Brugermanual til Comfytemp varmepude

1. Introduktion

Thank you for choosing the Comfytemp Heating Pad. This product is designed to provide soothing heat therapy for your neck, shoulders, and back, offering comfort and relief from muscle aches and stiffness. The cordless design of the portable unit ensures flexibility and convenience for use anywhere. Please read this manual thoroughly before use to ensure safe and effective operation.

2. Vigtige sikkerhedsinstruktioner

Ved brug af elektriske apparater skal grundlæggende forholdsregler altid følges for at reducere risikoen for brand, elektrisk stød og personskade, herunder følgende:

• GØR IKKE bruge, mens du sover.
• GØR IKKE use on an infant or invalid or on a person who is asleep or unconscious.
• GØR IKKE use on sensitive skin or on a person with poor blood circulation.
• GØR IKKE use on areas of the body that are swollen, inflamed, or have open wounds. Consult a physician before use if you have any medical conditions.
• GØR IKKE use pins or other metallic means to fasten this pad.
• GØR IKKE sit on, lean against, or crush the pad.
• ALDRIG efterlad apparatet uden opsyn, især hvis der er børn til stede.
• GØR IKKE use with liniment, salve, or ointment preparations, as skin burns could result.
• GØR IKKE immerse the control or cord in water or other liquids.
• GØR IKKE use if the cord or plug is damaged.
• GØR IKKE use if the pad is wet.
• Opbevar puden et køligt og tørt sted, når den ikke er i brug.
• Opbevares utilgængeligt for børn.

3. Produktfunktioner

• Neck Shoulder Heating Pad (Wired): Large 19"x 23" design for optimal fit around neck, shoulders, and upper back. Can also be applied to abdomen and waist.
• Customizable Heat & Timer (Wired): Features 9 heat settings and 11 auto-off timers (0.5H to 9H) for personalized heat therapy and energy conservation.
• Cordless and Portable Heating Pad (Rechargeable): Offers freedom of movement for use at home, office, or while traveling. Features a sticky cloth and Velcro collar for flexible adjustment and micro glass beads for weighted comfort.
• Longer Battery Life (Cordless): Equipped with a 7.2V/5000mAh battery providing 3-8 hours of continuous use. Includes a portable 12V/2A DC charger.
• Adjustable Heat & Timer (Cordless): Provides 3 heat settings (104°F to 140°F) and 3 auto-off timers (15-30-60 minutes) to prevent low-temperature burns and conserve energy.

4. Opsætning og opladning

4.1 Wired Heating Pad Setup

1. Unpack the heating pad and controller.
2. Ensure the connector on the pad is securely plugged into the controller.
3. Sæt controllerens netledning i en almindelig stikkontakt.
4. Position the heating pad comfortably on your neck, shoulders, back, or other desired area.

Image: The wired heating pad with its controller and the separate cordless heating pad.

4.2 Cordless Heating Pad Charging

1. Locate the charging port on the cordless heating pad's battery unit.
2. Connect the provided 12V/2A DC charger to the charging port.
3. Sæt opladeren i en almindelig stikkontakt.
4. The battery indicator light will show charging status. Charge fully before first use.
5. A full charge typically provides 3-8 hours of continuous use depending on the heat setting.

Image: The battery unit of the cordless heating pad, highlighting its 3-8 hour usage time and 7.2V 5000mAh capacity.

5. Betjeningsvejledning

5.1 Wired Heating Pad Operation

1. Tænd: Tryk på tænd/sluk-knappen på controlleren for at tænde varmepuden.
2. Juster varmeindstilling: Use the temperature control buttons to select one of the 9 heat settings. Start with a lower setting and increase as desired.
3. Indstil timer for automatisk sluk: Press the timer button to cycle through the 11 auto-off timer options (0.5H, 1H, 1.5H, 2H, 3H, 4H, 5H, 6H, 7H, 8H, 9H). The pad will automatically shut off after the selected time.
4. Sluk: Press the power button again to turn off the heating pad. Unplug from the outlet when not in use.

Image: Close-up of the wired heating pad's controller, displaying its heat and timer settings.

5.2 Cordless Heating Pad Operation

1. Wear the Pad: Place the cordless heating pad around your neck and shoulders. Adjust the collar using the sticky cloth and Velcro for a comfortable and secure fit.
2. Tænd: Press and hold the power button on the control unit to turn on the heating pad.
3. Juster varmeindstilling: Press the heat setting button to cycle through the 3 available heat levels (Low, Medium, High).
4. Indstil timer for automatisk sluk: Press the timer button to select an auto-off duration (15, 30, or 60 minutes).
5. Indikator for lavt batteri: The indicator light will signal when the battery is low, prompting you to recharge.
6. Sluk: Press and hold the power button to turn off the heating pad.

Image: A woman wearing the cordless heating pad, illustrating its ease of use with indicators for 3 heat modes, 3 auto-off settings, and a low battery warning.

6. Vedligeholdelse og opbevaring

• Rensning: Disconnect the heating pad from the power source (and controller for wired pad) before cleaning. The fabric cover can typically be spot cleaned with a damp cloth and mild detergent. Do not machine wash or submerge the electrical components in water. Refer to the product label for specific cleaning instructions.
• Tørring: Allow the heating pad to air dry completely before storing or re-using.
• Opbevaring: Store the heating pad in a cool, dry place. Avoid folding tightly or placing heavy objects on top of it, which could damage the internal heating elements.

7. Fejlfinding

8. Specifikationer

• Mærke: Komfortabel temp
• Model: B0DP9FWVPP
• Wired Heating Pad Size: Approximately 19" x 23"
• Wired Heating Pad Heat Settings: 9 niveauer
• Wired Heating Pad Auto-Off Timers: 0.5H, 1H, 1.5H, 2H, 3H, 4H, 5H, 6H, 7H, 8H, 9H
• Cordless Heating Pad Battery: 7.2V/5000mAh
• Cordless Heating Pad Usage Time: 3-8 hours (depending on heat setting)
• Cordless Heating Pad Heat Settings: 3 levels (104°F to 140°F)
• Cordless Heating Pad Auto-Off Timers: 15, 30, 60 minutter
• Særlige funktioner: Cordless and Portable, Long Battery Life, Weighted design (cordless)
• Dato først tilgængelig: 29. november 2024

9. Garanti og support

For warranty information and customer support, please refer to the warranty card included with your product or visit the official Comfytemp website. You can also contact Comfytemp customer service directly for assistance with product inquiries, troubleshooting, or replacement parts.
