NIIMBOT D11 Ny version af etiketmaskine Brugermanual

1. Introduktion

This manual provides comprehensive instructions for the setup, operation, maintenance, and troubleshooting of your NIIMBOT D11 New Version Label Maker Machine. Please read this manual thoroughly before using the device to ensure proper function and safety.

Image: The NIIMBOT D11 label maker, shown with several rolls of label tape and a smartphone displaying the NIIMBOT app interface.

2. Sikkerhedsoplysninger

To prevent injury or damage to the device, observe the following safety precautions:

• Keep the product and its accessories away from children. Adult supervision is required if children use the device.
• Do not expose the product or power adapter to high temperatures or high humidity.
• This product contains batteries. Do not disassemble, impact, squeeze, or place the device at high temperatures.
• If the product exhibits any anomaly (e.g., overheating, short circuit), discontinue use immediately.

3. Pakkens indhold

Bekræft at alle varer er til stede i din pakke:

• NIIMBOT D11 etiketmaskine
• 3 Rolls of Label Tape (14x30mm clear, 14x40mm white, 12x40mm green)
• USB-C ladekabel
• Brugermanual

4. Produktet er slutview og funktioner

The NIIMBOT D11 is a portable thermal label printer designed for various organizational needs. It offers enhanced clarity and efficiency.

Nøglefunktioner:

• Høj opløsning: 300 dpi for clear text and images.
• Kompakt design: Smaller and more portable than traditional label makers.
• Automatisk kalibrering: Prevents waste of the first label.
• Hurtig udskrivning: Up to 50mm/s print speed.
• Monokrom udgang: Prints black text only.
• Bluetooth-forbindelse: Connects wirelessly to mobile devices via the NIIMBOT app.
• Understøttelse af flere enheder: Allows up to 6 mobile phones to connect simultaneously.
• Versatile App: Offers various templates, texts, symbols, logos, barcodes, QR codes, and image integration.
• Bred anvendelse: Suitable for home organization, small business, school, and office use.

Image: A visual comparison highlighting the smaller size and improved specifications (1500mAh battery, 300dpi, Type-C, 50mm/s) of the D11_H model compared to the D11.

Image: A close-up demonstrating the clarity of 300 dpi high-resolution thermal printing from the NIIMBOT D11_H compared to a lower resolution print.

5. Opsætningsvejledning

5.1 Opladning af enheden

Before first use, fully charge the label maker. The device uses a Type-C charging port.

1. Connect the provided USB-C cable to the charging port on the label maker.
2. Tilslut den anden ende af kablet til en USB-strømadapter (medfølger ikke) eller en USB-port på computeren.
3. The indicator light will show charging status. A full charge typically takes 1-2 hours and provides approximately 5 hours of working time.

Image: An illustration detailing the Type-C fast charging capability of the NIIMBOT D11, indicating a full charge in 1-2 hours for 5 hours of operation.

5.2 Installing the Label Roll

1. Åbn låget på etiketprinteren.
2. Insert the label roll into the compartment, ensuring the printing side of the label faces upwards and the first label extends slightly out of the printer slot.
3. Close the cover securely. The printer will automatically calibrate the label position.

Image: A visual explanation of the NIIMBOT D11's automatic calibration feature, showing how it rewinds the first label to prevent waste during printing.

5.3 Downloading the NIIMBOT App

The NIIMBOT D11 operates exclusively with the NIIMBOT mobile application.

1. Scan the QR code on the product packaging or search for "NIIMBOT" in your device's app store (App Store for iOS, Google Play Store for Android).
2. Download og installer applikationen.

5.4 Tilslutning via Bluetooth

1. Sørg for, at Bluetooth er aktiveret på din mobilenhed.
2. Open the NIIMBOT application.
3. Within the app, search for and select your NIIMBOT D11 printer to pair. The printer's indicator light will confirm a successful connection.

Note: The NIIMBOT D11 only supports mobile Bluetooth connections and is not compatible with computers or tablets.

Image: A diagram illustrating the NIIMBOT D11's capability to connect to multiple smartphones (up to 6) via Bluetooth through the NIIMBOT/NIIM App.

6. Betjening

6.1 Brug af NIIMBOT-appen

The NIIMBOT app provides a user-friendly interface for label creation.

• Skabeloner: Access a variety of pre-designed templates for different uses.
• Tekst: Input custom text with various fonts and sizes.
• Symboler og ikoner: Choose from a library of symbols and icons to enhance your labels.
• Stregkoder og QR-koder: Generer og udskriv stregkoder eller QR-koder.
• Billeder: Insert simple images onto your labels.
• Tid og dato: Add current time or date stamps.

Image: A smartphone screen displaying the NIIMBOT app interface, showcasing options for adding text, symbols, logos, barcodes, QR codes, images, and time to labels.

Image: A visual representation of the NIIMBOT Multi-Function APP, highlighting features such as borders, barcode/QR code generation, various icons, and font selection.

6.2 Oprettelse og redigering af etiketter

1. Open the NIIMBOT app and ensure your printer is connected.
2. Select a new label or choose an existing template.
3. Use the app's editing tools to add text, symbols, images, or other elements.
4. Adjust font size, style, and alignment as needed.

6.3 Udskrivning af etiketter

1. After designing your label, tap the "Print" button in the app.
2. Confirm the number of copies.
3. The label maker will print the labels. Manually tear off the printed label from the printer's output slot.

Note: The D11 uses fixed-length labels and does not support continuous label tape.

Image: A woman using the NIIMBOT D11 label maker, holding a smartphone displaying the app, with printed labels and gift boxes in the background.

6.4 Applikationsscenarier

The NIIMBOT D11 is suitable for a variety of labeling tasks:

• Hjemmeorganisation: Labeling kitchen containers, storage boxes, personal items.
• Lille virksomhed: Pris tags, product labels, inventory management.
• Kontor og skole: File classification, name tags, stationery labeling.

Image: A collage showing the versatility of the NIIMBOT D11, with labels used for kitchen items, medication reminders, and office organization.

Billede: Eksamples of the NIIMBOT D11's wide application, including labels for small business clothing tags, condiment bottles, and jewelry.

7. Vedligeholdelse

7.1 Rengøring af printeren

Regular cleaning helps maintain print quality and extends the life of your device.

• Ensure the printer is turned off before cleaning.
• Brug en blød, tør og fnugfri klud til at tørre printerens yderside af.
• Gently clean the print head with an alcohol wipe or a cotton swab lightly dampened with isopropyl alcohol. Allow it to dry completely before use.

7.2 Pleje af batterier

• Undgå at aflade batteriet helt ofte.
• Opbevar enheden et køligt og tørt sted, hvis den ikke bruges i længere perioder.
• Charge the device periodically (e.g., every 3 months) to prevent deep discharge.

7.3 Opbevaring af etiketter

Store label rolls in a cool, dry place away from direct sunlight to preserve their adhesive and print quality.

Image: A visual representation of NIIMBOT label durability, highlighting their waterproof, oil-proof, and scratch-resistant qualities for better printing experience.

8. Fejlfinding

Hvis du støder på problemer med din NIIMBOT D11, kan du se følgende almindelige problemer og løsninger:

Vigtige bemærkninger:

• The NIIMBOT D11 is a monochrome printer and only prints in black text. It cannot print in color.
• The label maker uses fixed-length labels and does not support continuous label tape.

9. Specifikationer

Image: The rear packaging of the NIIMBOT D11, displaying multi-language warnings, product specifications, and compliance marks.

10. Garantioplysninger

The NIIMBOT D11 Label Maker Machine comes with a limited warranty. Please refer to the warranty card included in your package or contact customer support for detailed terms and conditions.

11. Kundesupport

For technical assistance, product inquiries, or warranty claims, please contact NIIMBOT customer support:

• Support e-mail: service@niimbot.com
• Officiel Webwebsted: www.niimbot.com
