VTOMAN FlashSpeed ​​1000 bærbar kraftstation brugermanual

1. Introduktion

The VTOMAN FlashSpeed 1000 is a portable power station designed to provide reliable power for various applications, including home backup, outdoor activities, camping, and emergency situations. Featuring an 828Wh LiFePO4 battery and a 1000W (2000W peak) pure sine wave AC output, it offers versatile power solutions. This manual provides essential information for safe and efficient operation of your device.

2. Sikkerhedsinstruktioner

• Enheden må ikke skilles ad, repareres eller ændres. Forkert samling kan forårsage brand eller personskade.
• Udsæt ikke enheden for ild eller ekstreme temperaturer (over 60 °C/140 °F).
• Brug eller opbevar ikke enheden i badeværelser eller områder, der er udsat for vand eller regn.
• Brug kun godkendt tilbehør og opladere.
• Sørg for tilstrækkelig ventilation under brug og opladning for at forhindre overophedning.
• Hold enheden væk fra børn og kæledyr.
• Undgå at tabe enheden eller udsætte den for kraftige stød.
• If the unit emits unusual odors, heat, or appears abnormal, discontinue use immediately and contact support.

Figur 2.1: Indre view highlighting the LiFePO4 battery and Battery Management System (BMS) for enhanced safety and durability.

3. Pakkens indhold

Bekræft at alle varer er inkluderet i din pakke:

• 1x VTOMAN FlashSpeed ​​1000 bærbar kraftstation
• 1x AC ladekabel
• 1x cigarettænderkabel til køretøj
• 1x USB-C til USB-C kabel
• 1x USB-A til Type-C-kabel
• 1x brugermanual

Figur 3.1: Contents of the VTOMAN FlashSpeed 1000 package.

4. Produktet er slutview

Familiarize yourself with the various components and ports of your FlashSpeed 1000 Portable Power Station.

Figur 4.1: Front view of the VTOMAN FlashSpeed 1000.

Figur 4.2: Port layout and functions.

4.1. Udgangsporte

• AC stikkontakter: 3x 110V/1000W (2000W Surge) Pure Sine Wave.
• USB-A porte: 4 ports total (2x 12W Max, 1x 18W Max).
• USB-C porte: 2 ports, up to 100W Max.
• DC5521 udgangsporte: 2 ports, 12V/10A.
• Bilens cigarettænderport: 1 port, 12V/10A.

4.2. Input Ports

• AC-indgangsport: For fast wall charging.
• Anderson Input Port: For solar panel charging (10-50V, up to 300W).
• Bilopladningsindgang: Via vehicle cigarette lighter cable.

4.3. Special Ports

• Ekstra batteriport: For connecting an external battery to expand capacity.
• Jumperkabelport: For car jump-starting functionality (jumper cables sold separately).

5. Opsætning

Før første brug anbefales det at oplade strømforsyningen helt.

1. Unpack the VTOMAN FlashSpeed 1000 and all accessories.
2. Tilslut AC-opladekablet til strømforsyningens AC-indgangsport og derefter til en stikkontakt.
3. The display will indicate charging status. Charge until the battery indicator shows 100%.

6. Betjeningsvejledning

6.1. Opladning af kraftværket

The FlashSpeed 1000 offers multiple charging methods:

• AC vægudtag: Connect the included AC charging cable directly to a wall outlet. The unit can recharge from 0-80% within 1 hour using its 1000W AC input.
• Solpaneler: Connect compatible solar panels (VTOMAN 110W/200W/400W recommended) to the Anderson input port. The unit supports up to 300W solar input (10-50V) and can be fully charged in 4-6 hours under optimal sunlight.
• Biloplader: Use the vehicle cigarette lighter cable to charge the unit from your car's 12V outlet. A full charge typically takes 7-8 hours.

Figur 6.1: Recharging the power station via wall outlet.

Figur 6.2: 12V car charging while driving.

Figur 6.3: Solar charging the power station.

6.2. Brug af udgangsporte

To use the output ports:

1. Tryk på hovedafbryderen for at tænde enheden.
2. Press the respective button (AC, DC, or USB) to activate the desired output section. The indicator light will illuminate.
3. Tilslut dine enheder til de relevante porte.
4. The power station supports pass-through charging, allowing you to charge your devices while the unit itself is being charged.

Figur 6.4: Powering multiple devices simultaneously.

6.3. V-BEYOND Technology (Constant Power)

The FlashSpeed 1000 features V-BEYOND Technology, which allows it to power devices requiring more than its rated 1000W output. When powering appliances over 1000W, the unit will provide a constant 1000W output instead of shutting down, offering an alternative emergency solution for devices like water heaters, space heaters, or ovens.

Figur 6.5: V-BEYOND Technology in action, powering a resistive load.

6.4. Expandable Capacity

The FlashSpeed 1000's capacity can be expanded from 828Wh to 2376Wh by connecting it to a VTOMAN FlashSpeed 1500 extra battery (sold separately). This significantly extends the running time for your essential devices and appliances. Note that connecting an extra battery will also double the total charging time.

Figur 6.6: Expandable capacity with an extra battery.

6.5. Funktion af afbrydelsesfri strømforsyning (UPS)

When connected to an AC wall outlet and powering devices, the FlashSpeed 1000 can function as an Uninterruptible Power Supply (UPS). In the event of a power outage, it seamlessly switches to battery power in less than 20 milliseconds, ensuring continuous operation for connected devices like computers or medical equipment.

Figur 6.7: Seamless UPS transfer for uninterrupted power.

6.6. Car Jump Starter

The FlashSpeed 1000 can be used to jump-start cars, motorcycles, and ATVs. Connect appropriate jumper cables (sold separately) to the dedicated jumper cable port on the power station and then to your vehicle's battery terminals. The unit can help start your vehicle in approximately 3 seconds.

Figur 6.8: Using the FlashSpeed 1000 as a car jump starter.

7. Vedligeholdelse

Korrekt vedligeholdelse sikrer dit kraftværks levetid og optimale ydeevne.

• Batterilevetid: The LiFePO4 battery is designed for over 3000 charge cycles before its capacity degrades to 80% of its original state, offering a lifespan of 10+ years with proper care.
• Opbevaring: Opbevar enheden et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer. Ved langtidsopbevaring skal enheden oplades til 50-80% hver 3.-6. måned.
• Rensning: Brug en tør, blød klud til at rengøre enhedens yderside. Brug ikke flydende rengøringsmidler, og enheden må ikke nedsænkes i vand.
• Ventilation: Ensure the ventilation openings are clear of dust and debris to maintain proper airflow.

Figur 7.1: LiFePO4 battery and BMS for long-term safety and performance.

8. Fejlfinding

If you encounter issues with your FlashSpeed 1000, refer to the following common solutions:

• Enheden tænder ikke: Ensure the battery is charged. Press and hold the main power button for a few seconds.
• Ingen output fra porte: Verify that the specific output section (AC, DC, USB) is activated by pressing its respective button. Check if the device connected is within the power station's output limits.
• Langsom opladning: Ensure the charging cable is securely connected. For solar charging, confirm panels are in direct sunlight and free from obstructions. Check solar panel voltage og nuværende.
• Overbelastningsbeskyttelse: If the unit shuts down due to overload, disconnect the high-power device, wait a few minutes, and restart the power station. Use V-BEYOND technology for devices slightly above 1000W.
• Skærm virker ikke: Prøv at genstarte enheden. Hvis problemet fortsætter, skal du kontakte kundesupport.

9. Specifikationer

10. Garanti og support

10.1. Garantioplysninger

VTOMAN FlashSpeed ​​1000 bærbar kraftstation leveres med en 2-Year Service AgreementDerudover en 30-Day Easy Return policy is offered for eligible purchases.

10.2. Kundesupport

For technical assistance, warranty claims, or any questions regarding your product, please contact VTOMAN customer support through their official webwebstedet eller kontaktoplysningerne i din købsdokumentation.
