1. Vigtige sikkerhedsoplysninger
Please read all instructions carefully before installing or operating this thermostat. Failure to follow these instructions could result in fire, electric shock, serious injury, or property damage. Keep this manual for future reference.
- Elektrisk installation: Installation must be performed by a qualified electrician in accordance with local and national electrical codes. Ensure power is disconnected at the main circuit breaker before any installation or maintenance.
- GFCI beskyttelse: This thermostat features a built-in Class A Ground Fault Circuit Interrupter (GFCI) for enhanced safety, especially in bathrooms, kitchens, and damp areas. Regularly test the GFCI function as per local regulations.
- Voltage Kompatibilitet: Ensure the thermostat's voltage rating (120V/208V/240V) matches your electrical supply.
- Gulvføler: The included 15-ft floor sensor is crucial for accurate temperature control and protecting your flooring from overheating. Do not operate the system without a properly installed floor sensor.
- Tiltænkt brug: This thermostat is designed for electric radiant in-floor heating systems. Do not use it for other applications unless explicitly stated by the manufacturer.
2. Produktet er slutview
The Stelpro Concerto Smart Thermostat is an advanced programmable thermostat designed for electric radiant in-floor heating systems. It offers precise temperature control, remote management via Wi-Fi, and an intuitive mobile application for enhanced comfort and energy efficiency.
Figur 2.1: Forside view of the Stelpro Concerto Smart Thermostat, showing the digital display, up/down arrows, and power button. A Wi-Fi icon is visible in the top right corner.
Figure 2.2: The thermostat seamlessly integrated into a modern living room wall, demonstrating its sleek design and discreet presence.
Nøglefunktioner:
- Wi-Fi-forbindelse: Remote control and monitoring via a mobile application from anywhere.
- Programmerbare tidsplaner: Create custom heating schedules to optimize comfort and energy consumption.
- Bluetooth Installation Wizard: Simplifies the initial setup and pairing process with the mobile app.
- Flere kontroltilstande: Supports floor, room, or combination (RF) temperature control.
- Built-in Class A GFCI: Provides essential safety protection for wet environments.
- Floor Sensor Included: Comes with a 15-ft floor sensor for accurate floor temperature readings.
- Kompatibilitet: Works with most floor sensors on the market and is compatible with Google Home and Amazon Alexa.
3. Installation
The installation of the Stelpro Concerto Smart Thermostat involves electrical wiring and should only be performed by a qualified electrician. Refer to the detailed wiring diagrams provided in the separate installation guide that accompanies the product packaging.
Installationstrin (Overview):
- Strømafbrydelse: Turn off power to the heating circuit at the main electrical panel.
- Montering: Mount the thermostat to a standard electrical box.
- Ledningsføring: Connect the electrical wires according to the provided wiring diagram. Ensure all connections are secure.
- Floor Sensor Installation: Route the 15-ft floor sensor cable to the heating mat area and position the sensor correctly within the floor.
- Afsluttende samling: Secure the thermostat cover and restore power.
Note: Detailed wiring instructions and safety precautions are critical for proper installation. Consult the dedicated installation manual for comprehensive guidance.
4. Initial Setup and App Connectivity
After successful installation, the thermostat can be configured and controlled via the Stelpro mobile application. The Bluetooth installation wizard simplifies the initial pairing process.
4.1 Download af appen
The Stelpro mobile application is available for both Android and iOS devices. Søg efter "Stelpro" in your device's app store.
Figure 4.1: The Stelpro app is compatible with both Android and iOS operating systems, allowing broad accessibility for users.
Figure 4.2: A visual representation of the user-friendly mobile application, displaying various room temperature controls and scheduling options.
4.2 Bluetooth Pairing and Wi-Fi Connection
- Sørg for, at Bluetooth er aktiveret på din smartphone.
- Open the Stelpro app and follow the on-screen prompts to add a new device.
- The app will use Bluetooth to discover your thermostat.
- Once discovered, you will be guided through connecting the thermostat to your home Wi-Fi network. Enter your Wi-Fi credentials when prompted.
- After successful Wi-Fi connection, the thermostat will be accessible remotely via the app.
Tip: If you experience difficulty pairing, ensure your phone is close to the thermostat and that your Wi-Fi network is active and has a strong signal.
5. Betjeningsvejledning
The Stelpro Concerto Smart Thermostat offers both manual control via its interface and comprehensive control through the mobile application.
5.1 Manual Control (On-Device)
Figure 5.1: A close-up of a finger interacting with the thermostat's touch-sensitive up arrow, illustrating simple manual temperature adjustment.
- Justering af temperatur: Brug Op (^) og Ned (v) arrows on the thermostat's display to manually increase or decrease the setpoint temperature.
- Power knap: Press the circular power button at the bottom to turn the heating system on or off.
- Vise: The digital display shows the current temperature and Wi-Fi status.
5.2 App Control and Advanced Features
The mobile app unlocks the full potential of your Concerto Smart Thermostat, allowing for remote management and advanced programming.
- Fjernjustering af temperatur: Change the setpoint temperature from anywhere using the app.
- Planlægning: Create daily or weekly heating schedules to automatically adjust temperatures based on your routine. This feature helps save energy.
- Energiovervågning: Track your heating system's energy consumption directly from the app.
- Kontroltilstande: Select between floor, room, or combination (RF) control modes to suit your preference. The combination mode uses both the floor sensor and ambient room temperature for optimal comfort.
- Maksimal temperaturindstilling: Set a maximum floor temperature to protect sensitive flooring materials and ensure user safety.
- Voice Assistant-integration: Control your thermostat using voice commands through compatible devices like Google Home and Amazon Alexa.
6. Vedligeholdelse
The Stelpro Concerto Smart Thermostat requires minimal maintenance to ensure optimal performance and longevity.
- Rensning: Tør forsigtigt termostatens overflade af med en blød kludamp klud. Brug ikke slibende rengøringsmidler, opløsningsmidler eller kemiske spray, da disse kan beskadige overfladen eller de indvendige komponenter.
- GFCI test: Periodically test the built-in GFCI by pressing the "Test" button on the thermostat. The circuit should trip, and the test light should illuminate. Reset the GFCI by pressing the "Reset" button. If it does not trip or reset, contact a qualified electrician.
- Firmwareopdateringer: Ensure your mobile app and thermostat firmware are up-to-date to benefit from the latest features and improvements. Updates are typically managed through the app.
7. Fejlfinding
If you encounter issues with your Stelpro Concerto Smart Thermostat, refer to the following common troubleshooting steps:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Termostaten tænder ikke. | No power supply; tripped circuit breaker; incorrect wiring. | Check the circuit breaker. Ensure power is restored. Verify wiring connections (consult an electrician if unsure). |
| Kan ikke oprette forbindelse til Wi-Fi eller app. | Incorrect Wi-Fi password; weak Wi-Fi signal; Bluetooth pairing issue; app glitch. | Double-check Wi-Fi password. Move closer to your Wi-Fi router. Restart your phone and the thermostat (by cycling power). Re-attempt Bluetooth pairing. Ensure app is updated. |
| Floor not heating or uneven heating. | Incorrect temperature setting; floor sensor issue; heating element malfunction. | Verify the setpoint temperature. Check floor sensor connection. If the issue persists, contact a qualified technician. |
| GFCI trips frequently. | Ground fault detected; wiring issue; faulty heating element. | This indicates a serious electrical issue. Immediately contact a qualified electrician for diagnosis and repair. Do not bypass the GFCI. |
For issues not covered here, or if troubleshooting steps do not resolve the problem, please contact Stelpro customer support.
8. Specifikationer
Figure 8.1: Detailed dimensions of the Stelpro Concerto Smart Thermostat, indicating its height, width, and depth in both inches and millimeters.
| Attribut | Detalje |
|---|---|
| Mærke | Stelpro |
| Modelnavn | Concerto Smart |
| Produktdimensioner | 4.4D x 7.9W x 12.7H Centimetres (4.4 x 7.85 x 12.65 cm; 300 g) |
| Varens vægt | 300 g |
| Materiale | Plast |
| Farve | Hvid |
| Forbindelsesteknologi | Bluetooth, WiFi |
| Særlige funktioner | Dimmable, Lighted, Programmable, Temperature Display |
| Inkluderede komponenter | Floor sensor (15-ft) |
| Voltage Kompatibilitet | 120V/208V/240V |
| GFCI Type | Klasse A |
9. Garanti og support
9.1 Garantioplysninger
The Stelpro Concerto Smart Thermostat is backed by a 3 års garanti from the date of purchase. This warranty covers defects in material and workmanship under normal use and service. Please retain your proof of purchase for warranty claims.
The warranty does not cover damage resulting from improper installation, misuse, abuse, unauthorized modifications, or acts of nature.
9.2 Kundesupport
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Stelpro customer support. Visit the official Stelpro webwebstedet for de mest opdaterede kontaktoplysninger, ofte stillede spørgsmål og yderligere ressourcer.
Stelpro Official Webwebsted: www.stelpro.com
