Thank you for choosing the Mould King 13089 MOC Shaman 8x8 Off-Road Pickup Truck Building Kit. This kit provides an engaging building experience with over 3062 pieces, culminating in a functional off-road vehicle featuring motor and APP remote control capabilities. This manual provides essential information for setup, operation, and maintenance. For detailed, step-by-step assembly instructions, please refer to the colorful paper manual included in your package.

2. Produktet er slutview

The Mould King 13089 is an advanced building kit designed to replicate an 8x8 off-road vehicle. It features a robust 8-wheel drive system, low-pressure tires, independent suspension, and a double cross A-type joystick design for enhanced performance and stability across various terrains.

Nøglefunktioner:

• Over 3062 building block parts for a detailed and sturdy construction.
• Equipped with 8 motors for powerful movement.
• Includes 1 remote control and 2 lithium batteries for operation.
• Supports both Bluetooth control via a mobile phone APP and 2.4GHZ remote control.
• 8-wheel drive system for strong traction and stability.
• Low-pressure tires resistant to pressure and wear, enhancing grip.
• Independent suspension and double cross A-type joystick design for a smooth driving experience.
• Functional elements include opening doors with locks, an opening back door, and a sunroof.

The Mould King 13089 Off-Road Pickup Truck in action, demonstrating its powerful off-road capabilities.

The Mould King 13089 Off-Road Pickup Truck navigating various terrains including snowland, mountains, and swampland. Inset shows a low-pressure tire designed for compression, wear resistance, and enhanced grip.

Detaljeret view of the Mould King 13089 Off-Road Pickup Truck's functional elements, including opening doors with locks on both sides and an opening back door with a sunroof.

En overview of the accessories included with the Mould King 13089 kit, featuring the packing box, eight building block bags, the instruction manual, L motors, servo motors, M motors, remote control, MKH4.0 battery boxes, and wheel hubs.

3. Monteringsvejledning

The Mould King 13089 kit comes with a comprehensive, colorful paper instruction manual. This manual provides detailed, step-by-step guidance for assembling the 3062+ pieces. The building blocks are organized into numbered bags (1 to 8) to facilitate the assembly process.

Generalforsamlingens retningslinjer:

• Følg manualen: Always refer to the included paper manual for precise instructions. Each step is illustrated with detailed pictures.
• Organiser dele: Open numbered bags in the order specified by the manual to keep parts organized.
• Tjek for manglende dele: Before or during assembly, if you discover any missing items, please contact Mould King customer service immediately.
• Forsigtig håndtering: Håndter alle dele forsigtigt for at forhindre skader.

An adult enthusiast engaged in the assembly of the Mould King 13089 Off-Road Pickup Truck building kit.

4. Opsætning

Once the physical assembly is complete, follow these steps to set up the electronic components for operation.

Batteri installation:

1. Locate the battery compartments for the vehicle and the remote control.
2. Insert the two included lithium batteries into the vehicle's battery boxes, ensuring correct polarity.
3. Insert required batteries (not specified in product details, typically AA or AAA) into the remote control, observing polarity.

Motor and Control System Connection:

1. Ensure all 8 motors are securely connected to the main control unit as per the assembly manual.
2. Fjernbetjeningsparring: Turn on the vehicle and the 2.4GHZ remote control. Follow the pairing instructions in the paper manual to establish a connection.
3. Opsætning af APP-kontrol: Download the Mould King APP on your mobile device. Enable Bluetooth on your device. Open the APP and follow the on-screen instructions to connect to the vehicle via Bluetooth.

5. Betjeningsvejledning

The Mould King 13089 Off-Road Pickup Truck is designed for versatile operation across challenging environments.

Driving Modes and Terrain:

• The 8-wheel drive system provides superior traction and stability, allowing the vehicle to traverse extreme terrains such as snowy mountains, swamps, and rocky landscapes.
• Utilize the remote control or mobile APP to select various driving modes, optimizing performance for different surfaces.

Kontrolfunktioner:

• Styretøj: Use the remote control or APP to control the steering, which links the front wheels for precise maneuvering.
• Traction Rope: The vehicle is equipped with a gear-driven traction rope. Operate this feature via the remote or APP for recovery or assistance in difficult situations.
• Door and Sunroof Operation: Manually open and close the side doors, back door, and sunroof for interactive play or display.

An adult operating the Mould King 13089 Off-Road Pickup Truck using the remote control.

Underside view of the Mould King 13089 Off-Road Pickup Truck showing the simulated eight-drive chassis. Also depicts the steering wheel linking wheels and the gear-driven traction rope mechanism.

6. Vedligeholdelse

Proper maintenance ensures the longevity and optimal performance of your Mould King 13089 Off-Road Pickup Truck.

Rensning:

• Regularly clean the model with a soft, dry cloth to remove dust and debris.
• Avoid using water or harsh cleaning agents, as these can damage electronic components or the plastic blocks.

Batteripleje:

• Remove batteries from the vehicle and remote control if storing for extended periods to prevent leakage.
• Charge lithium batteries using only the recommended charger.

Komponentkontrol:

• Periodically inspect all connections, especially for motors and the control unit, to ensure they are secure.
• Check for any loose or damaged building blocks and reattach or replace them as needed.

7. Fejlfinding

This section addresses common issues you might encounter with your Mould King 13089 kit.

Manglende dele:

• If you find any missing pieces during assembly, please contact Mould King customer service directly via email. Provide details of the missing parts, and they will assist in sending replacements.

Gears Cracking or Breaking:

• Some users have reported issues with gears cracking or breaking. Ensure that all gears are assembled correctly and without excessive force.
• Avoid operating the vehicle in conditions that might put undue strain on the drivetrain, such as attempting to drive over obstacles too large for the vehicle or prolonged operation in very high-resistance environments.
• If gears break, contact customer support for potential replacement parts.

Connectivity Issues (Remote Control/APP):

• Ensure both the vehicle and the remote control/mobile device have sufficient battery power.
• Verify that the remote control is properly paired with the vehicle (refer to the paper manual for pairing instructions).
• For APP control, ensure Bluetooth is enabled on your mobile device and the APP has the necessary permissions. Try restarting the APP and the vehicle.

Vehicle Not Moving:

• Check battery levels in both the vehicle and the remote control.
• Ensure all motor connections are secure and correctly installed.
• Verify that the control system is properly connected and paired.

8. Specifikationer

A 1:6 scale model of the Mould King 13089 Off-Road Pickup Truck, displaying its dimensions: 17.52 inches (44.5 cm) length, 7.52 inches (19.1 cm) width, and 8.5 inches (21.6 cm) height.

9. Garanti og support

Mould King is committed to providing quality products and customer satisfaction. While specific warranty details are not provided in this manual, for any issues regarding missing parts, defective components, or operational difficulties, please contact Mould King customer service directly.

When contacting support, please have your product model number (13089) and details of your purchase readily available. This will help expedite the support process.
