Indledning
This manual provides essential information for the safe and efficient operation of your Philips SFL5101/56 LED Flashlight. Please read these instructions carefully before use and retain them for future reference.
Figure 1: Philips SFL5101/56 LED Flashlight and packaging.
Opsætning
1. Første opladning
Before first use, fully charge the flashlight. The device is equipped with a built-in 4500mAh rechargeable lithium battery.
- Locate the hidden USB-C charging port on the flashlight.
- Connect the provided USB-C cable to the flashlight and a compatible USB power adapter (not included).
- The digital display will indicate the charging progress. Charge until the display shows 100%.
Figur 2: Intern view of the 4500mAh battery and charging port.
2. Kontrol af batteriniveau
The digital display screen shows the remaining battery level. This allows for timely planning of usage and recharging.
Figure 3: Digital display indicating battery level.
Betjeningsvejledning
1. Tænd/sluk og valg af tilstand
The flashlight supports 4 lighting modes: High Light, Low Light, Burst Flash, and SOS.
- Power On/High Light: Click the power button once to activate the High Light mode.
- Lavt lys: Click the power button again (after High Light) for Low Light mode.
- Burst Flash: Double-click the power button for Burst Flash mode.
- SOS Distress Mode: Double-click the power button again (after Burst Flash) for SOS distress mode.
- Juster lysstyrke: In High or Low mode, long-press the power button to adjust the light brightness.
- Sluk: Long-press the power button to turn off the flashlight from any mode.
2. Telescopic Zoom Function
The flashlight features a telescopic zoomable head to adjust the illumination range.
- Long-range Focusing Beam: Extend the flashlight head outwards for a focused beam, providing up to 850 meters of coverage.
- Wide-angle Defocused Beam: Retract the flashlight head inwards for a wide-angle beam, offering a 70° illumination angle for a clearer field of view at shorter distances.
Figure 4: Telescopic zoom for long-range illumination.
Figure 5: Telescopic zoom for wide-angle illumination.
3. Brugsscenarier
The Philips SFL5101/56 LED Flashlight is suitable for various applications, including:
- Night camping og vandreture
- Exploration activities
- Nødbelysning under strømafbrydelsetages
- General indoor and outdoor use
Figur 6: Eksamples of flashlight use in different environments.
Opretholdelse
1. Rensning
To maintain optimal performance, keep the flashlight clean. Wipe the exterior with a soft, damp klæde. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
2. Opbevaring
Store the flashlight in a cool, dry place away from direct sunlight and extreme temperatures. If storing for an extended period, ensure the battery is partially charged (around 50%) and recharge it every few months to prolong battery life.
3. Batteripleje
Avoid fully discharging the battery frequently. Recharge the flashlight when the battery level is low to maintain battery health.
Fejlfinding
- Lommelygten tænder ikke: Ensure the battery is charged. If the battery is charged and the flashlight still does not turn on, contact customer support.
- Dæmpe lysudbytte: Batteriet er muligvis lavt. Genoplad lommelygten.
- Opladningsproblemer: Ensure the USB-C cable is properly connected and the power adapter is functioning. Check the charging port for any debris.
Specifikationer
| Feature | Detalje |
|---|---|
| Speciel funktion | Adjustable Light Modes, Durable, High Lumens, High Power, Rechargeable |
| Farve | Sort |
| Strømkilde | Batteridrevet |
| Lyskildetype | LED |
| Materiale | Aluminium |
| Batterikapacitet | 4500mAh |
| Lumen output | Op til 2300 Lumens |
| Dækning | Op til 850 mio |
| Drop modstand | 1.5M |
Sikkerhedsoplysninger
- Se ikke direkte ind i lysstrålen for at undgå øjenskader.
- Opbevares utilgængeligt for børn.
- Do not attempt to disassemble or modify the flashlight.
- Undgå at udsætte lommelygten for ekstreme temperaturer eller direkte sollys i længere perioder.
- Sørg for, at dækslet til USB-C-opladeporten er forsvarligt lukket, når den ikke oplades, for at opretholde vandtætheden.
Figure 7: The flashlight is made of durable aluminum alloy with 1.5m drop resistance.
Garanti og support
This Philips SFL5101/56 LED Flashlight comes with a 12-month warranty from the date of purchase. For warranty claims, technical support, or further assistance, please visit the official Philips support webwebsted:
Produktvideoer
Philips SFL5101/56 Flashlight Overview
Video 1: Denne video giver en kort oversigtview of the Philips SFL5101/56 LED Flashlight, highlighting its key features and design.
Philips SFL5101/56 Flashlight Features
Video 2: This video demonstrates the various features of the Philips SFL5101/56 LED Flashlight, including its telescopic zoom and lighting modes.
Philips SFL5101/56 Flashlight in Use
Video 3: This video showcases the Philips SFL5101/56 LED Flashlight in practical outdoor scenarios, demonstrating its performance.
Philips SFL5101/56 Flashlight Zoom Demonstration
Video 4: This video specifically demonstrates the telescopic zoom functionality of the Philips SFL5101/56 LED Flashlight, showing the adjustment between focused and wide beams.
