Carpuride W903S Trådløst Bærbart Carplay Android Auto System Brugsanvisning

1. Introduktion

This manual provides detailed instructions for the installation, operation, and maintenance of your Carpuride W903S Wireless Portable Carplay Android Auto System. Please read this manual thoroughly before use to ensure proper functionality and safety.

The Carpuride W903S is a portable car display unit that integrates wireless Apple CarPlay and Android Auto. It features a high-definition IPS screen and a multi-camera system including a 4K front camera, 1080p rear camera, and 1080p infrared camera. The image shows the main unit with its display, along with included accessories like mounting brackets, a 64GB SD card, and the rear camera.

2. Produktfunktioner

• Trådløs CarPlay og Android Auto: Seamless integration with iOS 6+ and Android 11+ devices.
• HD IPS Display: 1600 x 600 pixel resolution for clear visuals.
• Multi-Camera System: Includes a 4K front camera, 1080p rear camera, and 1080p infrared camera.
• Loop-optagelse: Automatic recording with a 64GB TF card included.
• G-sensor: Built-in gravity sensor for automatic video locking during sudden impacts.
• Stemmestyring: Supports Siri and Android voice assistants for navigation, calls, and music.
• Lyssensor: Justerer automatisk skærmens lysstyrke baseret på det omgivende lys.
• Flere lydudgangstilstande: Built-in speaker, Bluetooth audio, FM transmitter, and AUX output.
• Wireless Mirrorlink: Screen mirroring for compatible applications (Note: Some streaming services like Netflix/Amazon Prime may not support mirroring due to copyright).
• Universal kompatibilitet: Powered by a 12V Type-C cigarette lighter cable, compatible with 12-24V vehicles.

3. Installationsvejledning

3.1 Pakkens indhold

• 1x W903S Car Radio Unit
• 1x bagkamera
• 1x 64GB TF-kort
• 1x billader
• 1x AUX -kabel
• 1x brugermanual
• 1x Sugekopmontering
• 1x Adhesive Mount

3.2 Montering af enheden

Vælg en passende placering på dit instrumentbræt eller din forrude, der ikke blokerer for din view.

1. Attach the chosen mount (suction cup or adhesive) to the W903S unit.
2. Securely attach the unit to your desired location.

3.3 Strømtilslutning

Connect the provided Type-C 12V car charger to the W903S unit and plug the other end into your vehicle's cigarette lighter socket.

Vigtig: Use only the original Carpuride car charger to ensure optimal performance, especially for FM transmission.

3.4 Kamerainstallation

3.4.1 front kamera

The 4K front camera is integrated into the main unit. It can be rotated 350 degrees for optimal viewing. Avoid excessive rotation to prevent cable damage.

3.4.2 Rear Camera (1080p)

Install the rear camera at the back of your vehicle.

Note: The red wire of the rear camera does not need to be connected to your car's reverse lights. Simply connect the black wire to the AV IN port on the W903S. To display the rear camera image, press the "R" button on the original car charger.

This diagram shows the rear camera connecting to the AV IN port of the W903S unit. It explicitly states that the red wire of the rear camera does not need to be connected to the car's reverse lights. The image also highlights the 'R' button on the car charger, which is used to activate the rear camera view.

3.4.3 Infrared Camera (1080p)

The infrared camera is designed for interior vehicle monitoring. Rotate it towards the car's interior.

Forsigtighed: Avoid direct exposure to window glass or other smooth surfaces, as this can cause reflections and image flickering. For best performance, use it only for recording scenes inside the car.

4. Betjeningsvejledning

4.1 Tænd/sluk

The unit powers on automatically when the vehicle's ignition is turned on (if connected to a switched power source) and powers off when the ignition is off.

4.2 Trådløs CarPlay / Android Auto-forbindelse

This image displays the different wireless connectivity options: Apple CarPlay, Android Auto, and MirrorLink. It shows how a smartphone connects wirelessly to the Carpuride W903S to display these interfaces, enabling navigation, music, and communication features.

1. Sørg for, at Bluetooth og Wi-Fi er aktiveret på din smartphone.
2. On the W903S, select either "CarPlay" or "Android Auto" from the main menu.
3. Follow the on-screen prompts to pair your phone. Once paired, the system will automatically connect in the future.
4. Compatible with iOS 6+ and Android 11+.

4.3 Mirrorlink Function

The W903S supports wireless Mirrorlink to display your phone's content.

1. Download the corresponding EveLink App based on your phone model.
2. Select "Mirrorlink" on the W903S.
3. Follow the app instructions to establish the connection.

Note: Due to copyright restrictions, some applications like Netflix and Amazon Prime Video may not support screen mirroring.

4.4 Multi-Camera Operation

This image illustrates the multi-camera capabilities of the W903S, showing split-screen views from the 4K front camera, 1080p infrared camera (for interior view), and 1080p rear camera. Icons for loop recording, locked video, video playback, 64GB SD card, night vision, and adjustable reversing lines are also visible.

The W903S simultaneously records from the front, rear, and infrared cameras.

• Front Camera (4K): Registrerer vejen forude.
• Rear Camera (1080p): Giver en view of the area behind the vehicle, useful for parking and reversing. Activated via the "R" button on the car charger.
• Infrared Camera (1080p): Monitors the vehicle's interior, useful for observing passengers.

4.5 Loop-optagelse og G-sensor

The system automatically records video in a loop, overwriting the oldest files when the 64GB TF card is full.

The built-in G-sensor detects sudden vibrations or collisions and automatically locks the current video segment to prevent it from being overwritten.

4.6 Lydudgangstilstande

• Indbygget højttaler: Audio plays directly from the W903S unit.
• Bluetooth lyd: Connect your phone to your car's Bluetooth system. Audio from CarPlay/Android Auto will play through your car speakers.
• FM Transmitter: Tune your car radio to the same FM frequency (87.5 MHz to 108 MHz) selected on the W903S to transmit audio wirelessly.
• AUX udgang: Connect the provided 3.5mm AUX cable from the W903S to your car's AUX input for wired audio transmission.

5. Pleje og vedligeholdelse

• Rensning: Brug en blød, tør klud til at rengøre skærmen og enheden. Undgå slibende rengøringsmidler eller opløsningsmidler.
• Temperatur: Do not expose the unit to extreme temperatures (hot or cold) for extended periods.
• Kabelstyring: Ensure all cables are securely routed and not pinched or damaged.
• TF-kort: Periodically check the TF card for errors and format it if necessary (this will erase all data). Back up important recordings regularly.

6. Fejlfindingsvejledning

Enheden tænder ikke.

Check the car charger connection and ensure the vehicle's cigarette lighter socket is receiving power. Confirm the original Carpuride charger is used.

CarPlay/Android Auto not connecting wirelessly.

Ensure Bluetooth and Wi-Fi are enabled on your phone. Verify your phone's operating system (iOS 6+ or Android 11+) is compatible. Try restarting both the W903S and your phone.

No audio from car speakers.

Check your selected audio output mode (Bluetooth, FM, AUX). If using FM, ensure the W903S and car radio are on the same frequency. If using AUX, ensure the cable is properly connected to both the W903S and your car's AUX input.

Rear camera image not displaying.

Ensure the black wire of the rear camera is connected to the AV IN port on the W903S. Press the "R" button on the car charger to activate the rear view.

Infrared camera image flickering or showing reflections.

Reposition the infrared camera to avoid direct exposure to window glass or other reflective surfaces. It is optimized for interior recording.

Screen brightness is too low/high.

The light sensor automatically adjusts brightness. You can customize the auto-brightness range in the settings.

Mirrorlink not working for certain apps.

Some streaming services (e.g., Netflix, Amazon Prime) restrict screen mirroring due to copyright protection. This is normal behavior.

7. Tekniske specifikationer

8. Garanti og kundesupport

For warranty information or technical assistance, please contact Carpuride customer support. Refer to the contact details provided with your purchase or visit the official Carpuride webwebsted.

Note: Software updates are not guaranteed beyond the initial release. Spare parts availability information is not available.
