Audeze 207-MW-1117-01

Audeze Maxwell Wireless Gaming Headset (Flora Limited Edition)< /h1>
User Instruction Manual< /p>< /header>
Introduction< /a>< /li>
Setup< /a>< /li>
Operating Instructions< /a>< /li>
Maintenance< /a>< /li>
Troubleshooting< /a>< /li>
Specifications< /a>< /li>
Warranty & Support< /a>< /li>< /ul>< /nav>
1. Introduction< /h2>
Welcome to the Audeze Maxwell Wireless Gaming Headset (Flora Limited Edition) user manual. This headset is designed to provide an immersive audio experience for gaming across multiple platforms including Xbox, PlayStation, Mac, PC, and Switch. Featuring Audeze's renowned 90mm Planar Drivers and advanced A.I. noise filtering technology, the Maxwell delivers exceptional sound quality and clear communication. This limited Flora Edition boasts a unique floral design on the earpads and headband.< /p>
Please read this manual carefully to ensure proper setup, operation, and maintenance of your new headset.< /p>

Figure 1: Audeze Maxwell Flora Limited Edition Headset, showing the floral pattern on the earcups and headband, with the detachable boom microphone connected.< /p>< /div>< /section>
2. Setup< /h2>
2.1 Charging the Headset< /h3>
Before first use, fully charge your Audeze Maxwell headset. The headset provides over 80 hours of battery life on a full charge, and a 20-minute charge can provide a full day of gaming.< /p>
Connect the provided USB-C charging cable to the headset's USB-C port.< /li>
Connect the other end of the cable to a compatible USB power source (e.g., computer USB port, wall adapter).< /li>
The LED indicator on the headset will show charging status. Refer to the LED indicator section for details.< /li>< /ul>
2.2 Connecting to Devices< /h3>
The Audeze Maxwell headset offers multiple connectivity options: wireless (via USB-C dongle), Bluetooth, and wired (via USB-C cable).< /p>
2.2.1 Wireless Connection (USB-C Dongle)< /h4>
For low-latency wireless gameplay on Xbox, PlayStation, Mac, PC, and Switch, use the included USB-C wireless dongle.< /p>
Insert the USB-C wireless dongle into an available USB-C port on your gaming console or computer.< /li>
Power on your Audeze Maxwell headset by pressing and holding the Power button until the LED illuminates.< /li>
The headset and dongle should automatically pair. The LED on both devices will indicate a successful connection (e.g., solid blue).< /li>
Ensure the headset is selected as the audio output and input device in your system settings.< /li>< /ul>

Figure 2: Right earcup controls, including the power button and microphone port.< /p>< /div>
2.2.2 Bluetooth Connection< /h4>
Connect your headset to Bluetooth-enabled devices like smartphones, tablets, or computers.< /p>
With the headset powered on, press and hold the Bluetooth button (usually located near the power button) until the LED flashes rapidly, indicating pairing mode.< /li>
On your device, go to Bluetooth settings and select "Audeze Maxwell" from the list of available devices.< /li>
Once connected, the LED on the headset will change to a solid blue or green, depending on the model.< /li>< /ul>
2.2.3 Wired Connection (USB-C)< /h4>
For a direct wired connection, use the provided USB-C to USB-C or USB-C to USB-A cable.< /p>
Connect one end of the USB-C cable to the headset's USB-C port.< /li>
Connect the other end to a compatible USB port on your device.< /li>
The headset will function as a wired audio device.< /li>< /ul>< /section>
3. Operating Instructions< /h2>
3.1 kontroller overview< /h3>
The Audeze Maxwell headset features intuitive controls for managing audio, microphone, and power.< /p>
Power Button:< /b> Press and hold to power on/off. Short press for battery status.< /li>
Volume Wheel:< /b> Adjusts overall audio volume.< /li>
Microphone Mute Button:< /b> Toggles microphone mute.< /li>
Game/Chat Balance Wheel (Xbox version only):< /b> Adjusts the balance between game audio and chat audio.< /li>
Multi-function Button:< /b> Varies by context (e.g., play/pause, answer call).< /li>< /ul>

Figure 3: Left earcup with microphone attached, illustrating the overall design.< /p>< /div>
3.2 Microphone Usage< /h3>
The detachable boom microphone utilizes A.I. noise filtering technology to reduce background noise.< /p>
Insert the boom microphone into the dedicated port on the left earcup.< /li>
Position the microphone approximately 1-2 inches from your mouth for optimal clarity.< /li>
Use the microphone mute button to quickly mute or unmute your voice.< /li>< /ul>
3.3 Audeze HQ App< /h3>
Download the free Audeze HQ app for advanced customization of your headset.< /p>
Equalizer (EQ) Settings:< /b> Create and save custom EQ profiles to tailor the sound to your preference.< /li>
Firmware Updates:< /b> Keep your headset's firmware up-to-date for optimal performance and new features.< /li>
Sidetone Control:< /b> Adjust the level of your own voice heard through the headset.< /li>
Other Features:< /b> Access additional settings and diagnostics.< /li>< /ul>
The Audeze HQ app is available for PC and Mac. Visit the official Audeze website for download links.< /p>< /section>
4. Maintenance< /h2>
Proper care will extend the life and performance of your Audeze Maxwell headset.< /p>
Cleaning:< /b> Use a soft, dry cloth to wipe down the earcups and headband. For stubborn dirt, a slightly damp cloth can be used, but ensure no moisture enters the internal components.< /li>
Storage:< /b> Store the headset in a cool, dry place away from direct sunlight and extreme temperatures. Use the included carrying pouch or a dedicated headset stand to protect it when not in use.< /li>
Avoid Liquids:< /b> Do not expose the headset to water or other liquids.< /li>
Cable Care:< /b> Handle cables gently. Avoid sharp bends or excessive pulling.< /li>< /ul>

Figur 4: Forside view of the headset, showcasing the unique Flora design.< /p>< /div>< /section>
5. Troubleshooting< /h2>
If you encounter issues with your Audeze Maxwell headset, try the following solutions:< /p>
5.1 No Sound / Low Volume< /h3>
Check Volume:< /b> Ensure the volume wheel on the headset is turned up.< /li>
Device Volume:< /b> Verify the volume settings on your connected device (console, PC, phone).< /li>
Correct Output Device:< /b> Confirm that "Audeze Maxwell" is selected as the audio output device in your system's sound settings.< /li>
Re-pair:< /b> For wireless or Bluetooth connections, try disconnecting and re-pairing the headset.< /li>
Dongle Connection:< /b> If using the wireless dongle, ensure it is securely plugged in and its LED indicates a connection.< /li>< /ul>
5.2 Microphone Not Working< /h3>
Check Mute:< /b> Ensure the microphone mute button on the headset is not activated.< /li>
Microphone Connection:< /b> Verify the boom microphone is securely inserted into its port.< /li>
Input Device:< /b> Select "Audeze Maxwell" as the input (microphone) device in your system's sound settings or communication application.< /li>
Application Settings:< /b> Check microphone settings within your game or communication software (e.g., Discord, Xbox Party Chat).< /li>< /ul>
5.3 Connectivity Issues< /h3>
Interference:< /b> Move away from other wireless devices that might cause interference (e.g., Wi-Fi routers, other Bluetooth devices).< /li>
Distance:< /b> Ensure you are within the effective range of the wireless dongle or Bluetooth connection.< /li>
Reboot:< /b> Power cycle both the headset and the connected device.< /li>
Firmware Update:< /b> Check the Audeze HQ app for any available firmware updates, as these often resolve connectivity bugs.< /li>< /ul>
5.4 Headset Not Charging< /h3>
Cable Check:< /b> Ensure the USB-C charging cable is not damaged and is securely connected to both the headset and the power source.< /li>
Power Source:< /b> Try a different USB port or wall adapter.< /li>
LED Indicator:< /b> Observe the charging LED for any error indications.< /li>< /ul>< /section>
6. Specifications< /h2>
Feature< /th> Detail< /th>< /tr>
Model Name< /td> Maxwell Xbox (Flora Limited Edition)< /td>< /tr>
Audio Driver Type< /td> 90mm Planar Magnetic Driver< /td>< /tr>
Connectivity Technology< /td> Wireless (USB-C Dongle), Bluetooth 5.0, Wired (USB-C)< /td>< /tr>
Compatible Devices< /td> Xbox, PlayStation, Mac, PC, Switch, Tablets, Smartphones< /td>< /tr>
Battery Life< /td> 80+ Hours< /td>< /tr>
Quick Charge< /td> 20 minutes for a full day of gaming< /td>< /tr>
Noise Control< /td> Sound Isolation, A.I. Noise Filtering (Microphone)< /td>< /tr>
Frequency Range< /td> 20Hz - 20kHz< /td>< /tr>
Impedance< /td> 70 Ohm< /td>< /tr>
Earpiece Shape< /td> Over-ear< /td>< /tr>
Cable Feature< /td> Detachable (USB-C)< /td>< /tr>< /table>

Figure 5: Illustration of Audeze's 90mm Planar Magnetic Drivers, highlighting their advanced audio technology.< /p>< /div>< /section>
7. Warranty & Support< /h2>
7.1 Product Warranty< /h3>
Audeze products are covered by a limited warranty against defects in materials and workmanship. For specific warranty terms and conditions, including duration and coverage details, please refer to the warranty card included with your product or visit the official Audeze website.< /p>
7.2 Customer Support< /h3>
For further assistance, technical support, or inquiries regarding your Audeze Maxwell headset, please contact Audeze customer support through their official channels.< /p>
Online Support:< /b> Visit the Audeze support page on their official website for FAQs, knowledge base articles, and contact forms.< /li>
Audeze HQ App:< /b> Utilize the Audeze HQ app for firmware updates and advanced settings, which can often resolve performance issues.< /li>< /ul>
Official Product Video:< /b>< /p>
