Nitecore HC65 UHE 2000 Lumen USB-C Genopladelig Pandelampeamp Brugermanual

1. Introduktion

This manual provides detailed instructions for the safe and effective operation, maintenance, and troubleshooting of your Nitecore HC65 UHE 2000 Lumens USB-C Rechargeable Headlamp with Carbon 6K Battery Runtime Extender Kit. Please read this manual thoroughly before use to ensure optimal performance and longevity of the product.

2. Pakkens indhold

• Nitecore HC65 UHE Forlygteamp
• Nitecore Carbon Battery 6K
• 2 x pandebånd
• 2 x USB-C to USB-C Charging Cables
• Beslag
• Klip
• Opbevaringskasse

Image: The Nitecore HC65 UHE headlamp and the Carbon 6K battery runtime extender kit, showing all components included in the package.

3. Opsætning

3.1. Justering af hovedbøjle

Sæt hovedet påamp to the headband. Adjust the elastic straps to ensure a secure and comfortable fit on your head. The headband is designed for stability during various activities.

3.2. Første opladning

Oplad hovedtelefonen helt før første brug.amp. The HC65 UHE features a built-in USB-C charging port. Connect the provided USB-C cable to the headlamp's charging port and to a compatible USB power source. A full charge typically takes approximately 2 hours.

Image: The Nitecore HC65 UHE headlamp connected to a USB-C charging cable, illustrating the charging process.

Image: A diagram showing the power indication system with blue LEDs, indicating battery levels from 25% to 100% based on the number of constant-on lights.

3.3. Connecting the Carbon 6K Battery Runtime Extender

The Carbon 6K Battery Runtime Extender can be connected to the HC65 UHE headlamp to significantly extend its operational time. Securely attach the Carbon 6K battery to the headband using the provided bracket and clips. Connect the quick-release cable from the Carbon 6K to the headlamp's designated port.

• The Carbon 6K provides a well-balanced weight distribution for comfort.
• When connected, the headlamp will prioritize power from the Carbon 6K, preserving the internal battery.

Image: The Nitecore HC65 UHE headlamp shown with the Carbon 6K battery runtime extender attached to the headband, illustrating the complete setup.

Image: An illustration demonstrating how the Nitecore HC65 UHE headlamp draws power from the Carbon 6K battery first when connected, indicated by a glowing yellow power line.

Image: A user wearing the Nitecore HC65 UHE headlamp with the Carbon 6K battery, highlighting the balanced weight distribution for comfortable wear.

4. Betjeningsvejledning

4.1. Tænd/sluk

• For at tænde for hovedetamp: Tryk og hold tænd/sluk-knappen nede i 1 sekund.
• For at slukke hovedetamp: Press and hold the Power Button for 1 second while it is on.

4.2. Mode Switching and Brightness Levels

The HC65 UHE offers a triple output system: Primary White Light, Auxiliary White Light (Reading Light), and Auxiliary Red Light.

Billede: Et nærbillede view of the Nitecore HC65 UHE headlamp's front, highlighting the primary white LEDs and the two auxiliary lights (High CRI White and Red Light).

Primært hvidt lys

• Med hovedetamp on, short press the Mode Button to cycle through brightness levels: ULTRALOW - LOW - MID - HIGH - TURBO.
• Special Modes (SOS, Beacon): Med hovedetamp on, double-press the Mode Button to activate SOS. Double-press again for Beacon. Short press to return to the previous brightness level.

Auxiliary White Light (Reading Light)

• Med hovedetamp off, press and hold the Mode Button for 1 second to activate the Auxiliary White Light.
• Short press the Mode Button to cycle between LOW and ULTRALOW.

Ekstra rødt lys

• Med hovedetamp off, press and hold the Power Button for 1 second to activate the Auxiliary Red Light.
• Short press the Mode Button to cycle between LOW, HIGH, and SLOW FLASHING.

4.3. Red Safety Rear Light

The Carbon 6K Battery features a red safety rear light for enhanced visibility. To turn it on, long press the Power Button on the Carbon 6K for 1 second.

Image: A user wearing the Nitecore HC65 UHE headlamp with the Carbon 6K battery, clearly showing the illuminated red safety rear light on the back of the Carbon 6K unit.

5. Vedligeholdelse

5.1. Rensning

• Tør hovedet afamp and headband with a soft, damp klæde.
• Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• Ensure the USB-C port cover is securely closed to maintain water resistance.

5.2. Opbevaring

• Opbevar hovedlamp på et køligt, tørt sted væk fra direkte sollys.
• For long-term storage, charge the battery every three months to prolong its lifespan.

6. Fejlfinding

• Headlamp tænder ikke: Ensure the battery is charged. Check if the battery is properly connected.
• Dæmpe lysudbytte: Batteriet kan være lavt. Genoplad hovedtelefonerne.amp.
• Opladningsproblemer: Verify the USB-C cable is securely connected to both the headlamp og strømkilden. Prøv et andet USB-C-kabel eller en anden strømadapter.
• Carbon 6K not extending runtime: Ensure the quick-release cable is firmly connected between the Carbon 6K and the headlamp.

If issues persist, please contact Nitecore customer support for further assistance.

7. Specifikationer

Image: A table detailing the technical specifications of the Nitecore HC65 UHE headlamp, including brightness levels, runtime, beam distance, impact resistance, and IP rating for Primary White Light, Auxiliary White Light, and Auxiliary Red Light.

Carbon Battery 6K Specifications

• Vægt: 88 g (3.10 oz)
• Indbygget batteri: 6000mAh
• Energy Density: 245.5Wh/kg
• Function: Runtime Extender, Red Safety Rear Light

Billede: En detaljeret view of the Nitecore Carbon Battery 6K, highlighting its lightweight design, 6000mAh capacity, and energy density.

8. Sikkerhedsoplysninger

• Lad ikke lyset skinne direkte ind i øjnene.
• Opbevares utilgængeligt for børn.
• Adskil eller modificer ikke hovedetamp or battery.
• Avoid exposing the product to extreme temperatures or open flames.
• Ensure the USB-C port cover is sealed when not charging to maintain water resistance.

9. Garanti og support

Nitecore products are covered by a warranty. For detailed warranty information, product registration, or technical support, please visit the official Nitecore website or contact your local distributor. Please retain your purchase receipt for warranty claims.

For yderligere hjælp kan du besøge Nitecore-butik på Amazon.
