1. Introduktion
The Vantrue E360, E2 Rear Camera is an accessory designed to expand the recording capabilities of your existing Vantrue E360 or E2 dash camera system. This rear camera provides 2.7K Super HD video recording, offering enhanced clarity for capturing license plates and road signs from the rear of your vehicle. Equipped with STARVIS technology, WDR (Wide Dynamic Range), and an F1.8 fixed lens, it ensures superior performance even in low-light conditions. Its 160° wide-angle lens helps to minimize blind spots, providing comprehensive coverage for improved safety and peace of mind.
2. Hvad er der i æsken
Når du åbner pakken, skal du kontrollere, at alle følgende komponenter er inkluderet:
- Vantrue E360, E2 Rear Camera
- 20ft Extended Cable (USB-C to USB-C)
- Adhesive Mount with 3M Sticker
Image: The Vantrue E360, E2 Rear Camera, its 20ft extended cable, and an adhesive mount.
3. Opsætning og installation
The Vantrue E360, E2 Rear Camera is designed for straightforward installation. It connects directly to your Vantrue E360 or E2 front dash camera.
3.1 Mounting the Rear Camera
- Choose an optimal location on your rear windshield, typically at the top center, ensuring a clear view and avoiding obstruction from the defroster lines.
- Clean the chosen area thoroughly to ensure the adhesive mount adheres properly.
- Peel off the protective film from the 3M adhesive sticker on the camera mount.
- Firmly press the camera mount onto the cleaned area of the windshield for at least 30 seconds. Allow the adhesive to cure for a few hours before routing cables.
Image: Detail of the adhesive mount for the rear camera, showing its adjustable angle.
3.2 Tilslutning af kameraet
- Carefully route the 20ft extended cable from the rear camera along the vehicle's headliner, down the side pillars, and towards the location of your Vantrue E360 or E2 front dash camera. Tuck the cable neatly into the vehicle's trim for a clean installation.
- Connect one end of the extended cable to the rear camera and the other end to the designated rear camera port on your Vantrue E360 or E2 front dash camera.
- Once connected, the front dash camera should automatically detect the rear camera and begin recording simultaneously.
Image: Cable routing diagram for the rear camera installation.
Image: Rear camera installed on the vehicle's back window.
4. Betjeningsvejledning
The Vantrue E360, E2 Rear Camera operates in conjunction with your main Vantrue E360 or E2 dash camera. Once connected, it will automatically begin recording when the main unit is powered on.
4.1 2.7K Super HD Recording
The rear camera captures video at 2592x1944P resolution at 24 frames per second (FPS). This high resolution ensures that details such as license plates and road signs are clearly visible in the recorded footage. The 160° wide view angle provides extensive coverage of the area behind your vehicle.
Image: Visual comparison of 1080P vs. 2.7K Super HD recording quality.
4.2 Enhanced WDR and Super Night Vision
The camera features Enhanced WDR (Wide Dynamic Range) and Super Night Vision capabilities, powered by STARVIS technology and an F1.8 aperture lens. These technologies work together to optimize video quality in challenging lighting conditions, such as bright sunlight, tunnels, or low-light environments at night. This ensures that footage remains clear and detailed, capturing critical information regardless of the time of day or ambient light.
Image: Demonstration of Super Night Vision capabilities.
5. Vedligeholdelse
To ensure optimal performance and longevity of your Vantrue E360, E2 Rear Camera, follow these maintenance guidelines:
- Hold objektivet rent: Regularly wipe the camera lens with a soft, lint-free cloth to remove dust, smudges, or dirt that could affect video clarity.
- Tjek kabelforbindelser: Periodically inspect the connection between the rear camera and the main dash cam to ensure it is secure and free from damage.
- Montering af skærm: Ensure the adhesive mount remains firmly attached to the windshield. If it loosens, re-secure it or replace the adhesive.
- Softwareopdateringer: Check the Vantrue official website for any available firmware updates for your main E360/E2 dash cam, as these may include improvements for the rear camera's performance.
6. Fejlfinding
If you encounter issues with your Vantrue E360, E2 Rear Camera, refer to the following common problems and solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Rear camera not detected / No video feed | Loose cable connection; Incorrect port; Faulty cable. | Ensure the cable is securely plugged into both the rear camera and the main dash cam. Verify it's connected to the correct rear camera port. Try a different cable if available. |
| Blurry or unclear rear video | Dirty lens; Condensation on windshield; Camera not focused (unlikely for fixed lens). | Clean the camera lens and the area of the windshield where the camera is mounted. Ensure no obstructions are blocking the view. |
| Intermittent recording | Loose connection; SD card issues in main unit. | Check all cable connections. Ensure the main dash cam's SD card is functioning correctly and has sufficient space. |
If the problem persists after attempting these solutions, please contact Vantrue Customer Support for further assistance.
7. Specifikationer
| Feature | Detalje |
|---|---|
| Produktdimensioner | 2 x 1.7 x 1.2 tommer |
| Varens vægt | 6.1 ounce |
| Forbindelsesteknologi | USB |
| Speciel funktion | Automatic Incident Detection, Parking Monitor (features of main E360/E2 unit when connected) |
| Farve | Sort |
| Orientering | Bag |
| Type køretøjstjeneste | Bus, Car, Minivan, Truck |
| Videooptagelsesopløsning | 2.7K (2592x1944P) @ 24FPS |
| Monteringstype | Forrudemontering (klæbende) |
| Felt Af View | 160 grader |
8. Garanti og support
VANTRUE is committed to providing high-quality products and excellent customer service.
- Udvidet garanti: Enjoy an 18-month extended warranty on your product.
- Returpolitik: A 30-day return policy is available for your convenience.
- Kundesupport: Dedicated 24-hour customer support is available to assist you with any inquiries or issues.
For support, please contact us via:
- E-mail: support@vantrue.net
- Telefon: 510-666-4086
Image: Vantrue Warranty & Service information.
