VECELO Office Chair Instruction Manual

1. Introduktion

Tak for købetasing the VECELO Office Chair. This manual provides detailed instructions for the assembly, operation, and maintenance of your new chair. Designed for comfort and functionality, this chair features a 360-degree rotation, adjustable height, breathable mesh backrest, and smooth-rolling casters, making it suitable for various environments such as offices, study rooms, and home workspaces. Please read this manual thoroughly before assembly and use to ensure proper function and safety.

Figur 1.1: VECELO Office Chair in black, highlighting its ergonomic design and the range of available colors.

2. Sikkerhedsinstruktioner

• Sørg for, at alle dele er forsvarligt fastgjort før brug.
• Stå ikke på stolen.
• Brug ikke stolen på ujævne overflader.
• Keep children away from the chair during assembly.
• Avoid placing heavy objects on the chair that exceed its maximum weight capacity of 220.5 lbs (100 kg).
• Kontrollér regelmæssigt alle skruer og bolte for fastspænding.

3. Reservedelsliste

Før montering skal du kontrollere, at alle komponenter er til stede og ubeskadigede. Hvis der mangler eller er beskadigede dele, bedes du kontakte kundesupport.

• Ryglæn (1)
• Sædehynde (1)
• Gasløftecylinder (1)
• Base with Casters (1)
• Mekanismeplade (1)
• Armrests (2) - Note: This model may not include armrests.
• Screws and Allen Wrench (1 set)

Figur 3.1: eksploderede view of chair components, illustrating the backrest, seat, gas lift, and five-star base with casters.

4. Opsætning og montering

Follow these steps carefully to assemble your VECELO Office Chair. Assembly typically takes about 15 minutes for one person.

1. Fastgør hjul til basen: Insert each caster into the holes at the end of each leg of the five-star base until it clicks securely into place.
2. Indsæt gasløft: Placer gasløftecylinderen i det centrale hul på den samlede femstjernede base.
3. Fastgør mekanismepladen til sædet: Align the mechanism plate with the screw holes on the underside of the seat cushion. Secure it using the provided screws and Allen wrench. Ensure the lever is positioned correctly for easy access.
4. Fastgør ryglænet til sædet: Connect the backrest to the seat cushion using the designated screws. Ensure a firm and stable connection.
5. Tilslut sædeenheden til gasliften: Carefully place the assembled seat and backrest onto the gas lift cylinder, ensuring the central hole of the mechanism plate aligns with the top of the gas lift. Press down firmly to secure.

Figur 4.1: Illustration of the seat cushion being placed onto the gas lift and base assembly during setup.

Figur 4.2: The fully assembled VECELO Office Chair, demonstrating its compact and functional design.

5. Betjeningsvejledning

Your VECELO Office Chair is designed for ease of use and comfort. Familiarize yourself with its adjustable features:

• Højdejustering: To adjust the seat height, pull the lever located under the seat upwards. While holding the lever, stand up to raise the seat or remain seated and apply pressure to lower it. Release the lever to lock the height. The chair offers approximately 3.9 inches (10 cm) of stepless elevation.
• 360-graders rotation: The chair seat can freely rotate 360 degrees, allowing for easy movement and access to different areas of your workspace without needing to reposition the entire chair.
• Smooth Casters: The durable casters allow for smooth and quiet movement across various floor surfaces, enhancing mobility and work efficiency.

Figur 5.1: Visual guide to the chair's operational features, including seat height adjustment and swivel function.

Figur 5.2: User demonstrating the chair's mobility, highlighting the smooth operation of the casters for effortless movement.

6. Vedligeholdelse

• Rensning: Til ryglænet i net og sædet i stof skal du bruge en blød kludamprengøres med mild sæbe og vand. Undgå skrappe kemikalier eller slibende rengøringsmidler.
• Hjulpleje: Rengør regelmæssigt hår og snavs fra hjulene for at sikre jævn rulning.
• Hardwarekontrol: Kontrollér alle skruer og bolte hver par måneder for at sikre, at de er spændte. Efterspænd om nødvendigt for at opretholde stabilitet og sikkerhed.
• Undgå direkte sollys: Langvarig udsættelse for direkte sollys kan forårsage falmning af stoffet og nettet.

7. Fejlfinding

• Chair Sinks or Does Not Adjust Height: Ensure the gas lift lever is fully engaged. If the issue persists, the gas lift cylinder may need replacement. Contact customer support.
• Stolens vaklen: Check all assembly screws and bolts. Tighten any loose connections. Ensure the chair is on a flat, even surface.
• Hjul ruller ikke jævnt: Undersøg hjulene for fastklemt snavs (hår, fnug osv.), og rengør dem grundigt.
• Knirkende lyde: Apply a small amount of silicone lubricant to moving parts or joints, avoiding the gas lift cylinder.

8. Specifikationer

Figur 8.1: Dimensional drawing of the VECELO Office Chair, providing key measurements for reference.

9. Garanti og support

VECELO is committed to providing high-quality products. For specific warranty details, please refer to the warranty card included with your purchase or visit the official VECELO website. If you encounter any issues or have questions regarding your VECELO Office Chair, please contact our customer support team.

Kundesupport:

• For hjælp, besøg venligst VECELO Store on Amazon eller se din produktemballage for kontaktoplysninger.
