Brugervejledning til KOOSMILE Mini PC

1. Introduktion

This manual provides essential information for setting up, operating, and maintaining your KOOSMILE Mini PC. The Mini PC is a compact and powerful desktop computer designed for various tasks, including multitasking, work, streaming, and home entertainment. It features an Intel Core i9-12900HK processor, ample memory and storage, and versatile connectivity options.

2. Hvad er der i æsken

Kontroller venligst, at alle varer er til stede i pakken:

• 1 x KOOSMILE Mini PC
• 1 x HDMI-kabel
• 1 x strømadapter
• 1 x DisplayPort (DP) cable
• 1 x USB Hub
• 1 x Metal sheet bracket (for mounting)
• 1 x Brugermanual (dette dokument)

Image: The KOOSMILE Mini PC shown with its various ports and a view of the smart display. The image also depicts the compact size of the device.

3. Produktfunktioner

The KOOSMILE Mini PC is equipped with advanced features for optimal performance:

• Smart Display Monitoring: A built-in display on the lid shows real-time system information, including CPU frequency, usage, temperature, network activity (upload/download), and memory usage.
• Powerful Intel Core i9 CPU: Powered by the Intel Core i9-12900HK processor (14 cores, 20 threads, up to 5.0GHz) with 24 MB of cache, ensuring fast and responsive performance.
• Højhastighedshukommelse og -lagring: Comes with 32GB DDR4 RAM for quick boot-up and smooth operation, and a 2TB NVMe SSD for ample storage and fast data transfer.
• Understøttelse af tre skærme: Equipped with Intel Iris Xe Graphics, supporting up to three displays simultaneously via HDMI 2.1 (4K @ 60Hz), DP 1.4a (8K @ 60Hz), and Type-C (USB-C).
• Effektivt kølesystem: Features an advanced copper cooling fan and multiple vents for effective heat dissipation, maintaining stable performance.
• Faster Wireless Networking: Integrated WiFi 6 and Bluetooth 5.2 provide faster and more stable wireless connections.

Billede: Nærbillede view of the Mini PC's smart display, illustrating real-time monitoring of CPU frequency, usage, temperature, network speeds, and disk usage.

Image: Diagram illustrating the 32GB DDR4 high-speed memory and 2TB PCIe 3.0 SSD storage, highlighting their data transfer capabilities.

Image: A setup demonstrating the Mini PC's triple-screen expansion capability, showing three monitors connected for multitasking and increased productivity.

4. Opsætningsvejledning

Follow these steps to set up your KOOSMILE Mini PC:

1. Tilslut strøm: Connect the power adapter to the DC Port on the back of the Mini PC and plug it into a power outlet.
2. Tilslut skærm: Use the provided HDMI or DisplayPort cable to connect your monitor(s) to the corresponding ports on the Mini PC. Ensure the display device is connected before turning on the computer.
3. Tilslut ydre enheder: Tilslut dit tastatur, din mus og andre USB-enheder til de tilgængelige USB 3.0- eller USB 2.0-porte.
4. Netværks forbindelse: For a wired connection, connect an Ethernet cable to the RJ45 port. For wireless, the device supports WiFi 6.
5. Tænd: Tryk på tænd/sluk-knappen på forsiden af ​​Mini PC'en for at tænde den.

Billede: Detaljeret views of the Mini PC's front and rear ports, including USB 3.2, Type-C, Audio, HDMI, DisplayPort, RJ45, and DC power input, with labels for easy identification.

5. Betjeningsvejledning

Your KOOSMILE Mini PC comes pre-installed with Windows 11 Pro. Upon first boot, follow the on-screen instructions to complete the initial setup of the operating system.

• Smart Display Usage: The smart display on the lid provides real-time system metrics. You can monitor CPU frequency, usage, temperature, network speeds, and disk usage directly from this display.
• Multi-Display Konfiguration: To utilize the triple display support, connect up to three monitors using the HDMI, DisplayPort, and Type-C ports. Windows 11 allows you to configure display settings (extend, duplicate, or single display) through the Display Settings menu.
• Lagerstyring: The 2TB NVMe SSD offers substantial storage. If you need to adjust hard disk partition structures, guidance can be provided by customer support.

6. Specifikationer

Detailed technical specifications for the KOOSMILE Mini PC (Model: KT-M9):

7. Vedligeholdelse

For at sikre din mini-pc's levetid og optimale ydeevne, bør du overveje følgende vedligeholdelsestips:

• Køling: The advanced copper cooling fan and multiple vents are designed for efficient heat dissipation. Ensure proper airflow around the device and avoid blocking the vents.
• Rensning: Rengør regelmæssigt ydersiden af ​​Mini PC'en med en blød, tør klud. Undgå at bruge flydende rengøringsmidler direkte på enheden.
• Softwareopdateringer: Hold dit Windows-operativsystem og dine drivere opdaterede for at sikre systemstabilitet og sikkerhed.

Billede: En eksploderet view of the Mini PC's internal components, highlighting the metal matte finish, PCIe SSD storage, high-speed DDR4 memory, and the efficient cooling system with a silent copper fan.

8. Fejlfinding

If you encounter issues with your Mini PC, please refer to the following common solutions:

• Visningsproblemer: Ensure your HDMI device is connected before turning on the computer. Use the provided HDMI cable and avoid other adapter cables for HDMI connections to prevent compatibility issues.
• Driver kompatibilitet: To prevent potential compatibility problems, avoid installing third-party drivers unless specifically instructed by KOOSMILE support.
• Systemydelse: If the system feels slow, check the smart display for CPU usage and temperature. Ensure adequate ventilation and close unnecessary applications.
• Summende lyd: One user reported a buzzing sound that went away after restarting. If this persists, contact customer support.

9. Garanti og support

KOOSMILE offers a 1-year free warranty for this product. For any technical assistance, questions, or support needs, please reach out to our customer service team via email. Our team is dedicated to providing prompt and patient support.

Please refer to the contact information provided with your purchase or on the official KOOSMILE website for specific support channels.
