1. Introduktion
Thank you for choosing the Holyton Drone Strobe Light. This anti-collision lamp is designed to enhance the visibility of your drone during night flights and in various other scenarios. It features multiple colors and modes, ensuring compliance with aviation regulations and improving safety. Please read this manual thoroughly before use to ensure proper operation and maintenance.
2. Sikkerhedsoplysninger
- Always ensure the strobe light is securely attached to your drone or other object before operation.
- Adhere to all local aviation authority regulations regarding drone lighting, especially for night flying. This light meets FAA requirements for anti-collision lighting.
- Do not expose the device to extreme temperatures, direct sunlight for prolonged periods, or moisture.
- Opbevares utilgængeligt for børn.
- Do not attempt to disassemble or modify the light, as this will void the warranty and may cause damage.
3. Pakkens indhold
- Holyton Drone Strobe Light (1 unit)
- USB opladningskabel
- Mounting Accessories (e.g., adhesive pads, rubber bands)
- Brugermanual
4. Produktfunktioner
- Høj synlighed: 120 lumens brightness with 360° coverage.
- Multiple Colors & Modes: 7 switchable colors and 7 adjustable flashing modes.
- Genopladeligt batteri: Provides extended use time after a quick charge.
- Let og kompakt: Weighs only 6.5g, ideal for various drones and other applications.
- Alsidig anvendelse: Suitable for drones, RC vehicles, bicycles, motorcycles, helmets, and more.
- FAA Compliant: Meets requirements for anti-collision lighting during night flights.
5. Opsætning og installation
5.1 Indledende opladning
Before first use, fully charge the strobe light. Refer to Section 6 for charging instructions.
5.2 Mounting the Strobe Light
The Holyton Drone Strobe Light can be attached to various objects using the provided mounting accessories. For drones, ensure the light does not interfere with propellers, sensors, or flight stability.
- Ren overflade: Ensure the mounting surface on your drone or object is clean and dry.
- Påfør klæbemiddel: Peel the backing from an adhesive pad and firmly press it onto the designated area on the strobe light.
- Attach to Drone: Peel the remaining backing from the adhesive pad and attach the strobe light to your drone. Apply firm pressure for a few seconds to ensure a secure bond. Alternatively, use rubber bands or other suitable fasteners for temporary attachment.
6. Betjeningsvejledning
6.1 Tænd/sluk
- Tænd: Press and hold the power button for approximately 2 seconds until the light illuminates.
- Sluk: Press and hold the power button for approximately 2 seconds until the light turns off.
6.2 Changing Colors and Modes
The strobe light offers 7 different colors and 7 distinct flashing modes.
- Skift farve: While the light is on, short press the power button to cycle through the available colors (e.g., white, red, green, blue, yellow, pink, ice blue).
- Skift tilstand: Double-press the power button quickly to cycle through the different flashing modes (e.g., constant, slow flash, fast flash, alternating colors).
7. Opladning
The Holyton Drone Strobe Light is equipped with a rechargeable Lithium Ion battery.
- Opladningsport: Micro USB
- Opladningstid: Cirka 12 minutter for en fuld opladning.
- Brugstid: Up to 5 hours on a full charge, depending on the selected mode and color.
To charge, connect the provided USB charging cable to the Micro USB port on the strobe light and plug the other end into a standard USB power source (e.g., computer, wall adapter).
8. Vedligeholdelse
- Rensning: Brug en blød, tør klud til at rengøre lyset. Brug ikke skrappe kemikalier eller slibende materialer.
- Opbevaring: Store the strobe light in a cool, dry place away from direct sunlight when not in use.
- Batteripleje: For optimal battery life, avoid fully discharging the battery frequently. Charge the device regularly, even if not in use, to maintain battery health.
9. Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Lyset tændes ikke. | Batteriet er afladet. | Charge the strobe light fully. |
| Lyset oplader ikke. | Charging cable or power source is faulty. | Try a different USB cable or power adapter. Ensure the Micro USB connector is inserted correctly. |
| Light is not bright enough. | Low battery or incorrect mode. | Charge the device. Ensure a bright mode is selected (e.g., constant white light). |
| Light falls off during use. | Improper mounting or worn adhesive. | Ensure the mounting surface is clean and dry. Use new adhesive pads or more secure fastening methods. |
10. Specifikationer
| Feature | Detalje |
|---|---|
| Modelnummer | US03A76731000HT70402 |
| Mærke | Holyton |
| Farve | Sort |
| Form | Rektangulær |
| Finish Type | Malet |
| Lyskildetype | Lysdiode (LED) |
| Skærmmateriale | Plast |
| Varens vægt | 0.352 ounce (ca. 10 gram) |
| Antal batterier | 1 Lithium Ion (inkluderet) |
| Stil | Kompakt |
| Lysstyrke | 120 Lumens (Maximum Light Output) |
| Monteringstype | Drone Mount (Adhesive/Strap) |
| Pærefunktioner | Strobe, Flashing, Anti-Collision, Search and Rescue |
| Produktdimensioner | 1"L x 1"W x 1"H (approximately) |
11. Garanti og support
Holyton products are designed for reliability and performance. This product comes with a standard manufacturer's warranty against defects in materials and workmanship. Please refer to the product packaging or our official webwebstedet for specifikke garantivilkår.
For technical support, troubleshooting assistance, or warranty claims, please contact our customer service team:
- E-mail: holyton@foxmail.com
- Telefon: +1 (866) 514-8669
Our support team is available to assist you within 24 hours.
