4DRC Y10 Amphibious Vandtæt RC Monster Truck Instruktionsmanual

Indledning

This manual provides essential information for the safe and effective operation of your 4DRC Y10 Amphibious Waterproof RC Monster Truck. Please read these instructions thoroughly before use and retain for future reference.

Sikkerhedsoplysninger

No specific safety warnings were provided beyond general product safety. Always supervise children during operation. Keep fingers, hair, and loose clothing away from moving parts. Do not operate near people, pets, or obstacles. Ensure the battery compartment is securely sealed before water play.

Pakkens indhold

Image: The 4DRC Y10 RC Monster Truck, remote control, wristband controller, two rechargeable batteries, USB charging cable, and a screwdriver.

• 4DRC Y10 RC Monster Truck
• 2.4GHz fjernbetjening
• Wristband Controller (for simplified mode)
• 2 x 7.4V Rechargeable Batteries
• USB opladningskabel
• Skruetrækker
• Brugervejledning (dette dokument)

Opsætningsvejledning

1. Batteriinstallation og opladning

1. Truck Battery:

   Locate the battery compartment on the underside of the RC truck. Use the provided screwdriver to open the compartment. Connect one of the 7.4V rechargeable batteries to the truck's power connector. Securely close the battery compartment, ensuring it is sealed for waterproof operation.



   Image: Illustration of battery installation in the RC truck, showing the compartment and connection points.
2. Batterier til fjernbetjening:

   The 2.4GHz remote control requires 2 AA batteries (not included). Open the battery cover on the back of the remote control and insert the batteries, observing correct polarity. Close the cover securely.

3. Charging the Truck Battery:

   Connect the 7.4V rechargeable battery to the USB charging cable. Plug the USB cable into a standard USB power adapter (e.g., phone charger, computer USB port). The indicator light on the USB cable will show charging status (typically red for charging, off or green for fully charged). Charging time is approximately 2-3 hours. Do not overcharge.



   Image: The USB charging cable connected to a rechargeable battery, illustrating the charging process.

2. Parring af controlleren

To pair the remote control with the truck:

1. Ensure the truck battery is installed and the truck is powered off.
2. Install batteries in the remote control and power it on. The indicator light on the remote will flash.
3. Turn on the RC truck. The truck's lights will flash.
4. Within a few seconds, the remote control and truck lights will become solid, indicating successful pairing.
5. If using the wristband controller, ensure the main remote is off. Power on the truck, then power on the wristband controller. The wristband controller will pair with the truck. Note: The truck can only be paired with one controller at a time.

Betjeningsvejledning

Basic Controls (2.4GHz Remote Control)

• Left Joystick (Forward/Backward): Push forward to move the truck forward, pull backward to move backward.
• Right Joystick (Left/Right): Push left to turn the truck left, push right to turn right.
• Power knap: Tænder/slukker fjernbetjeningen.

Image: The 2.4GHz remote control, highlighting the joysticks for movement and steering.

Dobbelt kontroltilstande

The 4DRC Y10 offers two control methods:

• Fjernbetjeningstilstand: Provides precise steering and speed control for experienced users.
• Wristband Controller Mode: A simplified control option, ideal for younger children. This mode typically offers basic forward/backward and turning functions, often activated by gestures or fewer buttons. Ensure the main remote is off when using the wristband controller.

Image: The RC truck shown with both the traditional remote control and the wristband controller, illustrating the dual control options.

Amphibious and All-Terrain Operation

The 4DRC Y10 is designed for versatile use on various surfaces:

• Jord: Operates effectively on road, meadow, gravel, and sand.
• Vand: The fully sealed, waterproof body allows operation in shallow water, puddles, and pools. Ensure all compartments are securely closed before entering water.

Image: The 4DRC Y10 RC Monster Truck driving through water, demonstrating its amphibious capability.

Image: The 4DRC Y10 RC Monster Truck depicted on different terrains including road, meadow, gravel, and beach, showcasing its multi-terrain exploration capabilities.

360° Stunt Rotation

The truck can perform 360-degree rotations. Refer to the remote control's specific button or joystick combination for activating this stunt. This feature adds dynamic play to both land and water operations.

Image: The 4DRC Y10 RC Monster Truck shown in mid-rotation, illustrating its 360-degree stunt capability.

LED forlygter

The integrated LED headlights provide visibility and enhance the visual experience during operation, especially in low-light conditions.

Opretholdelse

• Rensning: After use, especially in water or dirt, wipe the truck clean with a damp cloth. Ensure all water is drained and the truck is dry before storing.
• Batteripleje: Always fully charge batteries before storage and recharge them periodically if not used for extended periods to maintain battery health. Remove batteries from the remote control if not in use for a long time.
• Opbevaring: Store the truck and accessories in a cool, dry place away from direct sunlight and extreme temperatures.

Fejlfinding

Specifikationer

• Model: Y10
• Mærke: 4DRC
• Skala: 1:14
• Produktdimensioner: 10.63 x 7.5 x 6.3 tommer
• Varens vægt: 2.53 pund
• Kontrolfrekvens: 2.4 GHz
• Battery (Truck): 7.4V Rechargeable (2 included)
• Batteri (fjernbetjening): 2 x AA batterier (medfølger ikke)
• Anbefalet alder: 8 år og opefter
• Funktioner: Amphibious, Waterproof, Metal Shell, LED Headlights, 4WD, 360° Stunt Rotation, Dual Control Modes

Garanti og support

For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official 4DRC webwebstedet. Behold din købskvittering som købsbevis.
