1. Vigtige sikkerhedsinstruktioner
Læs alle instruktioner omhyggeligt, inden apparatet tages i brug, og gem dem til senere brug. Manglende overholdelse af disse instruktioner kan resultere i elektrisk stød, brand eller alvorlig personskade.
- Sørg altid for strømforsyningens volumtage stemmer overens med typeskiltet på apparatet.
- Brug ikke apparatet på våde overflader eller til at opsuge væsker.
- Hold hår, løstsiddende tøj, fingre og alle dele af kroppen væk fra åbninger og bevægelige dele.
- Træk stikket ud af stikkontakten, når det ikke er i brug, og før rengøring eller servicering.
- Brug ikke noget apparat med en beskadiget ledning eller stik.
- UV-C lamp emits ultraviolet radiation. Avoid direct exposure to eyes and skin. The UV-C lamp is designed to activate only when the appliance is in contact with a surface.
- Do not allow children to use the vacuum cleaner. Close supervision is necessary when used near children.
- Brug kun som beskrevet i denne manual. Brug kun producentens anbefalede tilbehør.
2. Produktet er slutview
The Jimmy BX7 Pro is a corded mattress vacuum cleaner designed for deep cleaning of beds, sofas, and other upholstered surfaces. It features powerful suction, UV-C sterilization, ultrasonic technology, and a quick-heating function to effectively remove dust, pet hair, and allergens.
Figur 2.1: Jimmy BX7 Pro Mattress Vacuum Cleaner. This image shows the complete vacuum cleaner unit, highlighting its compact design and the transparent dust cup.
Nøglefunktioner:
- Kraftig sugning: 480W power and 16Kpa suction for effective dust and pet hair removal.
- Intelligent Dust Sensor: Automatically detects dust levels and displays cleanliness via LED indicators (red for dirty, green for clean).
- UV-C & Ultrasonic Technology: Designed to remove allergens and microorganisms from surfaces.
- Quick Heating Function: Heats to 140°F (60°C) in 5 seconds to assist in dust removal. This function activates only when the machine is in contact with the mattress.
- HEPA-filtrering: Equipped with a HEPA filter to capture fine particles.
- Langt strømkabel: 5m (16ft) cable for extended reach.
- Wide Suction Port: 245mm wide suction port for efficient cleaning.
3. Opsætning
The Jimmy BX7 Pro is designed for ease of use with minimal setup required.
- Udpakning: Carefully remove all components from the packaging. Ensure all parts listed in the product manual (not provided in this context, but generally expected) are present.
- Strømtilslutning: Plug the power cord into a suitable electrical outlet. Ensure the outlet voltage matches the specifications of the vacuum cleaner.
- Indledende kontrol: Before first use, ensure the dust cup and filter are correctly installed.
4. Betjeningsvejledning
4.1 Tænd/sluk
To turn the vacuum cleaner on, press the power button located on the handle. Press it again to turn the appliance off.
4.2 Using UV-C and Ultrasonic Technology
The BX7 Pro integrates UV-C light and ultrasonic technology to target microorganisms and allergens. These features activate automatically when the vacuum head is pressed against a surface, ensuring safe operation and effective cleaning.
Figur 4.1: UV & Ultrasonic Technology. This image illustrates the UV light emitting from the bottom of the vacuum head, indicating its activation during cleaning.
4.3 Quick Heating Function
The vacuum cleaner features a 5-second quick heating function, reaching 140°F (60°C). This heat assists in loosening dust and moisture from fabrics. The heating function is designed to activate only when the machine is in direct contact with the mattress or surface. It will automatically stop heating if the machine is lifted.
Figur 4.2: Quick Heating Function. This image shows red heat rays emanating from the vacuum's base, demonstrating the heating action on a surface.
4.4 Intelligent Dust Sensor and LED Display
The Intelligent Dust Sensor automatically calculates the concentration of dust on the surface being cleaned. An integrated LED display provides real-time feedback on cleanliness:
- Rødt lys: Indicates a very dirty area.
- Red to Blue Light: Indicates a dirty area that is becoming cleaner.
- Blåt lys: Indicates a clean area.
Figur 4.3: Intelligent Dust Sensor. This diagram illustrates the internal workings of the dust sensor and the corresponding LED color indicators for different levels of cleanliness.
Figur 4.4: LED Display Screen. This image shows the vacuum in use on a mattress, with the LED display visible on the top, indicating cleaning performance.
5. Vedligeholdelse
Regular maintenance ensures optimal performance and extends the lifespan of your Jimmy BX7 Pro.
5.1 Tømning af støvbeholderen
The transparent dust cup allows you to monitor dust accumulation. Empty the dust cup regularly, especially when the "Red Light" indicator persists or suction power decreases.
- Sørg for, at støvsugeren er taget ud af stikkontakten.
- Locate the dust cup release button (refer to product diagram in full manual if available).
- Press the release button and carefully detach the dust cup from the main unit.
- Hold the dust cup over a trash receptacle and open the bottom flap to empty the contents.
- Sæt støvbeholderen sikkert på igen, indtil den klikker på plads.
Figur 5.1: Emptying the Dust Cup. This image shows a hand holding the transparent dust cup, filled with collected dust, ready to be emptied.
5.2 Rengøring af HEPA-filteret
The HEPA filter should be cleaned regularly to maintain optimal suction and filtration efficiency. It is recommended to clean the filter after every few uses, or when you notice a decrease in performance.
- Sørg for, at støvsugeren er taget ud af stikkontakten.
- Fjern støvbeholderen som beskrevet ovenfor.
- Fjern forsigtigt HEPA-filteret fra indersiden af støvbeholderen.
- Bank filteret forsigtigt over en skraldespand for at fjerne løst støv.
- Rinse the filter under cool running water until the water runs clear. Do not use detergents.
- Allow the filter to air dry completely for at least 24 hours before reinserting it. Do not use a dryer or other heating devices.
- Once dry, reinsert the HEPA filter into the dust cup and reattach the dust cup to the main unit.
Figur 5.2: Cleaning the HEPA Filter. This image shows the filter being rinsed under running water, demonstrating the cleaning process.
6. Fejlfinding
If you encounter issues with your Jimmy BX7 Pro, please refer to the following common problems and solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Støvsugeren tænder ikke. | Ikke tilsluttet; stikkontaktfejl; beskadiget netledning. | Ensure the power cord is securely plugged into a working outlet. Check the power cord for damage. |
| Tab af sugning. | Full dust cup; clogged filter; obstruction in the suction path. | Empty the dust cup. Clean the HEPA filter. Check the suction port and brush roll for any blockages. |
| UV-C lamp ikke aktiveres. | Vacuum not in contact with surface; lamp defekt. | Ensure the vacuum head is firmly pressed against the cleaning surface. If the issue persists, contact customer support. |
| Varmefunktionen virker ikke. | Vacuum not in contact with surface. | The heating function only activates when the vacuum is in contact with the mattress. Ensure proper contact. |
| LED dust indicator always red. | Area is very dirty; sensor is obstructed. | Continue cleaning the area until the light turns blue. Ensure the sensor area on the vacuum head is clean. |
7. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Jimmy |
| Modelnavn | Jimmy BX7 Pro |
| Speciel funktion | ledning |
| Filtertype | HEPA filter |
| Inkluderede komponenter | Lyssæt medfølger |
| Er trådløs? | Ingen |
| Kapacitet | 1 pund |
| Wattage | 480 watt |
| Anbefalet anvendelse af produktet | Seng |
| Formfaktor | Håndholdt |
| Farve | Grå |
| Produktdimensioner | 16.14 cm L x 12.99 cm B x 9.84 cm H |
| Fabrikant | Jimmy |
| Antal genstande | 1 |
| Stil | BX7 Pro-Gray |
| Transportabel | Ja |
| Antal effektniveauer | 1 |
| Indendørs/Udendørs brug | Indendørs |
| Display Type | Ingen skærm |
| Varens vægt | 7.98 pund |
| Batterier påkrævet | Ingen |
8. Garanti og support
Garantioplysninger:
Jimmy provides a warranty for its products. For any quality problems within one year of purchase, a new machine replacement or refund is offered. If the issue arises after one year, please contact customer service for parts replacement or repair services.
For detailed warranty terms and conditions, please refer to the official Jimmy webwebsted eller kontakt kundesupport.
Kundesupport:
If you have any questions, require technical assistance, or need to claim warranty service, please contact Jimmy customer support. Contact details can typically be found on the official Jimmy webwebstedet eller i produktemballagen.
Du kan også besøge Jimmy Store on Amazon for yderligere produktinformation og supportressourcer.
