HATHASPACE HSE200 Smart True HEPA Air Purifier User Manual

1. Introduktion

Thank you for choosing the HATHASPACE HSE200 Smart True HEPA Air Purifier. This manual provides important information regarding the setup, operation, maintenance, and troubleshooting of your new air purifier. Please read this manual thoroughly before using the product to ensure safe and efficient operation. This device is designed to improve indoor air quality by filtering common airborne pollutants.

Billede: Forside view of the HATHASPACE HSE200 Smart True HEPA Air Purifier, showcasing dets elegante sorte design og kontrolpanel.

2. Sikkerhedsoplysninger

For at mindske risikoen for brand, elektrisk stød eller personskade, bedes du overholde følgende sikkerhedsforanstaltninger:

• Tag altid stikket ud af luftrenseren, før du flytter den, rengør den eller udfører vedligeholdelse.
• Brug ikke enheden med en beskadiget ledning eller et beskadiget stik. Hvis ledningen eller stikket er beskadiget, skal du kontakte kundesupport.
• Hold netledningen væk fra opvarmede overflader.
• Brug ikke luftrenseren i vådt eller damp environments, such as bathrooms or laundries.
• Stik ikke fingre eller fremmedlegemer ind i nogen af ​​åbningerne på luftrenseren.
• Ensure the air inlet and outlet are not blocked during operation.
• Dette apparat er ikke beregnet til brug af personer (inklusive børn) med nedsatte fysiske, sensoriske eller mentale evner, eller mangel på erfaring og viden, medmindre de er blevet under opsyn eller instruktion i brugen af ​​apparatet af en person, der er ansvarlig for deres sikkerhed. .

3. Produktet er slutview

Nøglefunktioner:

• 3-i-1 filtreringssystem: Includes a Polypropylene Pre-Filter, Activated Carbon Filter, and H13 True HEPA Filter.
• Effektiv rensning: Captures 99.9% of particles down to 0.3 microns, including pollen, dust, pet dander, smoke, odors, and VOCs.
• Stille drift: Designed for exceptionally silent use, ideal for bedrooms and living rooms.
• Dækning: Suitable for spaces up to 200 sq. ft., replacing 100% of the air every hour.
• Brugervenlig kontrol: Features 3-speed adjustable settings, an auto mode, and comes with a remote control.

Image: Diagram highlighting key features such as low noise, 3-level fan speed, True H13 grade HEPA filter, coverage up to 200 sq. ft., lightweight and compact design, 3 stagrensningsformål og egnethed til soveværelser.

Komponenter og kontroller:

• Kontrolpanel: Located on the top of the unit, with indicators for fan speed (1, 2, 3) and power button.
• Luftindtag: Located around the lower circumference of the unit for 360° air intake.
• Luftudtag: Placeret på toppen af ​​enheden.
• Filterrum: Accessible from the bottom of the unit.
• Strømledning: Til tilslutning til en stikkontakt.
• Fjernbetjening: For bekvem betjening på afstand.

Billede: En eksploderet view illustrerer 3-ernetage filtration system (Polypropylene Pre-Filter, Activated Carbon Filter, High-Efficiency H13 True HEPA Filter) and a diagram showing how to set up the unit by twisting open the base, removing the power adapter, and taking off plastic packaging from the filter.

4. Opsætning

Følg disse trin for indledende opsætning:

1. Pak enheden ud: Tag forsigtigt luftrenseren og alt emballagemateriale ud af kassen.
2. Fjern filteremballage: The filter inside the unit is typically wrapped in plastic for protection during shipping.
• Vend enheden på hovedet.
• Drej basen mod uret for at låse den op og fjerne den.
• Træk forsigtigt filteret ud.
• Fjern al plastikemballage fra filteret.
• Sæt filteret tilbage i enheden.
• Sæt basen på igen, og drej den med uret for at låse den sikkert.
3. Placering af luftrenseren: Place the air purifier on a firm, level surface. Ensure there is at least 6 inches (15 cm) of clear space around all sides for optimal airflow.
4. Tilslut strøm: Plug the power adapter into the air purifier, then plug the power cord into a standard electrical outlet.

5. Betjeningsvejledning

Kontrolpanel og fjernbetjening:

Image: Close-up of the air purifier's control panel, showing the fan speed indicators (1, 2, 3) and the power button.

• Power knap: Tryk for at tænde eller slukke enheden.
• Ventilatorhastighedsknap: Press to cycle through fan speeds: 1 (Low), 2 (Medium), 3 (High).
• Automatisk tilstand: The air purifier can automatically adjust fan speed based on detected air quality. Refer to your remote control for specific auto mode activation.
• Lysstyring: The remote control allows you to turn the indicator lights on or off.

Air Purification Process:

The HSE200 utilizes a 3-stage filtration system to purify the air:

1. Forfilter: Opfanger store partikler såsom støv, fnug og dyrehår.
2. Aktivt kulfilter: Absorberer lugte, røg og flygtige organiske forbindelser (VOC'er).
3. H13 ægte HEPA-filter: Traps 99.9% of airborne particles as small as 0.3 microns, including allergens, pollen, dust mites, and certain bacteria and viruses.

Image: Illustrates the air purifier's true 360-degree intake system, showing how it effectively eliminates fine dust & pollen, smoke & VOCs, pet dander & odors, and harmful gases.

Image: Depicts the ultra-quiet operation of the air purifier at 25dB in sleep mode, comparing it to the sound of breathing (10dB) and other brands (35dB), emphasizing its suitability for peaceful sleep environments.

6. Vedligeholdelse

Regelmæssig vedligeholdelse sikrer optimal ydeevne og forlænger din luftrensers levetid.

Rengøring af ydersiden:

• Tag altid stikket ud af stikkontakten før rengøring.
• Wipe the exterior surface with a soft, dry cloth.
• Brug ikke slibende rengøringsmidler, voks eller opløsningsmidler.

Filterudskiftning:

The 3-in-1 composite filter should be replaced every 3-4 months, or approximately every 2,000 hours of use, depending on air quality and usage frequency. Timely replacement is crucial for maintaining purification efficiency.

1. Træk stikket til luftrenseren ud af stikkontakten.
2. Turn the unit upside down and twist the base counter-clockwise to remove it.
3. Fjern det gamle filter fra enheden.
4. Insert the new HATHASPACE HSE200 replacement filter, ensuring it is seated correctly.
5. Sæt basen på igen, og drej den med uret for at låse den sikkert.
6. Sæt enheden i igen.

Replacement filters are available for purchase from HATHASPACE or authorized retailers.

7. Fejlfinding

Hvis du støder på problemer med din luftrenser, kan du se følgende almindelige problemer og løsninger:

Hvis problemet fortsætter efter at have prøvet disse løsninger, bedes du kontakte HATHASPACE kundesupport.

8. Specifikationer

9. Garanti og support

Garantioplysninger:

HATHASPACE products come with a standard manufacturer's warranty. Please refer to the warranty card included with your purchase or visit the official HATHASPACE webwebstedet for detaljerede garantivilkår og -betingelser. Gem din købsbevis til garantikrav.

Kundesupport:

For any questions, technical assistance, or warranty claims, please contact HATHASPACE customer support:

• Webwebsted: Visit the official HATHASPACE webwebsted for ofte stillede spørgsmål og supportressourcer.
• E-mail: Se din produktemballage eller webwebsted for support e-mailadresse.
• Telefon: Se din produktemballage eller webhjemmeside for supporttelefonnummer.

When contacting support, please have your product model number (HSE200) and purchase date ready.
