Arenti O3 2.5K/4MP udendørskamera brugermanual

1. Introduktion

This manual provides detailed instructions for the installation, operation, and maintenance of your Arenti O3 2.5K/4MP House Camera Outdoor. This camera is designed to provide reliable outdoor surveillance with advanced features such as 2.5K/4MP resolution, color night vision, spotlight and siren alarm, AI-powered motion detection, and two-way audio communication. Please read this manual thoroughly before using the product to ensure proper setup and optimal performance.

2. Pakkens indhold

Please check the package contents upon unboxing. If any items are missing or damaged, contact Arenti customer support.

• Arenti O3 2.5K/4MP Outdoor Camera
• Strømadapter (oplader)
• Monteringsskruer og vægdyvler
• Monteringsskabelon
• Brugervejledning (dette dokument)

3. Produktet er slutview

Familiarize yourself with the components of your Arenti O3 outdoor camera.

Figur 3.1: Arenti O3 2.5K/4MP Outdoor Camera. This image shows the camera mounted on a wall, connected by a cable, with a smartphone displaying its live view. The camera features a lens, a spotlight, and a sturdy mounting bracket.

• Kameraobjektiv: Captures 2.5K/4MP resolution video.
• Spotlight: Giver belysning til farvenatsyn og fungerer afskrækkende.
• Infrarøde lysdioder: For traditional black and white night vision.
• Mikrofon: Captures audio for two-way communication and noise detection.
• Højttaler: Enables two-way audio communication and siren alarm.
• Monteringsbeslag: Til sikker vægmontering.
• Strømkabel: Tilslutter kameraet til strømadapteren.
• Micro SD -kortplads: For local storage (supports up to 256GB, card not included).

4. Opsætning og installation

4.1 Appinstallation og kontooprettelse

Before physical installation, download the Arenti app and create an account.

1. Søg efter "Arenti" in your mobile device's app store (Google Play Store for Android or Apple App Store for iOS).
2. Download and install the Arenti app.
3. Åbn appen, og følg instruktionerne på skærmen for at registrere en ny konto eller logge ind, hvis du allerede har en.

Figur 4.1: Arenti Mobile Application. The image displays the Arenti app icon and a smartphone screen showing the app's interface with multiple camera feeds.

4.2 Fysisk installation

Choose a suitable location for your camera. The Arenti O3 is IP65 weather-resistant, designed to withstand various outdoor conditions.

1. Vælg placering: Vælg en placering, der tilbyder det ønskede viewing angle and is within range of your 2.4GHz Wi-Fi network. Ensure there is a power outlet nearby.
2. Monteringsoverflade: The camera can be wall-mounted. Use the provided mounting template to mark drill holes.
3. Bore huller: Bor huller på de markerede steder. Indsæt rawlplugs, hvis det monteres på murværk eller gipsvæg.
4. Sikkert kamera: Juster kameraets monteringsbeslag med hullerne, og fastgør det med de medfølgende skruer.
5. Tilslut strøm: Connect the power cable to the camera and plug the power adapter into a suitable outdoor-rated electrical outlet.

Figur 4.2: IP65 Weather Resistance. This image illustrates the Arenti O3 camera's durability against various weather conditions, including rain and snow, highlighting its IP65 rating.

4.3 Tilslutning til Wi-Fi

After physical installation, connect your camera to your home Wi-Fi network using the Arenti app.

1. Åbn Arenti-appen, og tryk på "+"-ikonet for at tilføje en ny enhed.
2. Vælg din kameramodel fra listen.
3. Follow the in-app instructions to connect the camera to your 2.4GHz Wi-Fi network. This typically involves scanning a QR code generated by the app with the camera's lens.
4. Når der er forbindelse, ændres kameraets statusindikator, og du vil se livefeedet i appen.

5. Betjening

5.1 Live View og opløsning

Access the live video feed from your camera through the Arenti app. The camera provides a clear 2.5K/4MP resolution for detailed monitoring.

Figur 5.1: 2.5K/4MP Resolution and Color Night Vision. This image compares the superior clarity of Arenti's 4MP resolution with standard 1080P, and demonstrates the camera's ability to capture full-color images even in low-light conditions.

5.2 Tovejslyd

Den indbyggede mikrofon og højttaler muliggør tovejskommunikation i realtid.

• Fra live view screen in the app, tap the microphone icon to speak through the camera's speaker.
• Tryk på højttalerikonet for at lytte til lyd fra kameraets omgivelser.

Figur 5.2: Clearly Two-Way Audio. This image shows the Arenti O3 camera facilitating a conversation between a user and a delivery person, illustrating its two-way audio capability.

5.3 Bevægelsesdetektion og advarsler

The camera features AI-powered human motion detection and customizable detection zones to minimize false alarms.

• Aktivér bevægelsesdetektion: In the app settings for your camera, enable motion detection.
• Tilpas detektionszoner: Definer specifikke områder inden for kameraets view where you want motion to be detected. This helps focus on critical areas and ignore irrelevant movements.
• Modtag advarsler: When motion is detected, the camera will automatically track the movement and send instant alerts to your phone.

Figur 5.3: Only Focus What You Care. This image demonstrates the camera's human and activity zone detection, outlining a child to show how it focuses on relevant motion.

5.4 Nattesyn

The O3 camera offers both traditional infrared night vision and advanced color night vision.

• Farve Night Vision: Enabled by the starlight CMOS sensor and 3000K warm light, providing clear, full-color images even in low-light conditions.
• Infrarødt nattesyn: Utilizes 2850nm infrared LEDs for clear black and white images in complete darkness.
• Settings for night vision modes can be adjusted within the Arenti app.

5.5 Optagelse og opbevaring

Your Arenti O3 camera supports both cloud storage and local storage options.

• Gratis cloud-lagring: The camera supports free 7-day cycle event recording cloud storage (requires App version 4.0.0+ and device version 5.5.4+).
• Lokal opbevaring: Supports full-day recording with FAT32 Micro SD cards (not included) up to 256GB. Insert the Micro SD card into the designated slot on the camera.
• Du kan genview optaget footage via the Arenti app, selecting either cloud or SD card playback.

Figur 5.4: No Subscription Required for Basic Storage. This image highlights the camera's feature of free 7-day cycle event recording cloud storage, alongside local storage options.

5.6 Spotlight og sirenealarm

The camera is equipped with a built-in spotlight and siren for active deterrence.

• When human or motion is detected, you can configure the camera to automatically activate the spotlight and/or siren alarm.
• These features can also be manually triggered from the Arenti app.

Figur 5.5: Siren and Spotlight Alarm. This image depicts the Arenti O3 camera's spotlight illuminating an area and its siren acting as an instant alert to deter unwanted visitors.

5.7 Smart Home-integration (Alexa)

The Arenti O3 camera is compatible with Amazon Alexa, allowing for voice control and integration into your smart home ecosystem.

• Enable the Arenti skill in the Alexa app.
• Link your Arenti account with your Alexa account.
• You can then use voice commands to view your camera feed on compatible Alexa-enabled devices (e.g., "Alexa, show me the front door camera").

6. Vedligeholdelse

Regular maintenance ensures the longevity and optimal performance of your Arenti O3 camera.

• Rengøring af linser: Gently wipe the camera lens with a soft, clean, lint-free cloth to remove dust or smudges. Avoid abrasive cleaners.
• Rengøring af bolig: Rengør kamerahuset med reklameamp klæde. Brug ikke skrappe kemikalier.
• Firmwareopdateringer: Regularly check the Arenti app for firmware updates. Keeping your camera's firmware up-to-date ensures access to the latest features and security enhancements.
• Strømtilslutning: Periodically inspect the power cable and adapter for any signs of damage.

7. Fejlfinding

If you encounter issues with your Arenti O3 camera, refer to the following common troubleshooting steps.

8. Specifikationer

Key technical specifications for the Arenti O3 2.5K/4MP Outdoor Camera.

9. Garanti og support

Your Arenti O3 camera comes with a manufacturer's warranty and dedicated customer support.

• Garanti: Produktet er dækket af en 2 års producentgarantiGem venligst din købsbevis i tilfælde af garantikrav.
• Kundesupport: For technical assistance, troubleshooting, or warranty inquiries, please contact Arenti customer support via email.
• E-mail: support@arenti.com
