Apollo Phantom Pro XXL Hjul Løbehjul Brugermanual

1. Introduktion

Thank you for choosing the Apollo Phantom Pro XXL Wheel Kick Scooter. This manual provides essential information for the safe assembly, operation, maintenance, and troubleshooting of your new scooter. Please read this manual thoroughly before first use and keep it for future reference.

The Apollo Phantom Pro is designed for effortless cruising in urban environments, perfect for commuting to work, school, or simply enjoying a ride. Its foldable and height-adjustable design ensures convenience and adaptability for various users.

Image: The Apollo Phantom Pro XXL Wheel Kick Scooter, showcasing its sleek design and large wheels.

2. Sikkerhedsoplysninger

Din sikkerhed er altafgørende. Følg altid følgende sikkerhedsretningslinjer:

• Bær altid passende sikkerhedsudstyr, inklusive hjelm, knæbeskyttere og albuebeskyttere.
• Sørg for, at alle clamps, bolts, and screws are securely tightened before each ride.
• Overskrid ikke den maksimale vægtkapacitet på 100 kg (220 lbs).
• This scooter is suitable for children aged 7 and above, and adults. User height should be between 120 cm and 190 cm.
• Ride on smooth, dry, and clean surfaces. Avoid uneven terrain, wet surfaces, sand, gravel, or obstacles.
• Do not ride in traffic or on public roads where prohibited.
• Maintain a safe distance from other riders and pedestrians.
• Use the rear friction brake to slow down and stop. Practice braking in a safe area.
• Avoid riding at excessive speeds, especially downhill.
• Do not make modifications to the scooter.
• The scooter is tested according to DIN EN 71 and EN 14619 standards.

3. Opsætning og montering

3.1 Udfoldning af scooteren

1. Placer scooteren på en flad overflade.
2. Locate the quick-release folding mechanism (1-click system) near the front wheel.
3. Press or pull the lever/button to release the folding lock.
4. Carefully unfold the handlebar stem upwards until it locks securely into place. You should hear a click.
5. Ensure the folding mechanism is fully engaged and stable before proceeding.

3.2 Justering af styrets højde

1. Find hurtigudløserklemmenamp på frempinden.
2. Åbn quick-release clamp.
3. Adjust the handlebar to your desired height (between 92 cm and 105 cm). Ensure the handlebar is at a comfortable level for safe riding, typically around hip height when standing on the deck.
4. Juster styret med forhjulet.
5. Luk quick-release clamp firmly to secure the handlebar in position. If the handlebar still moves, tighten the clamping screw on the quick-release lever.

Image: Demonstrates the scooter's easy folding mechanism and compact size.

Image: Shows the adjustable height feature accommodating various user sizes.

4. Betjeningsvejledning

4.1 At køre på scooter

• Place one foot firmly on the non-slip deck (griptape surface).
• Use your other foot to push off the ground to gain momentum.
• Once you have enough speed, place both feet on the deck, one behind the other.
• Styr ved forsigtigt at læne dig og dreje styret.
• The 200mm XXL high-rebound PU wheels are designed for smooth rides and high speeds, even over minor bumps.

Image: Highlights the large, fast wheels suitable for diverse urban terrains.

4.2 Bremsning

The Apollo Phantom Pro is equipped with a rear friction brake. To brake:

• Gently press your foot down on the rear fender brake.
• Apply gradual pressure to slow down smoothly. Avoid sudden, hard braking, especially at high speeds, to prevent loss of control.

4.3 Sammenfoldning til opbevaring/transport

Sådan foldes scooteren sammen til kompakt opbevaring eller transport:

1. Ensure the handlebar is at its lowest setting.
2. Åbn quick-release clamp on the handlebar stem and slide the handlebar down completely. Close the clamp.
3. Locate the 1-click folding mechanism near the front wheel.
4. Activate the mechanism to release the handlebar stem.
5. Fold the handlebar stem downwards until it clicks into its folded position, parallel to the deck.
6. The scooter is now compact and easy to carry or store.

Image: Illustrates the scooter's portability when folded, fitting easily into a car trunk.

Image: Detail of the integrated kickstand for convenient parking.

5. Vedligeholdelse

Regular maintenance will extend the life of your Apollo Phantom Pro scooter.

• Rensning: Tør scooteren af ​​med reklameamp cloth after use. Avoid using harsh chemicals or abrasive cleaners. Do not use high-pressure water jets.
• Bolts and Screws: Periodically check all bolts, nuts, and screws to ensure they are tight. Loose components can affect performance and safety. Pay special attention to the handlebar clamp and folding mechanism.
• Hjul og lejer: Inspect the 200mm PU wheels for wear and tear. The ABEC9 bearings are designed for durability, but if you notice any unusual noise or resistance, they may need cleaning or replacement. Avoid riding through water or sand, as this can damage bearings.
• Bremse: Check the rear friction brake for proper function. Ensure the brake pad is not excessively worn.
• Greb: The padded handles should be checked for secure attachment and wear.
• Opbevaring: Opbevar scooteren et tørt sted, væk fra direkte sollys og ekstreme temperaturer.

Image: Highlights key components like grips, bearings, and brake, which require periodic inspection.

6. Fejlfinding

Hvis du støder på problemer med din scooter, kan du se følgende almindelige problemer og løsninger:

7. Specifikationer

8. Garanti og support

For any questions, concerns, or support needs regarding your Apollo Phantom Pro XXL Wheel Kick Scooter, please contact the retailer or manufacturer directly.

While specific warranty details are not provided in this manual, please refer to your purchase documentation for information on warranty coverage. Typically, products come with a return policy (e.g., 30 days for refund/replacement) as per retailer terms.

Always retain your proof of purchase for warranty claims or support inquiries.
