Fisher FBX390 Bærbar Bluetooth Højttaler Brugermanual

1. Introduktion

Tak for købetasing the Fisher FBX390 Portable Bluetooth Speaker. This manual provides essential information for setting up, operating, and maintaining your speaker. Please read it thoroughly before use to ensure optimal performance and safety.

Pakkeindhold:

• Fisher FBX390 Portable Bluetooth Speaker
• Strømkabel
• Hurtig startvejledning
• Garantikort

2. Sikkerhedsoplysninger

To prevent fire, electric shock, or product damage, please observe the following safety guidelines:

• Udsæt ikke højttaleren for ekstreme temperaturer, direkte sollys eller åben ild.
• Undgå at tabe eller udsætte højttaleren for kraftige stød.
• Do not disassemble, repair, or modify the speaker yourself. Contact qualified service personnel.
• Keep the speaker away from water and liquids, despite its IPX4 water resistance. IPX4 protects against splashing water, not submersion.
• Use only the provided power cable for charging.
• Sørg for ordentlig ventilation, når du bruger højttaleren.

3. Produktfunktioner

The Fisher FBX390 speaker offers a range of features designed for an enhanced audio experience:

• Kraftig lyd: 10W RMS (20W Peak) output for clear and immersive sound.
• Bluetooth 5.3: Stable and fast wireless connectivity up to 33 feet (10 meters).
• Dynamiske RGB-lys: Integrated lighting effects that synchronize with music.
• True Wireless Stereo (TWS): Pair two FBX390 speakers for a stereo sound experience.
• IPX4 vandtæthed: Protection against splashing water, suitable for outdoor use.
• Flere afspilningsmuligheder: Bluetooth, AUX input, USB, and TF card support.
• FM-radio: Built-in tuner for listening to radio stations.
• Bærbart design: Lightweight (3.13 lbs) with a carrying handle for easy transport.
• Lang spilletid: Up to 5 hours of playback on a single charge (1500mAh battery).

Image: The Fisher FBX390 speaker demonstrating its IPX4 water resistance with water splashing around it. This feature makes it suitable for outdoor environments where splashes may occur.

Billede: En eksploderet view diagram of the Fisher FBX390 speaker's internal components, illustrating its 2-way audio system and a 3-inch subwoofer for enhanced bass and vibrant sound.

Image: Three Fisher FBX390 speakers showcasing their dynamic RGB lighting effects, which breathe and beat to the rhythm of the music, adding a visual element to the audio experience.

4. Opsætningsvejledning

4.1 Opladning af højttaleren

Before first use, fully charge the speaker. Connect the provided power cable to the charging port on the speaker and a suitable power source. The charging indicator light will illuminate. Once fully charged, the indicator light may change or turn off.

4.2 Tænd/sluk

• Sådan tænder du: Tryk på tænd/sluk-knappen ( og hold den nede)Ⓘ) for a few seconds until you hear an audible prompt or see the indicator lights activate.
• Sådan slukker du: Tryk på tænd/sluk-knappen ( og hold den nede)Ⓘ) igen i et par sekunder.

4.3 Bluetooth -parring

Sådan tilslutter du din højttaler til en Bluetooth-aktiveret enhed:

1. Sørg for, at højttaleren er tændt og i Bluetooth-parringstilstand (indikeret med en blinkende LED).
2. Aktiver Bluetooth på din enhed (smartphone, tablet osv.) og søg efter tilgængelige enheder.
3. Select "FBX390" from the list of devices.
4. Once connected, you will hear a confirmation tone, and the LED indicator will stop flashing.

Image: A group of people enjoying music with the Fisher FBX390 speaker, illustrating its Bluetooth 5.3 connectivity and compatibility with various devices like phones, tablets, computers, and laptops, along with USB, TF card, and AUX input options.

4.4 Ægte trådløs stereo (TWS) parring

To pair two FBX390 speakers for a stereo sound experience:

1. Ensure both FBX390 speakers are powered on and not connected to any Bluetooth device.
2. On one speaker (this will be the primary speaker), press and hold the TWS button (often indicated by two interlocking circles or a similar icon) until you hear a pairing prompt.
3. The two speakers will automatically search and connect to each other. A confirmation tone will sound once paired.
4. Now, connect your device to the primary speaker via Bluetooth as described in section 4.3. Audio will play in stereo through both speakers.

Image: Two Fisher FBX390 speakers positioned for True Wireless Stereo (TWS) pairing, providing dynamic audio for a user engaged in a gaming session, demonstrating enhanced sound immersion.

5. Betjeningsvejledning

5.1 Betjeningsknapper

The speaker features intuitive control buttons located on the top panel:

Billede: Et nærbillede view of the control panel on the top of the Fisher FBX390 speaker, showing buttons for power, volume, track control, mode selection, and TWS pairing.

• Power Button (Ⓘ): Press and hold to power on/off. Short press to play/pause in Bluetooth mode.
• Mode-knap (M): Short press to switch between Bluetooth, FM Radio, AUX, USB, and TF card modes.
• Lydstyrke ned / Forrige nummer (-): Short press for previous track. Press and hold to decrease volume.
• Lydstyrke op / Næste nummer (+): Short press for next track. Press and hold to increase volume.
• TWS knap: Press and hold to initiate TWS pairing (refer to section 4.4).

5.2 FM-radiofunktion

1. Press the Mode button (M) to switch to FM Radio mode.
2. Short press the Power button (Ⓘ) to automatically scan and save available FM stations.
3. Use the Previous/Next Track buttons (−/+) to navigate between saved stations.

5.3 AUX-indgang

Connect an external audio device using a 3.5mm AUX cable (not included) to the AUX input port. The speaker will automatically switch to AUX mode or can be selected using the Mode button.

5.4 USB / TF-kortafspilning

Insert a USB drive or TF (microSD) card containing audio files into the respective port. The speaker will automatically switch to the corresponding mode and begin playback, or you can select it using the Mode button.

6. Vedligeholdelse

• Rensning: Brug en blød, tør klud til at rengøre højttalerens overflade. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• Opbevaring: Opbevar højttaleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
• Batteripleje: If not used for extended periods, charge the speaker at least once every three months to maintain battery health.

7. Fejlfinding

8. Specifikationer

Image: A diagram illustrating the physical dimensions of the Fisher FBX390 speaker, with measurements of 13.64 inches in width, 8.1 inches in height, and 5.58 inches in depth.

9. Garanti og support

This Fisher FBX390 Portable Bluetooth Speaker comes with a Limited Warranty. Please refer to the included Warranty Card for detailed terms and conditions.

For technical support or warranty claims, please contact Fisher customer service. Contact information can typically be found on the Warranty Card or the official Fisher webwebsted.

Return Policy: Products purchased may be eligible for return/replacement within 30 days, subject to the retailer's return policy.
