DEERC Amphibious Remote Control Car (Model US-2624) User Manual

1. Introduktion

Thank you for choosing the DEERC Amphibious Remote Control Car, Model US-2624. This manual provides essential information for the safe operation, setup, and maintenance of your new RC car. Please read it thoroughly before use to ensure optimal performance and longevity of the product.

2. Hvad er der i æsken

Bekræft at alle komponenter er til stede i pakken:

• 1 x RC Amphibious Truck
• 1 x fjernbetjening
• 2 x genopladelige batterier (til bil)
• 4 x Amphibious Tires (pre-installed or spare)
• 1 x ladekabel

3. Sikkerhedsoplysninger

To prevent injury or damage, please observe the following safety guidelines:

• Children under 8 years old require adult supervision during operation.
• Brug ikke fjernstyrede biler i nærheden af ​​mennesker, kæledyr eller forhindringer.
• Avoid operating in public roads or areas with vehicle traffic.
• Ensure the battery compartment is securely sealed before water play.
• Nedsænk ikke fjernbetjeningen i vand.
• Brug kun det medfølgende opladningskabel og batterier.
• Forsøg ikke at modificere produktet eller dets komponenter.

4. Opsætning

4.1 Batteriopladning

1. Connect the included charging cable to a USB power source (e.g., computer, USB wall adapter).
2. Tilslut batteriet til ladekablet.
3. Allow the battery to charge fully. The charging indicator will typically change color or turn off when complete.
4. Hold altid batterierne under opladning.

4.2 Montering af bilbatteri

The DEERC Amphibious RC Car uses a magnetic shell for easy battery access.

1. Gently lift the top shell of the car, which is held by magnets.
2. Find batterirummet.
3. Insert a fully charged battery into the compartment and connect it to the car's power connector.
4. Sørg for, at forbindelsen er sikker.
5. Replace the top shell, ensuring it snaps into place magnetically.

4.3 Installation af batteri i fjernbetjening

The remote control typically requires 2x AA batteries (not included).

1. Åbn batterirummet på bagsiden af ​​fjernbetjeningen.
2. Insert 2 new AA batteries, observing the correct polarity (+/-).
3. Luk batterirummet forsvarligt.

4.4 Parring af bil og fjernbetjening

1. Ensure both the car and remote control have fresh or fully charged batteries installed.
2. Turn on the RC car using its power switch.
3. Tænd for fjernbetjeningen.
4. The indicator light on the remote will typically flash and then become solid once pairing is successful.
5. If pairing fails, turn both devices off and repeat the steps.

5. Betjeningsvejledning

The DEERC Amphibious RC Car is designed for versatile operation on various terrains and in water.

5.1 Grundlæggende kontroller

Refer to the remote control diagram for specific button functions:

• Venstre joystick: Controls forward/backward movement and left/right steering.
• Højre joystick: Controls 360° rotation and other stunt maneuvers.
• Auto Demo Button: Activates an automatic demonstration sequence.
• TÆND/SLUK -kontakt: Strømforsyner fjernbetjeningen.

5.2 Amphibious Operation

This RC car is designed to operate on both land and water. Its waterproof construction allows for seamless transitions.

• Land Mode: Drive on various surfaces including grass, sand, and pavement. The 4WD system provides excellent traction.
• Vandtilstand: The unique wheel design allows the car to propel itself through shallow water, making it suitable for pools or puddles. Ensure the battery compartment is sealed before entering water.

5.3 Stunt Functions

The car is capable of performing various stunts:

• 360° spins: Use the right joystick to execute rapid 360-degree rotations.
• All-Direction Drift: The specialized wheels enable sideways and diagonal movement for dynamic drifting.

6. Vedligeholdelse

6.1 Rengøring

• After each use, especially after water play, wipe the car thoroughly with a dry cloth to remove water, dirt, or debris.
• Ensure all water is drained from the car's interior and exterior to prevent corrosion.
• Brug ikke skrappe kemikalier eller opløsningsmidler til rengøring.

6.2 Batteripleje og -opbevaring

• Always disconnect batteries from the car and remote when not in use.
• Opbevar batterier et køligt, tørt sted, væk fra direkte sollys og ekstreme temperaturer.
• Undlad at overoplade eller overaflade batterier.
• Hvis batterierne opbevares i længere perioder, skal de oplades til cirka 50% kapacitet.

6.3 Generel opbevaring

• Store the RC car and remote control in a dry environment.
• Holdes væk fra støv og fugt.

7. Fejlfinding

If you encounter issues with your DEERC Amphibious RC Car, refer to the following common problems and solutions:

If the problem persists after trying these solutions, please contact DEERC customer support.

8. Specifikationer

9. Garanti og support

For warranty information or technical support, please refer to the contact details provided with your product packaging or visit the official DEERC website. Please have your model number (US-2624) and purchase details ready when contacting support.
