REL T/9x 10-Inch Powered Subwoofer

Indledning

The REL T/9x 10-Inch Powered Subwoofer is engineered to deliver deep, controlled bass and enhance the overall audio experience for both HiFi stereo systems and home theater setups. Featuring a sealed design with a Class A/B amplifier, this subwoofer is designed for seamless integration and optimal performance in various listening environments.

This manual provides essential information for the proper setup, operation, and maintenance of your REL T/9x subwoofer. Please read it thoroughly before use to ensure safe and effective operation.

Sikkerhedsoplysninger

Please observe the following safety precautions to prevent damage to the unit and ensure your personal safety:

• Strømkilde: Connect the subwoofer only to a power supply of the type specified on the rear panel.
• Ventilation: Ensure adequate ventilation. Do not block ventilation openings or place the unit on soft surfaces that may impede airflow.
• Vand og fugt: Udsæt ikke enheden for regn eller fugt. Placer ikke genstande fyldt med væsker, såsom vaser, på enheden.
• Varme: Placer ikke enheden i nærheden af ​​varmekilder såsom radiatorer, varmeapparater, komfurer eller andre apparater (herunder ampløftere), der producerer varme.
• Rensning: Rengør kun med en tør klud. Undgå at bruge flydende eller aerosolbaserede rengøringsmidler.
• Service: Forsøg ikke selv at servicere dette produkt. Overlad al service til kvalificeret servicepersonale.
• Placering: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm (Proposition 65 warning). Place the unit on a stable, level surface.

Opsætning

Udpakning og placering

Carefully remove the REL T/9x subwoofer from its packaging. Inspect the unit for any signs of damage. The T/9x is designed for floor standing placement.

Figur 1: Forside view of the REL T/9x Subwoofer in high gloss grey finish. This image shows the 10-inch front-firing driver and the sleek, sealed cabinet design.

Forbindelser

The REL T/9x offers versatile connection methods to integrate seamlessly into your audio system. The rear panel provides various input options.

Figure 2: Rear panel of the REL T/9x Subwoofer, displaying the various input terminals and controls. This includes High/Low Level inputs, Crossover, and Phase controls.

1. High-Level Connection (Recommended for Music):
   • Use the included high-level speaker wire.
   • Connect the bare wire ends to the corresponding speaker terminals on your amplifier (Left, Right, and Ground).
   • Connect the Speakon connector to the "HIGH LEVEL INPUT" on the subwoofer's rear panel.
   • This connection method ensures the subwoofer receives the same sonic signature as your main speakers, leading to better integration.
2. Low-Level Connection (Recommended for Home Theater LFE):
   • Use a single RCA cable (not included).
   • Connect one end of the RCA cable to the LFE output of your AV receiver or processor.
   • Connect the other end to the "LOW .1/LFE INPUT" on the subwoofer's rear panel.
   • For stereo low-level connection, use two RCA cables (not included) to connect to the "LOW LEVEL INPUT" (left and right) from your pre-amplifier eller kilde.
3. Strømtilslutning:
   • Connect the power cord to the AC inlet on the rear panel of the subwoofer.
   • Plug the other end into a suitable wall outlet.

Operating the REL T/9x

Første gang tændt

After making all connections, switch the power toggle on the rear panel to the "ON" position. The power indicator light will illuminate.

Justering af indstillinger

The REL T/9x features controls on the rear panel for fine-tuning its performance to your listening environment and preferences:

• HI/LOW LEVEL (Volume): This knob controls the overall output volume of the subwoofer. Start with a low setting and gradually increase until the bass blends seamlessly with your main speakers.
• CROSSOVER: This knob adjusts the upper frequency limit of the subwoofer. Adjust this to blend the subwoofer's output with the low-frequency roll-off of your main speakers. Common settings range from 30Hz to 120Hz.
• PHASE (0/180): This switch adjusts the phase of the subwoofer's output relative to your main speakers. Experiment with both 0 and 180 degrees to find the setting that produces the most impactful and coherent bass. The correct phase setting will result in the loudest and clearest bass response at your listening position.
• .1/LFE-NIVEAU: This control is specifically for the LFE input, allowing independent volume adjustment for dedicated home theater bass effects.

For optimal performance, it is recommended to adjust these settings while listening to familiar music or movie scenes to achieve a balanced and integrated sound.

Opretholdelse

For at sikre din REL T/9x subwoofers lange levetid og optimale ydeevne, skal du følge disse enkle vedligeholdelsesretningslinjer:

• Rensning: Regularly wipe the cabinet with a soft, dry, lint-free cloth. Avoid using abrasive cleaners, solvents, or chemical sprays, as these can damage the finish.
• Støv: Keep the driver and passive radiator free from dust accumulation. A soft brush or a vacuum cleaner with a brush attachment can be used carefully.
• Ventilation: Periodically check that the ventilation fins on the rear panel are clear of dust and obstructions to prevent overheating.
• Kabler: Ensure all cables are securely connected and free from kinks or damage.

Fejlfinding

Hvis du støder på problemer med din REL T/9x subwoofer, skal du se følgende almindelige fejlfindingstrin:

If the problem persists after attempting these solutions, please contact REL Acoustics customer support.

Specifikationer

Garanti og support

Garantioplysninger

The REL T/9x Subwoofer comes with a Begrænset garanti. For specific terms and conditions, please refer to the warranty card included with your product or visit the official REL Acoustics webwebsted.

Kundesupport

For technical assistance, troubleshooting beyond this manual, or warranty claims, please contact REL Acoustics customer support. You can find contact information on the official REL Acoustics webhjemmeside eller gennem din autoriserede forhandler.

Online ressourcer: www.rel.net
