1. Introduktion og sikkerhedsoplysninger
Thank you for choosing the SPORTNOW 2-in-1 Electric Folding Walking Pad Treadmill. This manual provides essential information for the safe and efficient operation, assembly, maintenance, and troubleshooting of your new fitness equipment. Please read this manual thoroughly before initial use and retain it for future reference.
Vigtige sikkerhedsinstruktioner
- Rådfør dig altid med en læge, inden du starter et nyt træningsprogram.
- Placer løbebåndet på en flad, stabil overflade med tilstrækkelig plads omkring det.
- Hold børn og kæledyr væk fra løbebåndet under drift.
- Ensure the safety key is properly attached to both the treadmill and your clothing before beginning your workout.
- Brug ikke løbebåndet, hvis det er beskadiget eller ikke fungerer korrekt.
- Maximum recommended user weight: 120 kg.
- Tag løbebåndets stik ud af stikkontakten, når det ikke er i brug, eller før rengøring og vedligeholdelse.
2. Produktet er slutview og funktioner
The SPORTNOW 2-in-1 Electric Folding Walking Pad Treadmill is designed for versatile home and office use, offering both walking and running modes. Its compact, foldable design allows for easy storage.
Image: The SPORTNOW 2-in-1 Electric Folding Walking Pad Treadmill in its upright running configuration, with a user exercising.
Nøglefunktioner:
- Kraftig 2.5 HK motor: Provides smooth and quiet operation, suitable for home use.
- 2-i-1 design: Functions as a traditional treadmill (up to 6 km/h) or a walking pad for under-desk use.
- LED Multifunction Display: Tracks time, speed, distance, steps, and calories burned.
- Fjernbetjening: Allows for easy speed adjustments without bending down.
- Shock-Absorbing Running Belt: Multi-layer design (41 cm wide) reduces noise and impact for a comfortable workout.
- Sammenfoldelig og bærbar: Easily folds for storage under a bed or sofa, with transport wheels for mobility.
- Integreret telefonholder: Conveniently holds your mobile device during exercise.
- Sikkerhedsnøgle: Ensures immediate shutdown in emergencies.
Billede: Et nærbillede view illustrating the powerful and stable 2.5HP motor located at the base of the treadmill.
3. Opsætning og montering
Your SPORTNOW treadmill is largely pre-assembled for convenience. Follow these steps for initial setup:
- Udpakning: Carefully remove the treadmill from its packaging. Retain all packaging materials until you are satisfied with the product.
- Placering: Position the treadmill on a firm, level surface. Ensure there is at least 0.6 meters (2 feet) of clear space on all sides and 2 meters (6.5 feet) at the rear for safety.
- Udfoldning (hvis relevant): If the handlebar is folded, gently lift and secure it into the upright position using the locking mechanisms. Ensure it is firmly locked before use.
- Strømtilslutning: Sæt netledningen i en jordet stikkontakt.
Image: The treadmill folded flat, demonstrating its compact storage capability under furniture, with an arrow pointing to the transport wheels.
4. Betjeningsvejledning
Tænder og slukker
- Tænd: Connect the power cord and flip the main power switch (usually located near the front base) to the 'ON' position. The LED display will illuminate.
- Sluk: Flip the main power switch to the 'OFF' position and unplug the unit.
Using the Safety Key
The safety key is a critical safety feature. Attach the clip end of the safety key to your clothing and insert the magnetic end into the designated slot on the console. The treadmill will not operate without the safety key in place. Pulling the safety key out will immediately stop the treadmill.
Billede: En detaljeret view of the treadmill's console, highlighting the safety key attachment point and the integrated phone holder.
2-i-1 driftstilstande
This treadmill offers two distinct modes:
- Running Mode (with handlebar up): When the handlebar is in the upright position, the treadmill can operate at speeds suitable for jogging or running, up to 6 km/h.
- Walking Pad Mode (handlebar folded down): With the handlebar folded down, the unit functions as a walking pad, ideal for use under a desk. Speed may be limited in this mode for safety.
Image: A visual comparison showing the treadmill in its upright 'Tapis de course' (running) mode and its folded 'Tapis de marche sous le bureau' (walking pad) mode.
Using the Remote Control and LED Display
Image: A hand holding the remote control, with the LED display showing various workout metrics like time, speed, distance, calories, and steps.
- Start/Stop: Press the 'Start' button on the remote to begin, and 'Stop' to pause or end your workout.
- Hastighedstilpasning: Brug knapperne '+' og '-' på fjernbetjeningen til at øge eller mindske hastigheden.
- LED display: The display cycles through or shows simultaneously: Time, Speed, Distance, Steps, and Calories burned.
- Telefonholder: Place your smartphone in the integrated holder for entertainment or tracking.
5. Vedligeholdelse
Regelmæssig vedligeholdelse sikrer dit løbebånds levetid og optimale ydeevne.
Rensning
- Tag altid stikket ud af løbebåndet før rengøring.
- Tør konsollen og de udvendige overflader af med en blød, tør klud.amp klud. Undgå slibende rengøringsmidler eller opløsningsmidler.
- Støvsug regelmæssigt under løbebåndet for at forhindre støvophobning.
Smøring
The running belt requires periodic lubrication to reduce friction and extend its lifespan. Your treadmill includes lubricating oil.
- Frekvens: Lubricate every 3-6 months, or after approximately 100 hours of use, depending on usage.
- Procedure:
- Tag stikket ud af løbebåndet.
- Loosen the rear roller bolts slightly to lift the running belt.
- Apply a small amount of the provided silicone lubricant evenly under the center of the running belt.
- Spænd de bagerste rullebolte.
- Plug in the treadmill and run it at a low speed (e.g., 1 km/h) for 5 minutes to distribute the lubricant.
Bæltejustering
If the running belt shifts to one side or slips, it may need adjustment. Refer to the specific instructions in your product's detailed manual for precise belt centering and tensioning procedures.
6. Fejlfinding
Dette afsnit omhandler almindelige problemer, du kan støde på med dit løbebånd.
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Løbebåndet tænder ikke. | Power cord not plugged in; Main power switch off; Circuit breaker tripped. | Ensure power cord is securely plugged in; Turn main power switch to 'ON'; Check household circuit breaker. |
| Treadmill starts but belt does not move. | Safety key not in place; Motor overload. | Ensure safety key is fully inserted; Reduce user weight if exceeding maximum; Contact customer support if issue persists. |
| Løbebåndet glider eller tøver. | Rem for løs; Utilstrækkelig smøring. | Adjust belt tension (refer to detailed manual); Lubricate the running belt as per maintenance section. |
| Usædvanlig støj under drift. | Loose components; Belt misalignment; Motor issue. | Check for loose bolts and tighten; Adjust belt alignment; If noise persists, discontinue use and contact customer support. |
If you encounter a problem not listed here or if solutions do not resolve the issue, please contact SPORTNOW customer support.
7. Specifikationer
Technical details for the SPORTNOW 2-in-1 Electric Folding Walking Pad Treadmill (Model FRA90-365V90OG0531):
| Feature | Detalje |
|---|---|
| Modelnummer | FRA90-365V90OG0531 |
| Motorkraft | 2.5 hestekræfter (HK) |
| Hastighedsområde | Op til 6 km / h |
| Løbefladedimensioner | 41 cm (Bredde) |
| Samlede dimensioner (udfoldet) | 120 cm (L) x 62 cm (B) x 100 cm (H) |
| Foldede dimensioner | 130 cm (L) x 62 cm (B) x 13 cm (H) |
| Produktets vægt | 24 kilo |
| Maksimal brugervægt | 120 kg (Recommended) |
| Display Type | LED |
| Displaymålinger | Time, Speed, Distance, Steps, Calories |
| Materiale | Legeret stålramme |
| Strømkilde | El-kabel |
| Særlige funktioner | Foldable, LED Display, Phone Holder, Safety Key |
| Inkluderede komponenter | Lubricating Oil, Remote Control |
Image: A diagram illustrating the key dimensions of the treadmill, including length, width, and height.
8. Garanti og kundesupport
SPORTNOW products are designed for quality and durability. For specific warranty details, please refer to the warranty card included with your purchase or visit the official SPORTNOW webwebsted.
If you require assistance, have questions about your product, or need to report a defect, please contact SPORTNOW customer support. Have your model number (FRA90-365V90OG0531) and purchase information ready when contacting support.
Kontaktoplysninger: Please refer to your purchase documentation or the SPORTNOW official webwebstedet for de mest aktuelle kontaktoplysninger til kundesupport.
