NGTeco N3 Portable Monitor User Manual

1. Introduktion

Thank you for choosing the NGTeco N3 Portable Monitor. This manual provides essential information for setting up, operating, and maintaining your new monitor. Please read it thoroughly to ensure optimal performance and longevity of your device.

Nøglefunktioner:

• 16-inch 1200P FHD Display: Enjoy crisp visuals with a 1920x1200 resolution and a 16:10 aspect ratio.
• Ultratyndt og bærbart design: Designed for ease of transport and use in various environments.
• Bred kompatibilitet: Connects to laptops, PCs, Macs, phones, Xbox, Switch, and PS4/PS5 via USB-C or HDMI.
• Integrerede højttalere: Provides audio output without external devices.
• Smart Cover: Offers protection and functions as a stand.

Image: The NGTeco N3 Portable Monitor in use, showcasing its display capabilities alongside a laptop.

2. Opsætning og tilslutning

Follow these steps to connect your NGTeco N3 Portable Monitor to your device.

2.1 Pakkens indhold

Før du fortsætter, skal du sørge for, at alle varer er til stede i din pakke:

Image: A visual representation of the items included in the NGTeco N3 Portable Monitor package.

1. Bærbar skærm
2. Beskyttende ærme
3. Brugervejledning (dette dokument)
4. Aftagelig fod
5. USB-C til USB-C kabel
6. USB-A til USB-C kabel
7. HDMI til Type-C-kabel

2.2 Tilslutning af skærmen

The NGTeco N3 monitor supports two primary connection methods:

Image: Visual guide illustrating the two primary methods for connecting the NGTeco N3 Portable Monitor.

2.3 Compatibility Notes for MacBooks (M1/M2/M3 Chips)

For MacBooks equipped with M1, M2, or M3 chips, dual-screen functionality may require an H5 hub (if not included) and specific driver installation. If you encounter issues with one screen working, no signal, or screen flickering, these are often compatibility-related and can be resolved by ensuring proper drivers and accessories are used. Please refer to NGTeco Support for detailed instructions and assistance.

2.4 Using the Detachable Stand

The monitor includes a detachable stand for flexible positioning. The stand allows for 360-degree rotation and adjustable angles for both horizontal (25-80 degrees) and vertical (20-89 degrees) display modes. You may hear a gear sound when adjusting the bracket, which is normal.

Image: Instructions for installing and adjusting the detachable stand, highlighting its rotational and angle capabilities.

3. Betjening af monitoren

3.1 Basic Display Functions

Once connected, your NGTeco N3 monitor will function as an external display. You can configure display settings (e.g., extend, duplicate, primary display) through your operating system's display settings.

Image: Key display specifications of the NGTeco N3 monitor, including resolution, brightness, and refresh rate.

3.2 On-Screen Display (OSD) menu

The monitor features an OSD menu for adjusting various settings such as brightness, contrast, color temperature, input source, and audio volume. Access the OSD menu using the physical buttons on the monitor (refer to the monitor's physical layout for button locations).

3.3 Enhanced Productivity

Utilize the NGTeco N3 as a second monitor to enhance your workflow, providing additional screen real estate for multitasking, content creation, or presentations.

Image: A comparison illustrating how adding an external monitor can improve work efficiency and collaboration.

3.4 Spil og underholdning

The monitor's 1200P IPS display and 60Hz refresh rate provide a suitable experience for gaming and multimedia consumption. Connect your gaming consoles (Xbox, Switch, PS4/PS5) for an expanded view.

Image: A user engaging in gaming on the NGTeco N3 portable monitor with game controllers.

3.5 Mobile Device Projection

For compatible smartphones with full-featured USB-C ports, you can project your phone's screen onto the NGTeco N3 monitor, transforming it into a larger display for apps, videos, or presentations.

Image: Demonstrating the ability to cast a mobile phone screen to the NGTeco N3 monitor for a larger viewoplevelse.

4. Vedligeholdelse

Proper care ensures the longevity and performance of your NGTeco N3 Portable Monitor.

4.1 Rengøring af skærmen

• Always power off the monitor and disconnect it from the power source before cleaning.
• Brug en blød, fnugfri klud (f.eks. en mikrofiberklud) til forsigtigt at tørre skærmen af.
• For genstridige mærker, gnid letampRengør kluden med vand eller en skærmspecifik rengøringsopløsning. Sprøjt ikke væske direkte på skærmen.
• Avoid using harsh chemicals, abrasive cleaners, or alcohol-based solutions, as these can damage the screen coating.

4.2 Generel pleje

• Keep the monitor away from direct sunlight, excessive heat, and humidity.
• Avoid placing heavy objects on the monitor or applying pressure to the screen.
• When transporting, use the provided protective sleeve to prevent scratches and impacts.
• Sørg for korrekt ventilation omkring skærmen for at forhindre overophedning.

5. Fejlfinding

If you encounter issues with your NGTeco N3 Portable Monitor, refer to the following common solutions:

5.1 Intet signal / Sort skærm

• Tjek kabler: Ensure all cables (USB-C, HDMI, power) are securely connected to both the monitor and your device.
• Strømkilde: Verify the monitor is receiving adequate power. If using HDMI, ensure the USB power cable is connected to a sufficient power source.
• Inputkilde: Use the OSD menu to manually select the correct input source (e.g., USB-C, HDMI).
• Enhedsudgang: Confirm your connected device is configured to output video to an external display. Try restarting your device.
• Compatibility (MacBooks M1/M2/M3): If using a MacBook with M1/M2/M3 chips, ensure any required H5 hub is connected and drivers are installed.

5.2 Screen Flickering / Unstable Display

• Kabelkvalitet: Try using a different, high-quality USB-C or HDMI cable.
• Strømforsyning: Ensure the monitor is receiving stable power. If powered by a laptop's USB port, try connecting to a dedicated wall adapter.
• Opdateringshastighed: Check your device's display settings to ensure the refresh rate is set appropriately (e.g., 60Hz).
• Driver opdateringer: Ensure your device's graphics drivers are up to date.

5.3 No Audio / Low Volume

• Skærmvolumen: Adjust the volume through the monitor's OSD menu.
• Enhedsvolumen: Check the audio output settings on your connected device and ensure the volume is not muted or too low.
• Output enhed: Confirm that the NGTeco monitor is selected as the audio output device in your operating system's sound settings.

5.4 One Screen Working (for dual-screen setups)

• MacBook M1/M2/M3: As noted in the setup section, specific hubs and drivers may be required for dual-screen functionality on these MacBooks.
• Skærmindstillinger: Ensure your operating system's display settings are configured to 'Extend' or 'Duplicate' displays, and that both monitors are detected.
• Kabelforbindelser: Double-check that both monitors are correctly connected and receiving power.

If these steps do not resolve your issue, please contact NGTeco Support for further assistance.

6. Specifikationer

7. Garanti og support

7.1 Garantioplysninger

For detailed information regarding the warranty period and terms for your NGTeco N3 Portable Monitor, please refer to the warranty card included with your product or visit the official NGTeco webwebsted. Gem din købsbevis til garantikrav.

7.2 Kundesupport

If you require technical assistance, have questions about your product, or need to report an issue, please contact NGTeco Customer Support. You can typically find contact information on the NGTeco webwebstedet eller i din produktemballage.

NGTeco Support: Visit the NGTeco Store on Amazon
