Scheppach BC-MP220-X Cordless Lawnmower

1. Introduktion

This instruction manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Scheppach BC-MP220-X cordless lawnmower. Please read this manual thoroughly before first use and keep it for future reference.

Figure 1: Scheppach BC-MP220-X Cordless Lawnmower with included 4Ah battery and charger.

Nøglefunktioner:

• Compact cordless lawnmower with 21.5 cm cutting width and mulching function, suitable for small lawn areas up to 120 m².
• Maintenance-free, brushless motor for high efficiency, longer runtime, extended lifespan, and reduced wear.
• Part of the Scheppach IXES 20-Volt series, allowing battery and charger compatibility with other tools in the system.
• Cutting height adjustment in 3 stages from 30 – 50 mm.
• Ergonomic comfort handle designed to absorb vibrations effectively.
• Ground blade made of special steel, ensuring robustness and durability.
• Divisible shaft for space-saving storage. Includes a scraper for easy cleaning of the mowing deck.
• Large wheels provide secure grip, even on sloped terrain.
• Practical LED light on the machine housing indicates the current battery charge level.
• Includes a 4Ah battery and charger in the scope of delivery.

2. Sikkerhedsinstruktioner

Overhold altid følgende sikkerhedsforanstaltninger for at forhindre personskade og beskadigelse af produktet.

Generel sikkerhed:

• Read all instructions carefully before operating the lawnmower.
• Bær passende personlige værnemidler (PPE), herunder øjenbeskyttelse, robust fodtøj og lange bukser.
• Hold børn og omkringstående væk fra betjeningsområdet.
• Never operate the lawnmower in wet grass or rain.
• Undersøg området for genstande, der kan blive slynget ud af bladet, før du slår græs.
• Disconnect the battery before cleaning, maintenance, or when leaving the machine unattended.

Batterisikkerhed:

• Use only the specified battery and charger for this product.
• Udsæt ikke batterier for ekstreme temperaturer eller direkte sollys.
• Kortslut ikke batteripolerne.
• Opbevar batterier på et køligt, tørt sted.

3. Pakkens indhold

Ensure all items are present and undamaged upon unpacking:

• Scheppach BC-MP220-X Cordless Lawnmower unit
• 4Ah 20-Volt IXES Series Battery
• Batterioplader
• Scraper for cleaning
• Instruktionsmanual

4. Opsætning og montering

Follow these steps to assemble your lawnmower before first use.

4.1 Handle Assembly:

The lawnmower features a divisible shaft for compact storage. To assemble, connect the two sections of the handle securely until they click into place. Ensure all locking mechanisms are engaged.

Figure 2: Connecting the divisible shaft for operation or disconnecting for storage.

4.2 Battery Insertion:

Insert the fully charged 20-Volt IXES Series battery into the designated battery compartment on the lawnmower until it locks securely. The integrated LED light on the machine housing will indicate the battery's charge level.

Figure 3: The Scheppach IXES 20-Volt battery system, highlighting compatibility across multiple tools.

5. Betjeningsvejledning

5.1 Opladning af batteriet:

Connect the charger to a power outlet and insert the battery. The charger's indicator lights will show the charging status. A full charge is indicated when the light turns green (or as per charger instructions). Always ensure the battery is fully charged before use for optimal performance.

5.2 Adjusting Cutting Height:

The cutting height can be adjusted in 3 stages, from 30 mm to 50 mm. To adjust, locate the height adjustment lever near the wheels and move it to the desired position. Ensure all wheels are set to the same height for an even cut.

Figure 4: Adjusting the cutting height between 30mm and 50mm.

5.3 Start og stop:

To start the lawnmower, press the safety button and then pull the switch lever towards the handle. Release the switch lever to stop the motor. Always ensure a firm grip on the handle during operation.

5.4 Mowing Techniques:

For best results, mow in straight, overlapping lines. The BC-MP220-X supports both standard mowing and mulching. For mulching, ensure the mulching plug (if included, or refer to specific model features) is correctly installed. The compact design and swiveling handle allow for easy maneuvering around obstacles and under garden furniture.

Figure 5: Illustration of mowing and mulching applications.

Figure 6: The swiveling handle allows for easy mowing under shrubs or garden furniture.

6. Vedligeholdelse

Regelmæssig vedligeholdelse sikrer din plæneklippers lange levetid og optimale ydeevne.

6.1 Cleaning the Mower:

After each use, disconnect the battery and clean the mowing deck and blade area. Use the included scraper to remove grass clippings and debris. Do not use water jets or harsh chemicals directly on electrical components.

Figure 7: Using the included scraper for easy cleaning of the mowing deck.

6.2 Pleje af knive:

Periodically inspect the blade for sharpness and damage. A dull or damaged blade can affect cutting performance and put strain on the motor. If necessary, have the blade sharpened or replaced by a qualified service technician.

6.3 Opbevaring:

For space-saving storage, the handle can be disassembled. Clean the lawnmower thoroughly and store it in a dry, secure location, away from direct sunlight and extreme temperatures. Remove the battery before long-term storage.

7. Fejlfinding

Se dette afsnit for almindelige problemer og deres løsninger.

8. Specifikationer

9. Garanti og support

Scheppach products are manufactured with high quality standards. In the unlikely event of a defect, please contact your retailer or the Scheppach customer service for assistance. Keep your proof of purchase for warranty claims.

For further support or spare parts, please visit the official Scheppach webwebstedet eller kontakt deres kundeserviceafdeling. Kontaktoplysninger kan typisk findes på produktemballagen eller i producentens webwebsted.
