eLinkSmart Fingerprint Padlock YL-P8bf-Purple User Manual

1. Introduktion

Thank you for choosing the eLinkSmart Fingerprint Padlock. This smart padlock offers a convenient and secure keyless solution for various indoor applications. With advanced biometric technology and smartphone app integration, you can manage access with ease. This manual provides detailed instructions to help you set up, operate, and maintain your new padlock.

2. Produktet er slutview

The eLinkSmart Fingerprint Padlock is a compact and lightweight security device designed for personal lockers, toolboxes, cases, chests, and cabinets. It features a zinc alloy body and a stainless steel shackle for durability. Key features include fingerprint unlocking, app-based authorization management, and long battery life.

Figure 1: eLinkSmart Fingerprint Padlock (Lavender Purple)

Figure 2: Padlock demonstrating its compact size when held

3. Opsætning

3.1 Indledende opladning

Before first use, fully charge the padlock using the provided USB charging cable. The padlock supports 6 months of standby time or over 2000 unlocks on a full charge. A red light or app voice prompt will indicate low battery.

Figure 3: Padlock connected to a USB charging cable

3.2 Download og parring af app

1. Scan the QR code in the included User's Manual or search for the 'eLinkSmart' app in your device's app store (iOS/Android).
2. Installer og åbn appen.
3. Sørg for, at din telefons Bluetooth er aktiveret.
4. In the app, select 'Add Device' or similar option. The app will detect the padlock via Bluetooth.
5. Follow the on-screen prompts to bind the padlock to your account. The padlock's indicator light will flash blue during pairing.

3.3 Registrering af fingeraftryk

The padlock can store up to 20 different fingerprints, including 2 admin fingerprints. Only admin users can reset or manage fingerprints.

1. In the eLinkSmart app, navigate to 'Fingerprint Management'.
2. Select 'Add Fingerprint' and follow the on-screen instructions.
3. You will be prompted to place your finger on the padlock's sensor multiple times from different angles to ensure accurate registration.
4. Once successfully registered, the app will confirm.

Figure 4: Screenshot of the eLinkSmart app interface for managing the padlock.

4. Betjening af hængelåsen

4.1 Lås op med fingeraftryk

To unlock the padlock using your fingerprint:

1. Placer en registreret finger på fingeraftrykssensoren.
2. The padlock will unlock in approximately 0.1 seconds if the fingerprint is recognized.

4.2 App Unlock

To unlock the padlock using the eLinkSmart app:

1. Ensure your phone's Bluetooth is on and the padlock is within range.
2. Open the eLinkSmart app.
3. Select the padlock from your device list.
4. Tap the 'Unlock' button within the app. The padlock will open.

4.3 Låsning af hængelåsen

To lock the padlock, simply push the shackle down into the lock body until it clicks into place. No fingerprint or app interaction is needed to lock it.

5. Vedligeholdelse

5.1 Opladning

Recharge the padlock using the provided USB cable when the low battery indicator (red light or app prompt) appears. A full charge typically takes about 40 minutes and provides power for approximately 6 months of standby or 2000 unlocks.

5.2 Rengøring

Keep the fingerprint sensor clean and dry for optimal performance. Use a soft, dry cloth to wipe the sensor if needed.

6. Fejlfinding

• Fingeraftryk ikke genkendt: Ensure your finger is clean and dry. Try placing your finger on the sensor from different angles. If issues persist, delete and re-register your fingerprint in the app.
• App not connecting to padlock: Verify that Bluetooth is enabled on your smartphone and the padlock is within range. Try restarting the app or your phone. If necessary, reset the padlock and re-pair it with the app.
• Padlock not responding: The battery might be low. Connect the padlock to a power source using the USB charging cable.
• Difficulty registering fingerprints via app: If the app fails on the final step of fingerprint registration, try renaming the user name for the prints. Some users have found this resolves the issue.

7. Specifikationer

8. Garanti og support

For warranty information and technical support, please refer to the contact details provided with your product packaging or visit the official eLinkSmart webwebsted. Gem din købskvittering i tilfælde af garantikrav.
