1. Introduktion
Thank you for choosing the EWEADN S9 Pro Wireless Gaming Mouse. This manual provides essential information for setting up, operating, and maintaining your new gaming mouse. The S9 Pro features triple connection modes, a high-precision PAW3395 optical sensor, customizable DPI settings, and a lightweight ergonomic design for optimal performance.
2. Pakkens indhold
Kontroller venligst, at alle varer er til stede i din pakke:
- EWEADN S9 Pro Wireless Gaming Mouse
- Instruktionsmanual (dette dokument)
- 8K Custom Receiver (USB dongle)
- 1.5M Parachute Cord (USB-C to USB-A cable)
- PE Bag Foot Pad
- Anti-slip Protection Sticker
Image: All items included in the EWEADN S9 Pro Wireless Gaming Mouse package, including the mouse, USB-C cable, receiver, and accessories.
3. Produktet er slutview
Familiarize yourself with the buttons and ports of your EWEADN S9 Pro mouse:
Image: A detailed diagram illustrating the various buttons and ports on the EWEADN S9 Pro mouse, including Left Button, Right Button, Middle Button (scroll wheel), DPI Switch, Forward Button, Backward Button, Type-C Port, and the 2.4G-OFF-BT mode switch on the underside.
- Venstre knap: Standard venstreklikfunktion.
- Højre knap: Standard højreklikfunktion.
- Middle Button (Scroll Wheel): Rul op/ned, klik på midten.
- DPI switch: Cycles through preset DPI levels.
- Frem-knap: Navigerer fremad i web browsere eller applikationer.
- Baglæns knap: Navigerer baglæns i web browsere eller applikationer.
- Type-C port: Til kabelforbindelse og opladning.
- 2.4G-OFF-BT Switch: Located on the underside, used to select connection mode or power off.
4. Opsætning
4.1. Opladning af musen
Before first use, it is recommended to fully charge the mouse. Connect the supplied USB-C cable to the mouse's Type-C port and the other end to a USB power source (e.g., computer USB port, USB wall adapter).
Image: The EWEADN S9 Pro mouse connected via its USB-C port to a charging cable, indicating the charging process.
4.2. Tilslutningstilstande
The S9 Pro mouse supports three connection modes: 2.4G Wireless, Bluetooth 5.0, and USB-C Wired. Use the switch on the underside of the mouse to select your desired mode.
Image: An illustration highlighting the three connection modes: 2.4G Wireless for blazing-fast speed, Bluetooth 5.0 for convenience, and USB-C Wired for zero delay and recharging.
2.4G trådløs forbindelse
- Locate the 8K Custom Receiver (USB dongle) in the package.
- Sæt USB-modtageren i en ledig USB-port på din computer.
- Slide the mode switch on the underside of the mouse to the "2.4G" position.
- Musen burde automatisk oprette forbindelse til din computer.
Bluetooth 5.0 forbindelse
- Slide the mode switch on the underside of the mouse to the "BT" position.
- Åbn Bluetooth-indstillingerne på din computer eller enhed, og søg efter nye enheder.
- Select "EWEADN S9 Pro" from the list of available devices to pair.
USB-C kablet forbindelse
- Connect the supplied USB-C cable to the mouse's Type-C port.
- Tilslut USB-A-enden af kablet til en ledig USB-port på din computer.
- Musen fungerer i kablet tilstand og oplades samtidigt.
5. Betjeningsvejledning
5.1. DPI-justering
The EWEADN S9 Pro mouse features customizable DPI settings. You can cycle through preset DPI levels using the dedicated DPI switch button on the top of the mouse. For fine-tuning and additional customization, please use the official EWEADN software.
Image: The EWEADN S9 Pro mouse with an overlay indicating 6 customizable DPI settings, ranging from 800 to 26000 DPI.
5.2. Afstemningsrate
The mouse supports an 8K polling rate in wireless mode (with the 8K receiver) and 1K in wired mode. The polling rate can be configured through the EWEADN software to match your preferences and system capabilities.
5.3. Programmerbare knapper
The S9 Pro mouse is equipped with programmable buttons. To customize button functions, DPI/IPS settings, lift-off distance, and create macros, download and install the official EWEADN software from the manufacturer's website. This software allows for advanced personalization of your mouse settings.
5.4. Ergonomisk design
The mouse is designed for right-handed users with medium to large hands, weighing only 59 grams. Its ergonomic shape aims to reduce fatigue during extended use. It supports various grip styles including palm, claw, and fingertip grips.
Image: An illustration demonstrating the EWEADN S9 Pro mouse's compatibility with palm grip, claw grip, and fingertip grip styles, designed for medium-large handed players.
6. Vedligeholdelse
6.1. Rensning
To clean your mouse, use a soft, dry, lint-free cloth. Avoid using harsh chemicals, solvents, or abrasive materials, as these can damage the surface and internal components. For stubborn dirt, a slightly damp En klud kan bruges, så der ikke kommer fugt ind i musen.
6.2. Batteripleje
The S9 Pro features a 500mAh rechargeable battery. To maximize battery life:
- Undgå at udsætte musen for ekstreme temperaturer.
- Oplad musen regelmæssigt, især når batteriindikatoren viser lav strøm.
- Hvis musen opbevares i længere tid, skal den oplades til cirka 50% inden opbevaring.
7. Fejlfinding
7.1. Musen reagerer ikke
- Tjek batteri: Ensure the mouse is charged. Connect the USB-C cable to charge.
- Kontroller forbindelsestilstand: Verify the mode switch on the underside is set correctly (2.4G, BT, or OFF).
- 2.4G trådløs: Sørg for, at USB-modtageren er korrekt tilsluttet en fungerende USB-port. Prøv en anden USB-port.
- Bluetooth: Re-pair the mouse with your device in Bluetooth settings. Ensure your device's Bluetooth is enabled.
- wired: Ensure the USB-C cable is firmly connected to both the mouse and the computer.
7.2. DPI ændres ikke
- Sørg for at du trykker på den korrekte DPI-knap.
- If using custom DPI settings, check the EWEADN software to ensure settings are applied correctly.
7.3. Lag or Stuttering
- Trådløs interferens: Move the mouse closer to the receiver or your Bluetooth device. Avoid placing the receiver near other wireless devices or large metal objects.
- Afstemningsfrekvens: While 8K polling rate offers high performance, some systems may experience issues. Try reducing the polling rate via the EWEADN software if you encounter instability.
- Batteriniveau: Low battery can sometimes affect wireless performance. Charge the mouse fully.
8. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | EWEADN |
| Modelnummer | S9 Pro |
| Forbindelsesteknologi | 2.4 GHz trådløs, Bluetooth 5.0, USB-C kablet |
| Bevægelsesdetekteringsteknologi | Optisk (PAW3395-sensor) |
| DPI rækkevidde | Op til 26000 DPI |
| IPS Tracking | 650 IPS |
| Afstemningsfrekvens | 8K Wireless, 1K Wired |
| Afbrydere | Kailh Micro Switch (100 Million Clicks) |
| Batterikapacitet | 500mAh |
| Batterilevetid | Op til 250 timer |
| Vægt | 59 gram (ca. 2.08 ounces) |
| Kompatibilitet | Windows 7/8/10/XP/Vista, Mac OS, Linux, Android |
| Kabellængde | 1.5M Parachute Cord |
| Pakkedimensioner | 7.32 x 5.75 x 2.32 tommer |
9. Garanti og support
EWEADN provides manufacturer support for its products. If you encounter any issues or have questions regarding your S9 Pro Wireless Gaming Mouse, please contact EWEADN customer support. The manufacturer aims to provide a response within 24 hours and offers 360 days of brand support.
Image: An illustration indicating EWEADN's commitment to customer support, including 24-hour reply times and 360 days of manufacturer brand support.
For the most up-to-date support information and software downloads, please visit the official EWEADN webwebsted.
