Indledning
The LAUNCH Creader Elite V2.0 is a professional diagnostic scan tool designed specifically for Land Rover and Jaguar vehicles. This device offers comprehensive system diagnostics, bi-directional control, and a wide range of maintenance services. It is equipped with an improved Android 8.1 operating system, a 4-inch touchscreen, and a 3000mAh battery for efficient and smooth operation. This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your device.
1. Opsætning
1.1 Hvad er der i æsken
- 1 * LAUNCH Creader Elite V2.0 OBD2 Scanner for JLR
- 1 * OBD2 Diagnostic Cable
- 1 * Hurtig startvejledning
- 1 * Brugervejledning
1.2 Første opsætning og tænding
To begin using your LAUNCH Creader Elite V2.0, connect the OBD2 diagnostic cable to the device and then to your vehicle's OBD2 port. The device will typically power on automatically upon connection to the vehicle's power supply. Ensure your vehicle's ignition is in the ON position (engine off) for proper communication.
1.3 Softwareopdatering
The device supports lifetime free updates via Wi-Fi. It is recommended to regularly update the software to ensure access to the latest functions, bug fixes, and vehicle model support. To update, navigate to the "Upgrade" icon on the main screen and follow the on-screen instructions. A stable Wi-Fi connection is required.
Figure 1: LAUNCH Creader Elite V2.0 Main Interface. The "Upgrade" icon facilitates software updates via Wi-Fi.
2. Betjening af enheden
2.1 Diagnose af alle systemer på OE-niveau
The Creader Elite V2.0 provides in-depth diagnostics for all available electronic control modules in Land Rover and Jaguar vehicles. This includes, but is not limited to, Engine, ABS, SRS, Transmission, EPB, TPMS, and more. The device can automatically identify the vehicle's VIN and perform a comprehensive scan of all systems.
- Auto-Identify VIN: Automatically detects vehicle identification number for quick setup.
- Auto-Scan All Systems: Performs a complete scan across all modules to identify faults.
- Læs og ryd koder: Displays diagnostic trouble codes (DTCs) and allows for their clearing after repairs.
- View Live datastrøm: Shows real-time sensor data in various formats (text, waveform, graphic).
- Læs ECU-oplysninger: Accesses control unit details such as unit type and version numbers.
- Read Freeze Frame: Captures a snapshot of vehicle conditions when a fault occurs.
Figure 2: OE-Level All System Diagnosis. This image illustrates the comprehensive diagnostic capabilities across various vehicle systems.
2.2 Enhanced Bi-directional Control (Active Test)
This function allows the diagnostic tool to send commands to the vehicle's ECUs to perform specific tests on actuators and components. This helps in quickly determining if a specific system, component, or subsystem is functioning correctly without disassembling parts. Examples include activating the fuel pump, cycling ABS solenoids, or testing window motors.
Figure 3: Bi-directional Control (Active Test). This feature enables direct control over vehicle components for diagnostic purposes.
2.3 Full OBD2 Functions for All Car Brands
In addition to Land Rover/Jaguar specific functions, the Creader Elite V2.0 serves as a universal OBD2 code reader for all vehicles manufactured after 1996 that comply with OBD2 protocols. It supports all 10 OBD2 test modes:
- Read/Erase Codes
- View Live-datastrøm
- Frys rammedata
- I/M-parathedstjek
- O2 Sensortest
- On-Board Monitoring Test (Mode 6)
- EVAP System Test (Mode 8)
- Komponenttest
- Køretøjsoplysninger
- DTC opslag
Figure 4: Full OBD2 Functions. This image displays the comprehensive OBD2 capabilities for general vehicle diagnostics.
2.4 Smart Diagnostic Features
The device incorporates several smart features to enhance diagnostic efficiency:
- 4-IN-1 Data Stream Graphing: Visually displays sensor data for in-depth analysis.
- Dataoptagelse og -afspilning: Allows recording and reviewing of live data streams.
- Diagnostic Report Share & Print: Generates detailed reports that can be shared via email or printed.
- DTC Lookup & Code Search: Provides explanations for over 3000 DTCs and offers online code search.
- Onlinefeedback: Enables users to send issues directly to technical support for troubleshooting.
- Flersproget support: Supports 11 languages for broader accessibility.
Figure 5: Smart Diagnostic Features. These features streamline the diagnostic process and data management.
3. Vedligeholdelsestjenester
The LAUNCH Creader Elite V2.0 provides a wide array of special functions and reset services specifically for Land Rover and Jaguar vehicles, designed to assist with common maintenance tasks. These services can be accessed via "Diagnose > Brand > System Selection > Special Function".
| Service | Beskrivelse |
|---|---|
| Olie Lamp Nulstil | Nulstiller olieservicelampen og vedligeholdelseskilometerstanden efter et olieskift. |
| Parking Brake Reset (EPB) | Deactivates/activates the brake control system for brake pad replacement. |
| Injektor Kodning | Codes new injector numbers into the ECU after replacement. |
| SAS kalibrering | Kalibrerer styrevinkelsensoren. |
| Udskiftning af batteri | Registers new battery information with the vehicle's power management system. |
| ABS-blødning | Performs brake system bleeding when ABS contains air. |
| Throttle Body Adaptation | Initialiserer gasspjældsaktuatorer til deres standardtilstand. |
| Højdekalibrering | Calibrates the electronic air suspension system, crucial for Land Rover/Jaguar. |
| Transmissionstilpasning | Resets transmission adaptive learning values. |
| Sunroof Calibration | Initialiserer soltagssystemet. |
| Airbag (SRS) Reset | Resets the Supplemental Restraint System. |
Note: Specific functions may vary by vehicle model and year. Always check compatibility before performing a service.
Figure 6: All Free Maintenance Services. A visual representation of the various reset and calibration functions available.
4. Fejlfinding
This section addresses common issues and provides solutions to help you resolve problems encountered while using the LAUNCH Creader Elite V2.0.
4.1 Almindelige problemer og løsninger
- Spørgsmål: The device does not power on or connect to the vehicle.
Løsning: Ensure the OBD2 cable is securely connected to both the device and the vehicle's OBD2 port. Verify that the vehicle's ignition is in the ON position (engine off). Check the vehicle's battery voltage; lav volumentage can prevent proper communication.
- Spørgsmål: The device fails to communicate with a specific vehicle system or module.
Løsning: Confirm the vehicle's ignition is ON. Ensure the software is up to date. Some functions or system access may vary by vehicle model and year; verify compatibility. Try restarting both the device and the vehicle.
- Spørgsmål: Received a broken or used product.
Løsning: If you receive a product that appears broken or used, please contact customer support at obdbox21@163.com for en udskiftning.
- Spørgsmål: Topology map not working after free update period.
Løsning: The topology map function should continue to work even after the free update period expires. Updates primarily provide bug fixes, optimizations, and support for new functions and models.
- Spørgsmål: Need assistance with a specific problem or function.
Løsning: For technical assistance, please contact our support team via email at obdbox21@163.com. Provide detailed information about the issue, including vehicle make, model, year, and any error messages displayed.
5. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | LANCERING |
| Model | LAUNCH CRE V2.0 for JLR |
| Produktdimensioner | 8 cm L x 1.5 cm B x 7.5 cm H |
| Operativsystem | Android 8.1 |
| Automotive Fit Type | Universal Fit (for OBD2), Specific for Land Rover/Jaguar |
| UPC | 884508003790 |
| Varens vægt | 1.55 pund |
| Batterier | 1 lithium-ion batteri (medfølger) |
| Forbindelse | 2.4 GHz Wi-Fi |
| Hukommelse | 2 GB RAM + 16 GB lagerplads |
| Skærm | 4-inch Bright Full Touchscreen |
6. Garanti og support
LAUNCH provides comprehensive support for the Creader Elite V2.0:
- Livstids gratis opdatering: Enjoy continuous software updates for Land Rover and Jaguar specific functions.
- Returnering og erstatning: An extended 60-Day Return & Replacement policy is offered.
- Kvalitetsbackup: A 5-Year Quality Backup ensures long-term reliability.
- Teknisk assistance: 24/7/365 technical assistance is available. For any questions or support, please contact us via email at obdbox21@163.com.
