Philips 14T5HE/46-850/IF1/G/DIM 14W T5 LED-pære brugermanual

Indledning

This manual provides essential instructions for the safe and efficient installation, operation, and maintenance of your Philips 14T5HE/46-850/IF1/G/DIM 14W T5 LED Bulb. Please read this manual thoroughly before use and retain it for future reference.

This LED bulb is designed as a direct replacement for traditional 4-foot T5 High Efficiency (HE) 28W fluorescent lamps and requires an electronic ballast for operation. It is a Plug & Play solution, ensuring compatibility with specific existing fixtures.

Vigtige sikkerhedsoplysninger

ADVARSEL: Only use to replace 4' T5 HE (High Efficiency) 28W lamps (not HO lamps).
Verify ballast type (28W T5 HE Ballasts) before installation.
Check ballast compatibility before using this product. Incompatible ballasts may cause improper operation or damage to the bulb.
Always disconnect power before installation or removal.
Pæren må ikke skilles ad eller ændres.
Ensure the bulb is securely seated in the fixture.
This product is designed for indoor use in dry locations unless otherwise specified by the fixture.

Billedbeskrivelse: A yellow warning label with black text. The text states: "WARNING Only used to replace 4' T5 HE (High Efficiency) 28W lamps (not HO lamps). Verify ballast type (28W T5 HE Ballasts) before installation. Check ballast compatibility before using product." Below the English text, the same warning is provided in French.

Pakkens indhold

Your package contains 10 Philips 14T5HE/46-850/IF1/G/DIM 14W T5 LED Bulbs.

Packaging for Philips T5 LED bulbs, showing a pack of 10

Billedbeskrivelse: A close-up of the product packaging, indicating a "10_pack" of Philips LED tubes. The image shows the end of a box with a label confirming it contains 10 lamps.

Opsætning og installation

Strømafbrydelse: Før installationen påbegyndes, skal du sørge for, at strømforsyningen til armaturet er helt afbrudt ved afbryderen.
Bekræft ballastkompatibilitet: Confirm that your existing fixture uses a compatible 28W T5 High Efficiency (HE) electronic ballast. This LED bulb is a Plug & Play type and requires an electronic ballast. It is compatible with GE F28W/T5/850/Eco and Philips F28T5/850/Alto bulbs.
Fjern eksisterende Lamp: Carefully remove the old fluorescent T5 lamp fra armaturet.
Installer LED-pære: Insert the Philips 14T5HE/46-850/IF1/G/DIM LED bulb into the fixture's G5 bi-pin sockets. Ensure both pins on each end are fully seated.
Sikker installation: Gently twist the bulb if necessary to ensure it is firmly in place and making proper electrical contact.
Gendan strøm: Når pæren er sikkert installeret, skal du genoprette strømmen til armaturet ved afbryderen.
Test drift: Turn on the light switch to verify the LED bulb is functioning correctly.

Billedbeskrivelse: Et nærbillede view of the end of a Philips LED tube, showing the G5 bi-pin base. The label on the bulb indicates "TYPE A LAMP" and "Use only with electronic ballasts."

Betjeningsvejledning

The Philips 14T5HE/46-850/IF1/G/DIM LED bulb operates as a direct replacement for compatible T5 fluorescent lamps. Once installed in a fixture with a compatible electronic ballast and power is supplied, the bulb will illuminate when the fixture's switch is turned on.

Dæmpbar funktionalitet: This bulb is dimmable, provided the existing electronic ballast and dimmer switch are compatible with dimmable T5 LED lamps. Consult your ballast and dimmer specifications for compatibility.
Øjeblikkelig tændt: Unlike some fluorescent lamps, this LED bulb provides instant full brightness upon switching on, with no warm-up time.

Opretholdelse

Philips LED bulbs are designed for long-term, maintenance-free operation. Minimal maintenance is required.

Rensning: Ensure power is disconnected before cleaning. Gently wipe the bulb with a soft, dry, or slightly damp klæde. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
Udskiftning: When the bulb reaches the end of its operational life, replace it with another compatible Philips 14T5HE/46-850/IF1/G/DIM LED bulb. Follow the installation steps outlined in the "Setup and Installation" section.

Fejlfinding

Problem	Mulig årsag	Løsning
Pæren lyser ikke.	Ingen strøm til armaturet. Pæren er ikke korrekt sat i. Incompatible or faulty electronic ballast. Defekt pære.	Kontroller afbryderen og vægafbryderen. Ensure bulb pins are fully inserted into sockets. Verify ballast compatibility. If incompatible or faulty, replace the ballast. Test with a known working bulb.
Pæren flimrer eller dæmpes uventet.	Incompatible or failing electronic ballast. Løs forbindelse. Inkompatibel lysdæmper (hvis relevant).	Verify ballast compatibility and condition. Sørg for, at pæren sidder sikkert fast. Confirm dimmer switch is compatible with dimmable T5 LED lamps.

Specifikationer

Modelnavn:	14T5HE/46-850/IF1/G/DIM
Varenummer:	476523
Mærke:	Signify (Philips)
Lystype:	LED
Wattage:	14 watt
Equivalent Fluorescent:	28W T5 HE (High Efficiency)
Pære base:	G5 Bi-Pin
Farvetemperatur:	5000 Kelvin
Voltage:	120 Volts (Ballast Dependent)
Speciel funktion:	Dimmable (with compatible ballast/dimmer), Plug & Play
Længde:	46 tommer
Materiale:	Plast
Item Weight (per 10-pack):	20 pund
GTIN:	50046677476521

Philips T5 LED bulb with specifications printed on it

Billedbeskrivelse: A close-up of the Philips LED tube, showing detailed specifications printed on the bulb itself. Information visible includes "14T5HE/46-850/IF1/G/DIM", "Use only with electronic ballasts", model numbers, and compliance marks like UL and RoHS.

Garanti og support

For warranty information or technical support regarding your Philips LED bulb, please refer to the official Signify (Philips) webwebstedet eller kontakt deres kundeservice direkte. Behold din købskvittering som købsbevis.

Fabrikant: Philips (Signify)

Varenummer: 476523
