7RYMS WA2 Stemme AmpBrugermanual til mikrofon med trådløs lavaliermikrofon

Indledning

This manual provides detailed instructions for the proper use and maintenance of your 7RYMS WA2 Voice Amplifier with Wireless Lavalier Microphone. Please read this manual thoroughly before operating the device to ensure optimal performance and longevity.

Produkt overview

The 7RYMS WA2 is a portable voice amplifier system designed for clear and effective vocal projection. It features a wireless lavalier microphone for hands-free operation and advanced noise-canceling technology.

Figur 1: The 7RYMS WA2 system, including the portable voice amplifier and the compact wireless lavalier microphone.

Nøglefunktioner:

• Trådløs transmission: Utilizes 2.4G automatic frequency modulation for stable connection up to 164 feet (50 meters).
• High-Volume Speaker: Equipped with a 65mm rare earth internal magnetic speaker for balanced, high-fidelity sound.


Figur 2: En detaljeret view of the 65mm speaker, emphasizing its high volume capability and 50-meter coverage area.

• DSP AI Denoise Chip: Integrates advanced AI denoise technology to reduce background noise and prevent howling.

Figur 3: En intern view highlighting the DSP AI Intelligent Denoise Chip for real-time noise reduction and howling prevention.
• Wireless Accompaniment & AUX Input: Supports external audio input for versatile applications.
• LED Digital Screen: High-efficiency display for clear status updates.
• Brugervenlig kontrol: Features one-click muting and 10-level volume adjustment.
• Forlænget batterilevetid: Amplifier offers up to 23 hours, and the lavalier microphone up to 7 hours of continuous use.


Figur 4: Battery performance: up to 23 hours for the amplifier (2000mAh) and 7 hours for the lavalier microphone (97mAh).

• High-Sensitivity Microphone: 9.7mm large-size condenser mic capsule for clear sound pickup.

Figur 5: The 7RYMS WA2 amplifier is suitable for various applications including teaching, tour guiding, public speaking, and shopping assistance.

Pakkens indhold

Bekræft, at alle nedenstående varer er inkluderet i din pakke:

• Wireless Headset (TX) x 1
• Amplifier (RX) x 1
• Rem x 1
• Ladekabel x 1
• Brugervejledning x 1

Opsætningsvejledning

1. Opladning af enhederne

Before first use, fully charge both the amplifier and the wireless lavalier microphone.

• Tilslut ladekablet til opladningsporten på amplifier (RX) and a suitable USB power adapter.
• Connect the charging cable to the charging port on the wireless headset (TX) and a suitable USB power adapter.
• The LED indicator will show charging status and turn off or change color when fully charged.

2. Tænd/sluk

• AmpLikator (RX): Press and hold the power button until the LED screen illuminates.
• Trådløst headset (TX): Tryk og hold tænd/sluk-knappen nede, indtil indikatorlyset tændes.
• To power off, press and hold the power button on each device until the indicators turn off.

3. Automatisk parring

De amplifier and wireless headset are pre-paired at the factory. If re-pairing is needed:

• Ensure both devices are powered on and within close proximity.
• The devices should automatically connect. A successful connection is indicated by a stable light on the headset and a specific icon on the amplifier's LED screen.

Betjeningsvejledning

1. Sådan bærer du mikrofonen

The wireless lavalier microphone can be worn using its integrated clip or magnetic attachment.

Figur 6: The 9.7mm large-size condenser microphone can be attached magnetically or clipped onto clothing for hands-free use. It weighs approximately 7 grams.

For optimal sound pickup, aim the microphone capsule towards the sound source.

2. Lydstyrkejustering

Juster amplifier's volume using the dedicated volume wheel or buttons. The LED screen will display the current volume level.

Figur 7: De amplifier features a stepless volume adjustment wheel, a one-click muting function, and a high-efficiency LED digital screen displaying battery percentage og andre statusindikatorer.

3. Muting-funktion

Press the mute button on the wireless headset (TX) to temporarily mute the microphone. Press it again to unmute.

4. Using AUX Audio Input

De amplifier supports external audio input via the AUX port. This allows connection to devices like mobile phones, tablets, or computers for playing background music or other audio.

Figur 8: The 7RYMS WA2 amplifier supports wireless accompaniment and AUX audio input, making it compatible with various devices such as mobile phones, tablets, and computers. A 3.5mm output is required for AUX connection.

5. Wireless Accompaniment

The device supports wireless accompaniment, allowing you to play audio wirelessly from a compatible source while using the microphone.

Opretholdelse

• Clean the device with a soft, dry cloth. Do not use liquid cleaners or solvents.
• Opbevar amplifier and microphone in a cool, dry place away from direct sunlight and extreme temperatures.
• Avoid dropping, colliding, or pounding the device, as it is a high-precision instrument.

Fejlfinding

1. Howling Sound

If you experience a howling sound:

• Do not place the wireless headset next to the ampvarmebeholder, når den er i brug.
• Sørg for amplifier's external mic port is only used with cardioid mics specifically designed for amplifiers. Common lavalier mics may cause howling.
• Reduce the volume if the howling persists.

2. Microphone Not Connecting

If the wireless headset does not connect:

• Sørg for både amplifier and the headset are fully charged and powered on.
• Verify that the headset has not automatically turned off after 30 minutes of inactivity if not connected. Power it on again.
• Ensure devices are within the 164ft (50m) operating range.

3. Dårlig lydkvalitet

• Ensure the microphone capsule is aimed directly at the sound source.
• Check for any obstructions between the microphone and the amplivligere.
• Avoid using the device near sources of heat or interference (e.g., radiators, ovens, refrigerators, air conditioners).

Specifikationer

Important Notices and Safety Information

• Always aim the microphone capsule at the sound source for optimal recording.
• The wireless headset will automatically power off if not connected within 30 minutes.
• Avoid placing the headset next to the amplifier during use to prevent howling.
• De amplifier's external microphone port is designed for cardioid microphones specifically used with amplifiers. Using common lavalier microphones may cause howling.
• This product is a high-precision device; protect it from falls, collisions, or impacts.
• Do not use this device near heat sources or sources of interference, such as radiators, ovens, refrigerators, or air conditioners.

Garanti og support

For warranty information, technical support, or service inquiries, please refer to the warranty card included with your product or visit the official 7RYMS webwebstedet. Behold din købskvittering som købsbevis.
