Indledning
This manual provides comprehensive instructions for the operation, maintenance, and troubleshooting of your new kinstone 102MF-6+128GB-GY-NEW Android Tablet. Please read this manual carefully before using the device to ensure proper functionality and to maximize your user experience.
Figure 1: Kinstone Android Tablet 10 Inch, front and back view.
Hvad er der i æsken
Kontroller, at alle varer er til stede i emballagen:
- 1 x Android 12G Tablet
- 1 x USB Type-C kabel
- 1 x strømadapter
- 1 x Brugermanual (dette dokument)
Figure 2: Included accessories: tablet, USB-C cable, power adapter, and user manual.
Opsætning
1. Første opladning
Before first use, fully charge the tablet. Connect the provided USB Type-C cable to the tablet's Type-C port and the power adapter, then plug the adapter into a wall outlet.
Figure 3: The tablet features a 6000mAh battery and charges via a Type-C port.
2. Tænd/sluk
- To power on: Press and hold the Power button located on the side of the tablet until the screen lights up.
- Sådan slukker du: Tryk på tænd/sluk-knappen og hold den nede, og vælg derefter "Sluk" fra de muligheder, der vises på skærmen.
3. Indledende konfiguration
Upon first startup, follow the on-screen prompts to set up your language, Wi-Fi connection, Google account, and other basic settings.
4. Indsættelse af et MicroSD-kort (valgfrit)
The tablet supports up to 1TB TF card expansion. Locate the MicroSD card slot on the side of the tablet and gently insert the card until it clicks into place.
Figure 4: The tablet offers 6GB RAM and 128GB ROM, with support for 1TB MicroSD card expansion.
Betjeningsvejledning
1. Grundlæggende navigation
- Berøringsskærmbevægelser: Tryk for at vælge, swipe for at rulle, knib for at zoome.
- Fysiske knapper:
- Power Button: Powers on/off, locks/unlocks screen.
- Volume Buttons: Adjusts audio volume.
- Reset Button: Small pinhole for force restart if needed.
Figur 5: Overview of tablet ports and buttons, including power, volume, reset, and Type-C.
2. Forbindelse
- Wi-Fi: The tablet supports 2.4G and 5G dual-band Wi-Fi. Go to Indstillinger > Netværk og internet > Wi-Fi to connect to a network.
- Bluetooth: The tablet features Bluetooth 5.0 for stable and fast connections. Go to Indstillinger > Forbundne enheder > Bluetooth to pair with devices.
Figure 6: The tablet supports both 2.4G and 5G Wi-Fi bands and Bluetooth 5.0 for reliable connectivity.
3. Kamerabrug
The tablet is equipped with a 5MP rear camera and a 2MP front camera. Open the "Camera" application to capture photos and videos.
Figure 7: The tablet features a 5MP rear camera and a 2MP front camera for capturing moments.
4. Lyd
The tablet features dual speakers for stereo surround sound. An earphone jack is also available for private listening.
Figure 8: The tablet is equipped with dual speakers for enhanced audio experience.
5. Lagerstyring
With 128GB of internal storage and support for up to 1TB external TF card, you can manage your files, applications, and media through the "Files" app or by connecting the tablet to a computer.
6. Applikationsstyring
Download and install applications from the Google Play Store. Manage installed apps via Indstillinger > Apps.
Opretholdelse
1. Rensning
Brug en blød, fnugfri klud til at rengøre skærmen og tablettens kabinet. Undgå at bruge skrappe kemikalier eller slibende materialer.
2. Softwareopdateringer
Tjek regelmæssigt for systemopdateringer for at sikre optimal ydeevne og sikkerhed. Gå til Indstillinger > System > Systemopdatering.
3. Batteripleje
To prolong battery life, avoid extreme temperatures and fully discharging the battery frequently. The 6000mAh battery provides 6-8 hours of usage.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Tabletten tænder ikke. | Lavt batteri; systemnedbrud. | Charge the tablet for at least 30 minutes. If still unresponsive, press the reset button with a pin. |
| Problemer med Wi-Fi-forbindelse. | Forkert adgangskode; routerproblem; uden for rækkevidde. | Verify Wi-Fi password. Restart router. Move closer to the Wi-Fi source. |
| Applikationer der går ned eller fryser. | Utilstrækkelig RAM; app-fejl; forældet software. | Close background apps. Clear app cache. Update the app or system software. |
| Langsom ydeevne. | For mange apps kører; lav lagerplads; forældet software. | Close unused apps. Free up storage space. Perform a system update. |
Specifikationer
| Feature | Detalje |
|---|---|
| Modelnavn | 102MF-6+128GB-GY-NEW |
| Operativsystem | Android |
| Skærmstørrelse | 10.1 tommer |
| Skærmopløsning | 1280 x 800 pixels (IPS HD) |
| Processor | 2 GHz Octa-Core (MediaTek 8183) |
| VÆDDER | 6 GB |
| Intern opbevaring | 128 GB |
| Udvidelig opbevaring | Op til 1 TB (TF-kort) |
| Bagkamera | 5 MP |
| Forreste kamera | 2 MP |
| Trådløs forbindelse | 802.11ac (2.4G+5G Dual Wi-Fi) |
| Bluetooth | Bluetooth 5.0 |
| Batterikapacitet | 6000mAh |
| Gennemsnitlig batterilevetid | 6-8 hours (usage), 10 hours (listed) |
| Opladningsport | Type-C |
| Dimensioner (LxBxH) | 12.9 x 7.5 x 1.4 tommer |
| Varens vægt | 2 pund |
| Farve | Grå |
Figure 9: The tablet is powered by a MediaTek 8183 Octa-core processor for high performance.
Figure 10: The tablet features a 10.1-inch In-cell HD IPS screen with 1280x800 resolution and 178° viewvinkel.
Garanti og support
The Kinstone Android Tablet comes with a 2-års garanti from the date of purchase. This warranty covers manufacturing defects and ensures a satisfactory shopping experience.
For technical support, warranty claims, or any inquiries, please contact Kinstone customer service. We are committed to responding within 12 hours to assist you.
For mere information, besøg den officielle Kinstone-butik på Amazon.
