1. Introduktion
The Nexxt Solutions Smart Wi-Fi Indoor Pan and Tilt Camera (NHC-P710) provides advanced home security and monitoring capabilities. Featuring 2K HD resolution, motion detection, night vision, and two-way audio, this camera allows for comprehensive surveillance and remote interaction. Its 355-degree rotatable design ensures wide coverage, making it an ideal solution for monitoring your home, pets, or loved ones.
This manual provides detailed instructions for setting up, operating, and maintaining your camera to ensure optimal performance and security.
Figure 1.1: Nexxt Solutions Smart Wi-Fi Indoor Pan and Tilt Camera (NHC-P710) and packaging.
2. Hvad er der i æsken
Kontroller venligst, at alle komponenter er til stede og i god stand, når du åbner pakken:
- Indoor PTZ Wi-Fi camera
- Strømadapter
- USB type-C kabel
- 1 monteringsbeslag
- 2 skruer
- 2 betonankre
- Hurtig opsætningsvejledning
3. Opsætningsvejledning
3.1. Forberedelse til installation
- Ensure your Wi-Fi network is 2.4GHz. This camera does not support 5GHz Wi-Fi.
- Place the camera within range of your Wi-Fi router.
- Download the Nexxt Home app from the App Store (iOS) or Google Play Store (Android).
3.2. Tænd for kameraet
- Connect the USB Type-C cable to the camera's power port.
- Sæt strømadapteren i en almindelig stikkontakt.
- Vent på, at kameraets indikatorlampe blinker, hvilket angiver, at det er klar til parring.
3.3. Adding the Camera to the Nexxt Home App
- Open the Nexxt Home app and log in or create a new account.
- Tryk på "+"-ikonet i øverste højre hjørne for at tilføje en ny enhed.
- Select "Security Camera" or search for the NHC-P710 model.
- Følg instruktionerne på skærmen for at forbinde kameraet til dit Wi-Fi-netværk. Dette involverer typisk at scanne en QR-kode genereret af appen med kameraets objektiv.
- Når det er tilsluttet, kan du navngive dit kamera og tildele det til et bestemt rum.
Figure 3.1: Simple setup process for the 2K HD Smart Wi-Fi Indoor Camera.
3.4. Montering af kameraet (valgfrit)
The camera can be placed on a flat surface or mounted to a wall or ceiling using the included mounting bracket.
- Choose a suitable location for mounting, ensuring a clear view og adgang til en stikkontakt.
- Attach the mounting bracket to the desired surface using the provided screws and anchors.
- Securely attach the camera to the mounting bracket by twisting it into place.
4. Betjeningsvejledning
4.1. Lev View og fjernadgang
Once connected, you can access the live video feed from your camera anytime, anywhere, using the Nexxt Home app on your smartphone.
- Open the Nexxt Home app and select your camera from the device list.
- The live feed will appear. You can switch between standard and HD resolution.
Figur 4.1: Fjernbetjening viewing of the camera feed via the Nexxt Home app.
4.2. Panorerings- og vippekontrol
The camera features a 355-degree rotatable design, allowing you to adjust its viewvinkel på afstand.
- I live view interface of the app, use the directional controls (usually a joystick or arrow buttons) to pan (move horizontally) and tilt (move vertically) the camera lens.
Figure 4.2: The camera's 355-degree rotatable design for comprehensive coverage.
4.3. Tovejslyd
The built-in microphone and speaker enable two-way communication.
- Tryk på mikrofonikonet i appens live view at tale gennem kameraet.
- Tryk på højttalerikonet for at lytte til lyd fra kameraets omgivelser.
Figure 4.3: Two-way communication feature.
4.4. Bevægelsesdetektion og advarsler
The camera can detect motion and send instant alerts to your smartphone.
- Enable motion detection in the camera settings within the Nexxt Home app.
- Adjust sensitivity levels and set detection zones as needed.
- Modtag push-notifikationer på din telefon, når der registreres bevægelse.
Figure 4.4: Advanced motion detection with an effective range of up to 32 feet.
4.5. Nattesyn
Integrated IR LEDs provide clear night vision, even in low light or complete darkness.
- Nattesyn aktiveres automatisk under dårlige lysforhold.
- You can manually toggle night vision on/off in the app settings if desired.
Figure 4.5: Integrated IR LEDs allow clear night vision monitoring.
4.6. Local Storage (MicroSD Card)
The camera supports local storage via a microSD card (up to 128GB, not included).
- Insert a formatted microSD card into the camera's slot.
- Configure recording settings (continuous, event-triggered) in the Nexxt Home app.
- Review optaget footagdirekte fra appen.
5. Funktioner overview
The Nexxt Solutions Smart Wi-Fi Indoor Pan and Tilt Camera is equipped with a range of features designed for enhanced security and convenience:
- Full 2K HD Resolution: Provides sharp live streaming and video playback for clear monitoring.
- Avanceret bevægelsesdetektion: Detects movement up to 32 feet with smart human body detection to minimize false alerts.
- 355-Degree Rotatable Design: Offers comprehensive activity monitoring with wide room coverage.
- Clear Night Vision: Bred viewing angle and IR LEDs ensure clear visibility in low-light conditions.
- Tovejs lyd: Communicate directly through the camera using the built-in microphone and speaker.
- Understøttelse af lokal lagring: Supports microSD cards up to 128GB for continuous or event-triggered recording.
- Fjernadgang: View live feeds and manage settings from anywhere via the free Nexxt Home app on iOS or Android devices.
- Smart Home-kompatibilitet: Works with Amazon Alexa and Google Home for voice control and integration into your smart home ecosystem.
Figure 5.1: Key features of the Nexxt Solutions Smart Wi-Fi Camera.
6. Vedligeholdelse
Korrekt vedligeholdelse sikrer dit kameras levetid og optimale ydeevne.
- Rensning: Brug en blød, tør klud til at rengøre kameralinsen og huset. Undgå at bruge skrappe kemikalier eller slibende rengøringsmidler.
- Softwareopdateringer: Regularly check the Nexxt Home app for firmware updates. Keeping your camera's software up-to-date ensures you have the latest features and security enhancements.
- Power Cycle: If the camera experiences minor issues, try unplugging it from the power source for 10 seconds and then plugging it back in.
- MicroSD-kort: Hvis du bruger et microSD-kort, skal du regelmæssigt kontrollere dets status i appen og overveje at formatere det med et par måneders mellemrum for at opretholde ydeevnen.
7. Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Kamera offline | No power; Wi-Fi signal weak or disconnected; Router issues. | Check power connection; Move camera closer to router; Restart router; Re-add camera in app. |
| Kan ikke oprette forbindelse til Wi-Fi | Incorrect Wi-Fi password; 5GHz network used; Too far from router. | Verify password; Ensure 2.4GHz network; Relocate camera. |
| Dårlig billedkvalitet | Dirty lens; Insufficient lighting; Network bandwidth issues. | Clean lens; Ensure adequate lighting; Check internet speed. |
| Bevægelsesalarmer ikke modtaget | Motion detection disabled; App notifications off; Incorrect sensitivity. | Enable motion detection in app; Check phone notification settings; Adjust sensitivity. |
| Problemer med tovejslyd | Microphone/speaker muted in app; Network latency. | Unmute audio in app; Check network connection. |
8. Specifikationer
| Feature | Detalje |
|---|---|
| Modelnavn | Smart Wi-Fi camera (NHC-P710) |
| Indendørs/Udendørs brug | Indendørs |
| Videooptagelsesopløsning | 2K HD |
| Forbindelsesprotokol | Wi-Fi (2.4 GHz) |
| Strømkilde | Elektrisk med ledning |
| Night Vision Range | 32 fod |
| Kontrolmetode | Voice (Amazon Alexa, Google Home), App |
| Monteringstype | Vægmontering (valgfrit) |
| Opbevaring | MicroSD-kort (op til 128 GB) |
| Produktdimensioner | 2.7 x 2.7 x 4.3 tommer |
| Varens vægt | 13.1 ounce |
9. Garanti og support
For warranty information and technical support, please refer to the official Nexxt Solutions webwebstedet eller kontakt deres kundeservice direkte. Gem din købskvittering som købsbevis i tilfælde af garantikrav.
Fabrikant: Nexxt løsninger
For yderligere hjælp, besøg Nexxt Solutions Store on Amazon.
