ELEPHAS Mini Bærbar Projektor Brugermanual

Indledning

This manual provides comprehensive instructions for the safe and efficient operation of your ELEPHAS 1080P Mini Portable Projector. Please read this manual thoroughly before using the product and retain it for future reference.

Produkt overview

The ELEPHAS Mini Portable Projector is designed to deliver a high-definition viewing experience with advanced features such as 4K video decoding support, automatic keystone correction, 180° rotation, and dual-band Wi-Fi 6 connectivity. It includes a built-in Hi-Fi speaker and Bluetooth 5.2 for enhanced audio.

Figur 1: Front view of the ELEPHAS Mini Portable Projector, showcasing its compact cylindrical design and lens.

Nøglefunktioner:

• HD 1080P Resolution & 4K Video Decoding: Supports 1920x1080P resolution and full-format decoding including HEVC/VP9/AVS2/AVC 4K@30fps and AV1/MPEG1/MPEG2 1080p/60fps.
• Automatisk keystone-korrektion: Features ±45° automatic keystone correction for perfectly aligned images.
• 180° roterbar projektion: Allows projection onto walls, ceilings, or floors from various angles.
• Bluetooth 5.2 & Hi-Fi Speaker: Integrated 3W Hi-Fi speaker and Bluetooth connectivity for external audio devices.
• Dobbeltbånds Wi-Fi 6: Ensures stable and fast streaming with compatibility for 2.4G and 5G networks.

Pakkens indhold

Når du åbner pakken, skal du kontrollere, at alle nedenstående varer er til stede og i god stand:

• ELEPHAS Mini Bærbar Projektor
• HDMI kabel
• Strømadapter (ikke eksplicit angivet, men underforstået til drift)
• Remote Control (not explicitly listed but implied for operation)
• Brugervejledning (dette dokument)

Note: If any items are missing or damaged, please contact customer support.

Opsætning

1. Placering

Position the projector on a stable, flat surface. Ensure there is adequate ventilation around the device. The 180° rotatable projection allows for flexible placement, including projecting onto ceilings or walls.

Figur 2: The projector demonstrating its 180-degree rotation capability, projecting images onto both a wall and a ceiling in a bedroom setting.

2. Strømtilslutning

1. Tilslut strømadapteren til projektorens strømindgang.
2. Sæt strømadapteren i en passende stikkontakt.

3. Første opstart

Tryk på tænd/sluk-knappen på projektoren eller fjernbetjeningen for at tænde enheden. Indikatorlampen lyser.

4. Fokusjustering

Adjust the focus ring on the projector lens until the projected image appears clear and sharp. For optimal clarity, ensure the projector is at an appropriate distance from the projection surface.

5. Automatisk keystone-korrektion

The projector features automatic ±45° keystone correction. This function automatically adjusts the image to be rectangular, even if the projector is placed at an angle. Manual adjustment may be available in the settings if needed.

Figur 3: Illustration of the automatic keystone correction feature, showing how a distorted image is automatically corrected into a perfect rectangle.

Betjeningsvejledning

1. Navigering i grænsefladen

The projector runs on Android 11.0 with a built-in app interface. Use the remote control to navigate through menus, select applications, and adjust settings. The main screen provides access to pre-installed apps like Netflix and YouTube, as well as an AppStore for additional downloads.

Figur 4: The projector's Android 11.0 interface displaying various application icons such as Netflix, YouTube, and AppStore, indicating built-in smart capabilities.

2. Wi-Fi-forbindelse

1. Go to "Settings" on the main interface.
2. Vælg "Netværk og internet" eller "Wi-Fi".
3. Tænd Wi-Fi, og vælg det ønskede netværk fra listen.
4. Enter the password if prompted and connect. The projector supports dual-band Wi-Fi 6 (2.4G and 5G).

3. Bluetooth-forbindelse

The projector features Bluetooth 5.2 for connecting to external audio devices like headphones or speakers. It is important to note that Bluetooth connectivity is for audio output devices only and not for connecting to smartphones as an input source.

1. Go to "Settings" and select "Bluetooth".
2. Ensure Bluetooth is enabled on both the projector and your audio device.
3. Vælg din lydenhed fra listen over tilgængelige enheder, der skal parres.

Figur 5: The projector connected via Bluetooth 5.2 to an external soundbar, illustrating its audio output capabilities. Note: Bluetooth is for audio devices only, not smartphones.

4. Connecting External Devices (HDMI)

Use the provided HDMI cable to connect external devices such as laptops, gaming consoles, or TV sticks to the projector.

1. Connect one end of the HDMI cable to the HDMI input port on the projector.
2. Connect the other end to the HDMI output port of your external device.
3. On the projector's interface, select the HDMI input source.

5. Adjusting Projection Size

The projector can display an image up to 200 inches. The projection size is primarily determined by the distance between the projector and the screen. Move the projector closer to the screen for a smaller image, and further away for a larger image.

Opretholdelse

1. Rengøring af linsen

Gently wipe the projector lens with a soft, lint-free cloth specifically designed for optical surfaces. Avoid using abrasive cleaners or excessive force, which can scratch the lens.

2. Rengøring af projektorhuset

Brug en blød, tør klud til at rengøre projektorens yderside. Ved genstridige mærker kan du bruge en let tør klud.amp cloth can be used, followed by a dry cloth. Do not use liquid cleaners directly on the projector.

3. Ventilation

Ensure that the ventilation vents on the projector are not blocked. Proper airflow is crucial to prevent overheating and maintain optimal performance and lifespan of the device.

4. Opbevaring

When not in use for extended periods, store the projector in a cool, dry place, away from direct sunlight and extreme temperatures. It is recommended to use the original packaging or a protective case to prevent dust accumulation and physical damage.

Fejlfinding

Specifikationer

Garanti og support

ELEPHAS products are designed for reliability and performance. For warranty information and technical support, please refer to the warranty card included in your product packaging or visit the official ELEPHAS webwebsted. Behold din købskvittering som købsbevis i tilfælde af garantikrav.

For further assistance, you may contact ELEPHAS customer service through their official channels. Details can typically be found on the manufacturer's webwebstedet eller produktemballagen.
