Indledning
The Magnasonic UC22 Ultrasonic Cleaner utilizes high-frequency ultrasonic waves (40,000Hz) to generate millions of microscopic bubbles. This cavitation process gently yet powerfully dislodges dirt, grease, and grime from various items, restoring their brilliance. Designed for both home and commercial use, it offers a comprehensive cleaning solution for delicate and durable items alike.
Vigtige sikkerhedsoplysninger
- Do not operate the cleaner without at least 250ml (1 cup) of liquid inside the tank. Damage to the unit could occur.
- Always ensure the unit is unplugged when not in use or when filling/emptying the tank.
- Opbevares utilgængeligt for børn.
- Nedsænk ikke hovedenheden i vand.
- Avoid cleaning items with loose stones, soft/porous stones, or costume jewelry.
- Not to be used on glasses/sunglasses with pre-existing scratches or cracks in the coating.
Pakkens indhold
- Magnasonic UC22 Ultrasonic Cleaner Unit
- 8oz Gem & Jewelry Cleaner Concentrate Solution
- Rengøringskurv
- Urholder
- Instruktionsmanual
Image: The Magnasonic UC22 Ultrasonic Cleaner, showing its tank filled with water and various items being cleaned, along with the included cleaning solution.
Opsætning og første brug
- Place the ultrasonic cleaner on a stable, flat surface near a power outlet.
- Open the lid and place the cleaning basket inside the stainless steel tank.
- Fill the tank with water, ensuring the water level is above the minimum fill line (at least 250ml) and below the maximum fill line. For enhanced cleaning, add a few drops of the included Gem & Jewelry Cleaner Concentrate Solution.
- Carefully place the items to be cleaned into the basket. Ensure items are fully submerged and do not overcrowd the tank. For watches, use the provided watch holder.
- Luk låget.
Image: A user placing a ring into the ultrasonic cleaner's basket, highlighting the 40 kHz ultrasonic frequency, 5 cleaning modes, basket/watch holder, and large 20 oz stainless steel tank.
Betjeningsvejledning
- Plug the unit into a power outlet. The digital display will illuminate.
- Select a cleaning cycle by pressing the "SET" button. The cleaner features 5 preset cleaning cycles: 90, 180, 280, 380, and 480 seconds. Choose the appropriate cycle based on the item and level of dirt.
- Press the "ON" button to start the cleaning process. The unit will emit a soft hum, indicating the ultrasonic waves are active.
- Når cyklussen er færdig, slukker enheden automatisk.
- Open the lid and carefully remove the basket with the cleaned items.
- Rinse the cleaned items under clean water and dry them with a soft cloth.
Image: A visual guide demonstrating the four simple steps to operate the ultrasonic cleaner, from filling with water to achieving sparkling results.
Recommended Cleaning Times:
- Jewelry (Rings, Necklaces, Earrings): 180-280 seconds. For heavily soiled items, multiple cycles may be necessary.
- Eyeglasses/Sunglasses: 90-180 seconds. Ensure lenses do not have pre-existing damage.
- Retainers/Dentures/Aligners: 180-280 sekunder.
- Watches (Water-resistant only): Use the watch holder, 90-180 seconds.
- Small Tools/Razors/Makeup Brushes: 280-480 sekunder.
Image: An illustration of the diverse range of items suitable for cleaning with the ultrasonic cleaner, such as glasses, retainers, watches, and jewelry.
Understanding Ultrasonic Cleaning:
The Magnasonic UC22 operates at 40 kHz, which is the optimal frequency for deep cleaning without causing damage to most items. Lower frequencies (e.g., 30 kHz) can be too aggressive, while higher frequencies (e.g., 60 kHz) may be less effective.
Image: A visual explanation of why 40 kHz is the ideal ultrasonic frequency for effective and safe cleaning, contrasting it with lower and higher frequencies.
Vedligeholdelse og pleje
- After each use, empty the water from the tank and wipe the interior with a soft, dry cloth.
- Do not use abrasive cleaners or harsh chemicals on the unit.
- Opbevar rengøringsmidlet på et køligt, tørt sted, når det ikke er i brug.
- The SUS 304 stainless steel tank is designed for durability and resistance to corrosion.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Enheden tænder ikke | Ikke tilsluttet; problem med stikkontakten | Sørg for, at netledningen er sat ordentligt i en fungerende stikkontakt. |
| Cleaning results are unsatisfactory | Insufficient cleaning time; Tank not filled correctly; Items too dirty | Run a longer cycle or multiple cycles. Ensure water level is correct. Add cleaning solution for stubborn dirt. |
| Unit makes no sound | Unit not operating; Malfunction | Ensure a cleaning cycle is selected and the "ON" button is pressed. If still no sound, contact customer support. |
Produktspecifikationer
- Modelnummer: UC22-CLEANER-KIT
- Tank kapacitet: 20 oz (600 ml)
- Ultralydsfrekvens: 40,000 Hz
- Tank materiale: SUS 304 rustfrit stål
- Cleaning Cycles: 5 preset (90, 180, 280, 380, 480 seconds)
- Produktdimensioner: 4.9 x 7.5 x 4 tommer
- Varens vægt: 1.54 pund
- Fabrikant: Magnasonic
- Oprindelsesland: Kina
Image: A comparison chart highlighting the superior features of the Magnasonic cleaner, including its larger tank capacity and optimal ultrasonic frequency, compared to other models.
Image: A visual comparison illustrating the generous 20 oz tank capacity of the Magnasonic cleaner, allowing for larger items like brushes and glasses to be cleaned easily.
Officielle produktvideoer
Video: A demonstration of the Magnasonic Ultrasonic Cleaner in action, showing how to place items like rings into the basket, add water, select a cleaning cycle, and observe the cleaning process. The video concludes by showing the sparkling results after cleaning.
Før og efter resultater
Image: A visual representation of the cleaning effectiveness, displaying a diamond ring before and after being cleaned with the Magnasonic Ultrasonic Cleaner, highlighting the restored brilliance.
Garanti og support
Magnasonic offers North American support for this product. For warranty information or technical assistance, please refer to the contact details provided on the official Magnasonic webwebstedet eller produktemballagen.
