available from your retailer.
Fabrikant: Anker
Mærke: Anker SOLIX
Webwebsted: www.anker.com/solix (Eksamplinket, det faktiske link kan variere)
