1. Introduktion
Thank you for choosing the Lepulse Smart Scale F3. This smart scale is designed to provide comprehensive body composition analysis, helping you track your health and fitness journey. It measures 13 essential body metrics and syncs with the Vihealth app for detailed data management and progress tracking.
Figure 1.1: Lepulse Smart Scale F3 displaying weight and BMI, with companion app on smartphone and smartwatch.
2. Sikkerhedsoplysninger
- Må ikke anvendes, hvis du har en pacemaker eller anden intern medicinsk anordning.
- Må ikke bruges, hvis du er gravid.
- Placer vægten på en hård, flad overflade for at opnå nøjagtige målinger. Undgå tæpper eller ujævne gulve.
- Keep the scale dry. Do not immerse in water or use harsh chemical cleaners.
- Vægtens overflade kan være glat, når den er våd. Træd forsigtigt på og af.
- Denne vægt er kun til husholdningsbrug og bør ikke anvendes til medicinsk diagnose eller behandling.
- Opbevares utilgængeligt for børn.
3. Pakkens indhold
Bekræft at alle varer er til stede i pakken:
- Lepulse Smart Scale F3
- Brugermanual
4. Produktfunktioner
The Lepulse Smart Scale F3 offers advanced features for comprehensive health monitoring:
- Stort display: Sequentially displays 7 key metrics directly on the scale: weight, body fat, body water, BMI, muscle mass, bone mass, and body type.
- Højpræcisionssensorer: Equipped with large X-shaped stainless steel electrodes and high-precision gravity sensors for accurate readings.
- Offline datalagring: Stores data for up to 8 users and 24 measurements even when not connected to the app. Data syncs automatically upon next connection.
- 13 Essential Metrics: Measures weight, BMI, body fat, muscle mass, body water, BMR, protein ratio, fat mass, bone mass, visceral fat, subcutaneous fat, skeletal muscle mass, and body age.
- Multi-User Support: The Vihealth app supports up to 10 users with individual data management and unlimited data storage.
- Særlige tilstande: Includes Athlete Mode for workout enthusiasts and Baby Mode for weighing infants or pets.
- App-integration: Seamlessly syncs with Apple Health, Google Fit, and other health platforms via the Vihealth app.
- Holdbart design: 6mm tempered glass platform with a 400lb/180kg/28st capacity and rounded corners for enhanced safety.
Figure 4.1: The 13 body composition metrics measured by the Lepulse Smart Scale F3.
5. Opsætning
5.1 Batteriinstallation
The Lepulse Smart Scale F3 typically uses AAA batteries (not always included). Locate the battery compartment on the underside of the scale. Insert the batteries according to the polarity indicators (+/-).
5.2 Download og parring af app
- Download Vihealth app from the App Store (for iOS) or Google Play Store (for Android).
- Aktiver Bluetooth på din smartphone.
- Open the Vihealth app and create an account or log in.
- Follow the in-app instructions to pair your scale. This usually involves stepping on the scale to activate it while the app is open and searching for devices.
Figure 5.1: Connecting the Lepulse Smart Scale F3 to the Vihealth app and other health platforms.
6. Betjeningsvejledning
6.1 Tage en måling
- Placer vægten på en hård, flad og stabil overflade.
- Step onto the scale barefoot and stand still. Ensure your feet are positioned on the stainless steel electrodes for accurate body composition analysis.
- The scale display will show your weight first, followed by other metrics sequentially.
- If the Vihealth app is open and connected, your data will automatically sync. If not, the scale will store the data for later synchronization.
Figure 6.1: Accurate weight measurement on the Lepulse Smart Scale F3.
6.2 Understanding Display Metrics
The scale's large VA screen sequentially displays 7 key metrics:
- Vægt: Din nuværende kropsvægt.
- Kropsfedt: Procenttage af kropsfedt.
- Kropsvand: Procenttage af vand i din krop.
- BMI: Kropsmasseindeks.
- Muskelmasse: Procenttage of muscle in your body.
- Knoglemasse: Weight of bone mineral in your body.
- Kropstype: An assessment of your body composition.
Figure 6.2: Sequential display of metrics on the Lepulse Smart Scale F3.
6.3 Flerbrugerfunktionalitet
The Lepulse Smart Scale F3 can automatically recognize up to 8 users based on their weight data. For more detailed user management and individual tracking, use the Vihealth app.
Figure 6.3: The Lepulse Smart Scale F3 supports multiple users for family health tracking.
6.4 Special Modes (Vihealth App)
The Vihealth app offers specialized modes for tailored tracking:
- Atlettilstand: Recommended for individuals aged 18+ who exercise 3 or more times weekly. This mode adjusts the algorithm for more accurate body composition readings for athletes.
- Baby Mode / Pet Mode: Allows you to weigh a baby or pet by first weighing yourself, then holding the baby/pet and stepping on the scale again. The app will calculate the baby's/pet's weight.
Figure 6.4: Athlete Mode in the Vihealth app for specialized tracking.
Figure 6.5: Baby Mode/Pet Mode for weighing infants or pets.
7. Vihealth App Usage
The Vihealth app is central to utilizing all features of your Lepulse Smart Scale F3.
7.1 Viewing All 13 Metrics
After syncing, open the Vihealth app to view all 13 body composition metrics, including those not displayed directly on the scale. The app provides detailed insights and historical data.
7.2 Goal Setting and Progress Tracking
The app allows you to set health goals and track your progress over time with detailed graphs (weekly, monthly, yearly). This visual representation helps in monitoring your fitness journey effectively.
Figure 7.1: Tracking progress and setting goals within the Vihealth app.
7.3 Data Sharing and Integration
The Vihealth app supports seamless synchronization with popular health platforms such as Apple Health, Google Fit, and Fitbit. You can also easily share your data on various social platforms directly from the app.
8. Vedligeholdelse og pleje
- Rengør vægtens overflade med en blød,amp klud. Brug ikke slibende rengøringsmidler, og nedsænk ikke vægten i vand.
- Opbevar vægten på et køligt, tørt sted.
- Hvis vægten ikke skal bruges i længere tid, skal batterierne fjernes for at forhindre lækage.
- Avoid dropping the scale or subjecting it to strong impacts, as this may damage the sensors.
9. Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Unøjagtige eller inkonsistente aflæsninger | Scale is on an uneven surface; Batteries are low; Scale moved between measurements; User not standing still. | Ensure scale is on a hard, flat, stable surface. Replace batteries. Avoid moving the scale. Stand still during measurement. For best accuracy, weigh yourself at the same time each day under similar conditions. |
| Scale only shows weight, no other metrics | Not standing barefoot; Feet not making proper contact with electrodes; App not connected or profile not set up correctly. | Ensure you are standing barefoot with feet centered on the electrodes. Verify the Vihealth app is open, connected via Bluetooth, and your user profile (age, height, gender) is correctly entered. Full body composition analysis requires electrical impedance measurement through bare feet. |
| Bluetooth pairing issues or frequent disconnection | Bluetooth interference; App or phone issue; Scale battery low. | Ensure Bluetooth is enabled on your phone and the app is open. Try restarting your phone and the app. Replace scale batteries. Move closer to the scale. If issues persist, try unpairing and re-pairing the scale in the app's settings. |
| Scale unit (KG/LB) keeps changing | Unit setting reset. | Check the unit switch in the battery compartment (if available) and ensure it's set to your preferred unit. If the issue persists, ensure the app's unit setting matches and is stable. |
10. Specifikationer
| Feature | Detalje |
|---|---|
| Produktdimensioner | 11 x 11 x 1.06 tommer |
| Produktets vægt | 3.66 pund |
| Mærke | Lepulse |
| Farve | Sort |
| Anbefalede anvendelser | 13 Body Composition Metrics, Babies & Pets (Baby Mode), Bathroom Scales for Weight, Body Fat Scale, Fitness Tracking, Humans & Adults (Universal Mode), Measure Heart Rate, Scale for Body Weight, Smart Digital Scale, Weight Loss Progress Tracking, Workout Enthusiasts (Athlete Mode) |
| Særlige funktioner | Auto Shut Off, Backlit Display, Body Fat, Bodyweight, Large Display |
| Display Type | LCD |
| Kapacitet | 400lb / 180kg / 28st |
| Afdeling | 0.05 kg / 0.1 lb |
11. Garanti og support
Lepulse offers a 30-day return policy for this product. For any inquiries or assistance, please contact our customer service. We aim to provide responsive 24-hour customer support.
Se venligst din købsdokumentation for specifikke garantivilkår og kontaktoplysninger.
