DANFI AUDIO DF Vinyl Record Player TE-2030 Instruction Manual

Indledning

Tak for købetasing the DANFI AUDIO DF TE-2030 Vinyl Record Player. This manual provides essential information for the safe and efficient operation of your new record player. Please read it thoroughly before use and retain it for future reference.

The TE-2030 is a versatile 3-speed vintage-style record player featuring built-in speakers, adjustable treble and bass controls, Bluetooth input for wireless streaming, and multiple connectivity options including RCA line-out, AUX-in, and a 3.5mm headphone jack. Its belt-driven turntable is designed for smooth vinyl playback, making it suitable for 7", 10", and 12" records.

Sikkerhedsoplysninger

• Læs alle instruktioner, før du bruger pladespilleren.
• Hold enheden væk fra vand eller fugt.
• Bloker ikke nogen ventilationsåbninger.
• Brug kun tilbehør/tilbehør specificeret af producenten.
• Tag stikket ud af enheden under tordenvejr, eller når den ikke skal bruges i længere perioder.
• Overlad al service til kvalificeret servicepersonale.

Hvad er der i æsken

Ved udpakning skal du sørge for, at alle nedenstående varer er til stede og i god stand:

• DANFI AUDIO DF Vinyl Record Player (TE-2030)
• 45 RPM Adapter
• Power Cord (100V-240V~)
• Støvdæksel
• Brugermanual

Produkt overview

Figur 1: Forside og top View of the TE-2030 Record Player with Labeled Components

Front Panel Controls & Features:

• Tænd/sluk-knap/lydstyrkeknap: Turns the unit on/off and adjusts playback volume.
• Treble/Bass Knob: Adjusts the tone for enhanced listening.
• 3.5 mm hovedtelefonstik: Til privat lytning.
• 3.5mm AUX-in: Tilslut eksterne lydenheder.
• Indbyggede højttalere: Integrerede stereohøjttalere til lydudgang.

Turntable Components:

• Pladespillerfad: Where the vinyl record rests.
• Turntable Spindle: Holder rekorden på plads.
• 45 RPM Adapter: Used for 7-inch records with large center holes.
• Tonearmsløfter: Løfter og sænker tonearmen.
• Auto Stop Switch: Enables/disables automatic stopping of the platter.
• Hastighedsskift: Selects playback speed (33 1/3, 45, 78 RPM).
• Cartridge/Stylus: Læser pladens riller.
• Tone Arm Lock: Secures the tonearm when not in use.

Tilslutninger bagpanel:

• Strømport: Tilslutter strømadapteren.
• RCA Audio Out (L/R): Connects to external speakers or an amplivligere.

Opsætning

1. Pak enheden ud: Carefully remove all packaging materials and place the record player on a stable, flat surface.
2. Tilslut strøm: Plug the power cord into the DC 5V 1A input on the back of the unit, then plug the adapter into a standard wall outlet.
3. Fjern pennens beskytter: Gently remove the white protective cap from the stylus.
4. Støvdæksel: Place the clear dust cover onto the hinges at the back of the unit.

Betjeningsvejledning

Afspiller vinylplader

1. Turn the Power/Volume knob clockwise to turn on the unit. The indicator light will illuminate.
2. Place a vinyl record on the turntable platter. If playing a 7-inch record, place the 45 RPM adapter on the center spindle.
3. Select the appropriate speed (33 1/3, 45, or 78 RPM) using the Speed Switching lever.
4. Unlock the tone arm from its rest.
5. Lift the tone arm using the Tone Arm Lifter lever.
6. Manually move the tone arm to the desired position over the record.
7. Gently lower the tone arm onto the record using the Tone Arm Lifter lever. The record will begin playing.
8. Adjust the volume using the Power/Volume knob. Use the Treble/Bass knob to fine-tune the sound.
9. At the end of the record, if the Auto Stop switch is ON, the platter will stop spinning automatically. If OFF, the platter will continue to spin.
10. To stop playback, lift the tone arm, return it to its rest, and lock it. Turn the Power/Volume knob counter-clockwise to turn off the unit.

Bluetooth-indgang

Figure 2: Wireless Bluetooth Streaming to the Record Player

1. Turn the Power/Volume knob clockwise to turn on the unit. The indicator light will flash blue, indicating Bluetooth pairing mode.
2. Enable Bluetooth on your smartphone or other device and search for “TE-2030”.
3. Select “TE-2030” to pair. Once connected, the indicator light will turn solid blue.
4. Play music from your device. Audio will stream through the record player's built-in speakers.
5. Adjust volume and tone using the knobs on the record player or your device.

AUX-indgang

Figure 3: AUX-In and RCA Output Ports

1. Connect a 3.5mm audio cable (not included) from your external audio device to the AUX-in port on the front of the record player.
2. The unit will automatically switch to AUX mode.
3. Play music from your connected device. Audio will be routed through the record player's speakers.
4. Adjust volume and tone as desired.

Lytning til hovedtelefoner

Figure 4: Private Listening via Headphone Jack

1. Plug your 3.5mm headphones (not included) into the headphone jack on the front of the unit.
2. Audio will now be routed through your headphones for private listening.
3. Adjust volume and tone as desired.

RCA Line-Out

1. Connect an RCA cable (not included) from the RCA Audio Out ports (red for right, white for left) on the back of the unit to your external amplifier eller drevne højttalere.
2. Ensure your external audio system is set to the correct input.
3. Audio will play through the connected external system.

Opretholdelse

Udskiftning af stylus

The stylus should last about 200-250 hours under normal use. If you notice a change in sound quality, it may be time to replace the stylus. The stylus needle is a universal type for Victrola and Crosley record players, purchasable on Amazon.

1. Fjernelse af den gamle stylus: Gently pull down the front edge of the needle. Pull the needle forward. Pull out and remove.
2. Installation af en ny stylus: Hold the tip of the stylus and insert the other edge by pressing upward. Push the stylus upward until it locks at the tip.

Almen pleje

• Keep the unit clean and dust-free. Use a soft, dry cloth for cleaning.
• Undgå at berøre pennen med fingrene.
• Handle records by the edges to prevent fingerprints and dust.

Fejlfinding

Specifikationer

Officiel produktvideo

Garanti & Support

For any questions, problems, or missing parts, please contact customer support directly. The manufacturer offers support for product inquiries.

E -mail til kundesupport: support23@163.com

Please refer to the original purchase documentation for specific warranty details.
