Indledning
This manual provides essential information for the safe and efficient operation of your AMEIFU F2 Air Purifier. Please read it thoroughly before use and retain it for future reference.
Vigtige sikkerhedsinstruktioner
- Læs alle instruktioner, inden du betjener apparatet.
- Betjen ikke en ventilator med en beskadiget ledning eller stik. Kassér blæseren eller returner til et autoriseret serviceværksted til undersøgelse og/eller reparation.
- Før ikke ledningen under gulvtæpper. Dæk ikke ledningen med tæpper, løbere eller lignende belægninger. Anbring ledningen væk fra trafikområdet, og hvor den ikke vil blive snublet over.
- For at mindske risikoen for brand eller elektrisk stød må denne blæser ikke bruges sammen med en solid-state hastighedskontrolenhed.
- Unplug the air purifier before moving, cleaning, or performing any maintenance.
- Hold luftrenseren væk fra vand eller andre væsker.
- Bloker ikke luftindtag eller -udtag.
- Dette apparat er ikke beregnet til brug af personer (inklusive børn) med nedsatte fysiske, sensoriske eller mentale evner, eller mangel på erfaring og viden, medmindre de har fået opsyn eller instruktion i brugen af apparatet af en person, der er ansvarlig for deres sikkerhed.
- Børn skal være under opsyn for at sikre, at de ikke leger med apparatet.
Produktkomponenter
Familiarize yourself with the parts of your AMEIFU F2 Air Purifier:
- Air Purifier Unit (Main Body)
- H13 HEPA Filter (Pre-installed)
- Strømledning
- Aromatherapy Pad (inside the unit)
Image: The AMEIFU F2 Air Purifier, showing its compact design and the top opening for aromatherapy oil application.
Opsætningsvejledning
- Unpack the Air Purifier: Tag forsigtigt enheden ud af emballagen.
- Fjern filteremballage: The power cord and filter are placed inside the product for shipping.
- Turn the unit upside down and twist the base cover counter-clockwise to unlock.
- Remove the base cover and take out the H13 HEPA filter.
- Fjern al plastikemballage fra filteret.
- Place the unwrapped filter back into the unit.
- Sæt bunddækslet på igen, og drej det med uret for at låse det sikkert.
- Placer enheden: Place the air purifier on a flat, stable surface. Ensure there is at least 6 inches (15 cm) of space around all sides for optimal airflow.
- Tilslut strøm: Sæt netledningen i en almindelig stikkontakt.
Billede: En eksploderet view illustrating the 3-stage filtration system: Pre-Filter, H13 HEPA Filter, and Activated Carbon Filter.
Betjeningsvejledning
Kontrolpanel overview
The AMEIFU F2 Air Purifier features a smart touch control panel with the following functions:
- Power knap: Tænder/slukker enheden.
- Lys knap: Styrer displaylyset.
- Mode knap: Cycles through fan speeds (L1, L2, L3, Auto) and Sleep Mode.
- Timer knap: Sets the operating timer (2h, 4h, 8h, 12h).
- Børnelås knap: Activates/deactivates the child lock.
- Indikator for filternulstilling: Lyser når filteret skal udskiftes.
Image: Close-up of the air purifier's smart touch control panel, highlighting the various function buttons.
Første gang tændt
After plugging in, the air purifier will enter a preheating state. The indicator light will flash for approximately one minute as it calibrates the air quality sensor.
Luftkvalitetsindikator
The unit features a real-time air quality sensor. The light color indicates current air quality:
- Grøn: God luftkvalitet.
- Blå: Minor pollution detected.
- Rød: Severe pollution detected.
Indstillinger for blæserhastighed
Press the "Mode" button to cycle through the following fan speeds:
- L1 (Low): Quiet operation, suitable for sleeping.
- L2 (Medium): Balanced performance for daily use.
- L3 (High): Maximum purification for quick cleaning.
- Automatisk tilstand: Adjusts fan speed automatically based on detected air quality.
Dvaletilstand
Activate Sleep Mode by pressing the "Mode" button until it is selected. In this mode, the fan operates at a low noise level (less than 15dB), and the display screen turns off automatically after one minute to ensure an undisturbed environment. L1 or Auto speed is recommended for sleeping.
Image: A child sleeping, with the air purifier nearby, demonstrating its low noise level (15dB) in sleep mode.
Timer funktion
Press the "Timer" button to set the operating duration. Available settings are 2 hours, 4 hours, 8 hours, and 12 hours. The unit will automatically turn off after the set time.
Børnelås
To activate the Child Lock, press and hold the "Child Lock" button for a few seconds. This prevents accidental changes to settings. Repeat the action to deactivate the Child Lock.
Image: A child and a dog playing near the air purifier, highlighting the child lock feature for safety.
Aromaterapi funktion
To use the aromatherapy function:
- Locate the aroma pad on the top of the unit.
- Add a few drops of your preferred essential oil (not included) onto the aroma pad.
- The fragrance will be diffused with the purified air.
Image: A woman adding essential oil to the top of the air purifier, demonstrating the aromatherapy feature.
Opretholdelse
Udskiftning af filter
The filter reset indicator light will flash after approximately 2160 hours of use, prompting you to replace the filter. For optimal performance, replace the filter every 3-6 months, depending on usage and air quality.
- Træk stikket til luftrenseren ud af stikkontakten.
- Turn the unit upside down and twist the base cover counter-clockwise to unlock.
- Fjern det gamle filter, og bortskaf det korrekt.
- Insert a new AMEIFU H13 HEPA replacement filter (search B0DK574MDG on Amazon). Ensure it is correctly seated.
- Sæt bunddækslet på igen, og drej det med uret for at låse det sikkert.
- Plug the unit back in. Press and hold the "Filter Reset" button for 3-5 seconds until the indicator light turns off to reset the filter timer.
Note: Do not wash the filter. The filter is not reusable.
Rengøring af enheden
- Tag altid stikket ud af luftrenseren før rengøring.
- Tør enhedens yderside af med en blød, tør klud.
- Brug ikke slibende rengøringsmidler eller opløsningsmidler.
- Periodically vacuum the air inlet vents to remove dust and debris.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Enheden tænder ikke. |
|
|
| Airflow is weak or noise is excessive. |
|
|
| Air quality indicator always red/blue despite clean environment. |
|
|
| Filter reset light remains on after filter change. |
|
|
Specifikationer
| Feature | Detalje |
|---|---|
| Modelnummer | F2 |
| Mærke | AMEIFU |
| Produktdimensioner | 7.3" D x 7.3" B x 11.2" H |
| Vægt | 3.24 pund |
| Dækningsområde | Op til 1200 Sq Ft |
| Filtreringstype | H13 HEPA 3-Stage Filtration (Pre-filter, H13 HEPA, Activated Carbon) |
| Blæserhastigheder | 3 (L1, L2, L3) + Auto Mode |
| Timerindstillinger | 2 timer, 4 timer, 8 timer, 12 timer |
| Støjniveau (dvaletilstand) | Mindre end 15dB |
| Særlige funktioner | Real-Time Air Quality Sensor, Child Lock, Aromatherapy Function, Filter Reset Reminder |
| Wattage | 6 watt |
| Certificeringer | CARB Certified, CE Certified, EPA Certified, ETL Certified, FCC Certified |
Garanti og support
For warranty information and customer support, please refer to the documentation included with your purchase or contact AMEIFU customer service directly. Keep your purchase receipt as proof of purchase.
Udskiftningsfilter: The official replacement filter can be purchased on Amazon by searching for ASIN B0DK574MDG.
