Lionelo Ellen 3-i-1 rejseseng og co-sleeper brugsanvisning

1. Introduktion

This instruction manual provides essential information for the safe assembly, operation, and maintenance of your Lionelo Ellen 3-in-1 Travel Cot. Please read all instructions carefully before use and retain this manual for future reference.

The Lionelo Ellen 3-in-1 functions as a co-sleeper, a standard baby cot, and a portable travel cot, designed for children from birth up to 36 months (maximum 15 kg).

1.1. Sikkerhedsadvarsler

• Always ensure all locking mechanisms are engaged before placing a child in the cot.
• Do not use the cot if any parts are broken, torn, or missing.
• Brug ikke mere end én madras i barnesengen.
• The cot is suitable for children from birth up to 15 kg.
• When used as a co-sleeper, ensure the cot is securely attached to the adult bed using the provided straps, and there is no gap between the cot and the bed.
• Never leave a child unattended in the cot.
• Hold små dele væk fra børn for at undgå kvælningsfare.

2. Produktkomponenter

Before assembly, verify that all components are present and undamaged. The package includes:

• Ramme til rejseseng
• Mattress (Polyurethane foam T25, 2 cm thick)
• Transporttaske
• Attachment Straps (for co-sleeper function)
• Wheels with Brakes (2 units)

3. Monteringsvejledning

3.1. Unfolding the Cot

1. Remove the cot from the transport bag.
2. Stand the cot upright and pull the short sides upwards until they lock into place.
3. Push down the center of the cot base until it lies flat and locks.
4. Ensure all four corners are fully extended and locked.

3.2. Installing the Mattress

Place the provided mattress inside the cot. The cot offers two mattress height levels:

• Øvre niveau: For newborns up to 9 kg. This level reduces bending for parents during care.
• Lower Level: For older children up to 15 kg. This provides a deeper, safer space for active toddlers.

To adjust the mattress height, follow the specific instructions for your model to reposition the mattress support base.

4. Betjeningsvejledning

4.1. Co-Sleeper Function

The Lionelo Ellen cot can be used as a co-sleeper, allowing your child to sleep safely next to the parent's bed. To activate this function:

1. Lower one side of the cot by disengaging the side locking mechanism.
2. Position the cot next to the adult bed, ensuring there is no gap between the cot and the bed.
3. Securely attach the cot to the adult bed using the provided attachment straps. Follow the strap instructions carefully to ensure a tight and safe connection.

4.2. Side Entry

For older children, the cot features a zippered side entry, allowing them to independently enter and exit the cot. Ensure the zipper is fully closed when the child is sleeping or unattended.

4.3. Mobilitet

The cot is equipped with two wheels with brakes for easy movement. To move the cot, release the brakes. To secure the cot in place, engage the brakes on both wheels.

5. Vedligeholdelse og pleje

5.1. Rensning

• Stof: The main fabric (Polyester Oxford 300D) can be cleaned with a damp klud og mild sæbe. Brug ikke skrappe rengøringsmidler eller slibende rengøringsmidler.
• Madrasbetræk: The quilted cotton mattress cover is removable and washable. Follow the care label instructions for washing.
• Ramme: Wipe the steel frame and plastic elements with a damp klæde.

5.2. Opbevaring

When not in use, fold the cot compactly and store it in the provided transport bag in a dry place, away from direct sunlight and extreme temperatures.

6. Fejlfinding

• Cot does not lock into place during assembly: Ensure the short sides are pulled up completely before pushing down the center base. Sometimes, the side rails need to be fully extended and locked first.
• Wheels are not moving freely: Check if the brakes are engaged. Clean any debris from the wheel mechanisms.
• Cot feels unstable: Verify that all locking mechanisms on the frame and sides are fully engaged. Do not use if any part is damaged.

7. Specifikationer

8. Garanti og support

For warranty information, product registration, or technical support, please refer to the official Lionelo webwebstedet eller kontakt deres kundeserviceafdeling. Gem din købsbevis til eventuelle garantikrav.

Fabrikant: Lionelo
